5 - 87
Chapter 5 Data Used for Positioning Control
When "
Pr.1
Unit Setting" is "degree"
The table below lists the control systems that require the setting of the positioning
address or movement amount and the associated setting ranges.
(With any control system excluded from the table below, neither the positioning
address nor the movement amount needs to be set.)
Da.2
setting value
Value set with GX Works2
(degree)
Value set with sequence program
1
(
10
-5
degree)
ABS Linear 1 : 01H
ABS Linear 2 : 0AH
ABS Linear 3 : 15H
ABS Linear 4 : 1AH
Current value changing : 81H
Set the address
0 to 359.99999
Set the address
0 to 35999999
INC Linear 1 : 02H
INC Linear 2 : 0BH
INC Linear 3 : 16H
INC Linear 4 : 1BH
Fixed-feed 1 : 03H
Fixed-feed 2 : 0CH
Fixed-feed 3 : 17H
Fixed-feed 4 : 1CH
Set the movement amount
-21474.83648 to 21474.83647
Set the movement amount
-2147483648 to 2147483647 2
Forward run speed/position : 06H
Reverse run speed/position : 07H
In INC mode
Set the movement amount
0 to 21474.83647
In ABS mode
Set the address
0 to 359.99999
In INC mode
Set the movement amount
0 to 2147483647
In ABS mode
Set the address
0 to 35999999
Forward run position/speed : 08H
Reverse run position/speed : 09H
Set the movement amount
0 to 21474.83647
Set the movement amount
0 to 2147483647
1: Set an integer because the sequence program cannot handle fractions.
(The value will be converted properly within the system.)
2: When the software stroke limit is valid, -35999999 to 35999999 is set.
