M800S/M80/E80 Series Connection and Setup Manual
13 Connection of MITSUBISHI CNC Machine Operation Panel
335
IB-1501269-J
<Device No. of key switches>
(Note 1) "$" in the device No. varies depending on the channel No. of RIO.
(RIO1 = "0", RIO2 = "2", RIO3 = "4")
(Note 2) While the key switch is pressed, "1" is input in the ZR device.
Key switch Device Key switch Device
X00 ZR5$24[0] X20 ZR5$26[0]
X01 ZR5$24[1] X21 ZR5$26[1]
X02 ZR5$24[2] X22 ZR5$26[2]
X03 ZR5$24[3] X23 ZR5$26[3]
X04 ZR5$24[4] X24 ZR5$26[4]
X05 ZR5$24[5] X25 ZR5$26[5]
X06 ZR5$24[6] X26 ZR5$26[6]
X07 ZR5$24[7] X27 ZR5$26[7]
X08 ZR5$24[8] X28 ZR5$26[8]
X09 ZR5$24[9] X29 ZR5$26[9]
X0A ZR5$24[A] X2A ZR5$26[A]
X0B ZR5$24[B] Not used ZR5$26[B]
X0C ZR5$24[C] X2C ZR5$26[C]
X0D ZR5$24[D] X2D ZR5$26[D]
X0E ZR5$24[E] X2E ZR5$26[E]
X0F ZR5$24[F] Not used ZR5$26[F]
X10 ZR5$25[0] X30 ZR5$27[0]
X11 ZR5$25[1] X31 ZR5$27[1]
X12 ZR5$25[2] X32 ZR5$27[2]
X13 ZR5$25[3] Not used ZR5$27[3]
X14 ZR5$25[4] X34 ZR5$27[4]
X15 ZR5$25[5] X35 ZR5$27[5]
X16 ZR5$25[6] X36 ZR5$27[6]
X17 ZR5$25[7] Not used ZR5$27[7]
X18 ZR5$25[8] X38 ZR5$27[8]
X19 ZR5$25[9] X39 ZR5$27[9]
X1A ZR5$25[A] X3A ZR5$27[A]
X1B ZR5$25[B] Not used ZR5$27[B]
X1C ZR5$25[C] Not used ZR5$27[C]
X1D ZR5$25[D] Not used ZR5$27[D]
X1E ZR5$25[E] Not used ZR5$27[E]
X1F ZR5$25[F] Not used ZR5$27[F]
