Mitsubishi M80 series User Manual

M800S/M80/E80 Series Connection and Setup Manual
32 SRAM Open Parameter Screen
554
IB-1501269-J
Display item Details Setting range
(4) Display format
Designate the display format of the data, display limitation and the
state of the input protection.
a) Cancellation of input protection
1: Not check
Input protection check for the data protection key 2 will not be
executed in the group detail screen.
0: Check
Input protection check for the data protection key 2 will be
executed in the group detail screen.
The name of the data protection key varies depending on the
machine tool builder. Refer to the instruction manual issued by
the machine tool builder for details.
b) Cancellation of restriction on display
1: Display
The group detail screen is displayed without entering the
machine tool builder's password.
0: Not display
The group detail screen is not displayed when the password
is not entered.
c) BCD fromat
1: Valid
Display the group detail screen data in BCD format.
0: Invalid
d) BIT format
1: Display the group detail screen data in BIT format.
0: Invalid
e) HEX format (Hexadecimal format)
1: Valid
Display the group detail screen data in HEX format.
0: Invalid
f) Sign (Decimal format only)
1: Without sign
Display the group detail screen data in decimal format
without sign.
0: With sign
Display the group detail screen data in decimal format with sign.
- This will be valid after the power is turned ON again.
- When "BCD format", "HEX format" and "BIT format" are all set to "0"
or more than one format is set to "1", the data display format will be
decimal format with sign.
- If the data type is "DOUBLE", it will be decimal format with sign.
-
(5) Amount of free space
Display the amount of free space of the SRAM open area. It will be
updated each time the data type or the number of data is set. If the data
input exceeds the amount of free space, it will be displayed in negative
value. The area will not be allocated even it is formatted. Adjust the
data type and the number of data to make it positive value.
The format is ####.##XB (X: prefix ... K, M). When it is less than 1024
byte, it is ####B.
-
7 6 5 4 3 2 1 0
a)
b)
c)
d)
e)
f)
