M800S/M80/E80 Series Connection and Setup Manual
4 General Specifications
102
IB-1501269-J
(13) RIO3EXT (Remote I/O 2.0 communication)
(14) RIO3 (Remote I/O 2.0 communication)
<Cable side connector type>
Connector : 1-1318119-3
Contact : 1318107-1 x6
Recommended manufacturer : Tyco Electronics
Refer to the following chart for the maximum number of connecting stations and I/O points.
(Note 1) Refer to the section "General Specifications: Remote I/O Unit" for the number of occupying stations and I/
O points of remote I/O units.
(15) CJ71 (Control unit I/F)
<Cable side connector type>
Connector : 2-1318119-4
Contact : 1318107-1
Recommended manufacturer : Tyco Electronics
AB
1 I/O TXRXD 1 I/O TXRXD*
2 NC 2 0V
3 FG 3 NC
Operation panel I/O unit type
Max. number of stations
(RIO3EXT connection)
Max. number of I/O points
(RIO3EXT connection)
FCU8-DX731
53 stations
(2nd, 4th to 6th, 13th to 19th, and 23rd to 64th
stations can be used)
1696 points/ 1696 points
FCU8-DX750
52 stations
(4th to 6th, 13th to 19th, and 23rd to 64th stations
can be used)
1664 points/ 1664 points
FCU8-DX760
51 stations
(5th, 6th, 13th to 19th, and 23rd to 64th stations
can be used)
1632 points/ 1632 points
FCU8-DX761
50 stations
(6th, 13th to 19th, and 23rd to 64th stations can be
used)
1600 points/ 1600 points
FCU8-DX834
49 stations
(5th, 6th, 15th to 19th, and 23rd to 64th stations
can be used)
1568 points/ 1568 points
A1 I/O TXRXD B1 I/O TXRXD*
A2 -+5V B2 - +3.3V
A3 -- B3 -0V
A4 -FG B4 -0V
