M800S/M80/E80 Series Connection and Setup Manual
6 Precautions for Connecting
222
IB-1501269-J
(e) For the optical cable connector, pull off while holding down the lock button.
(f) For the Ethernet connector, pull off while holding down the locked latch.
(g) For the USB connector, pull off while holding down the locked latch.
CAUTION
1. Do not connect or disconnect the cables between units while the power is ON.
2. Do not pull the cables when connecting/disconnecting it.
(1)
(2)
Press
Pull
(1)
(2)
Press
Pull
(1)
(2)
Press
Pull
