Mitsubishi M80 series

M800S/M80/E80 Series Connection and Setup Manual
4 General Specifications
101
IB-1501269-J
<Input/output circuit>
(a) 5V manual pulse generator
(Note) No HA3A and HA3B in FCU8-DX731.
(b) 12V manual pulse generator
(Note) No HA3A and HA3B in FCU8-DX731.
HA1A
HA2A
HA3A
HA1B
HA2B
HA3B
+5V
0V
5V
+5V
+5V
0V
0V
0V
MPG
B
A
5V
0V
470Ω
470Ω
Control
circuit
B
A
MPG
HA1A
HA2A
HA3A
HA1B
HA2B
HA3B
+12V
0V
+5V
+5V
+12V
0V
0V
0V
12V
0V
470Ω
470Ω
Control
circuit
