5 - 88
Chapter 5 Data Used for Positioning Control
When "
Pr.1
Unit Setting" is "PLS"
The table below lists the control systems that require the setting of the positioning
address or movement amount and the associated setting ranges.
(With any control system excluded from the table below, neither the positioning
address nor the movement amount needs to be set.)
Da.2
setting value
Value set with GX Works2
(PLS)
Value set with sequence program
1
(PLS)
ABS Linear 1 : 01H
ABS Linear 2 : 0AH
ABS Linear 3 : 15H
ABS Linear 4 : 1AH
Current value changing : 81H
Set the address
-2147483648 to 2147483647
Set the address
-2147483648 to 2147483647
INC Linear 1 : 02H
INC Linear 2 : 0BH
INC Linear 3 : 16H
INC Linear 4 : 1BH
Fixed-feed 1 : 03H
Fixed-feed 2 : 0CH
Fixed-feed 3 : 17H
Fixed-feed 4 : 1CH
Set the movement amount
-2147483648 to 2147483647
Set the movement amount
-2147483648 to 2147483647
Forward run speed/position : 06H
Reverse run speed/position : 07H
Forward run position/speed : 08H
Reverse run position/speed : 09H
Set the movement amount
0 to 2147483647
Set the movement amount
0 to 2147483647
ABS circular sub : 0DH
ABS circular right : 0FH
ABS circular left : 10H
Set the address
-2147483648 to 2147483647
Set the address
-2147483648 to 2147483647
INC circular sub : 0EH
INC circular right : 11H
INC circular left : 12H
Set the movement amount
-2147483648 to 2147483647
Set the movement amount
-2147483648 to 2147483647
