Mitsubishi MELSEC-Q QD77MS User Manual

5 - 165
Chapter 5 Data Used for Positioning Control
Storage buffer
memory address
Setting value
Default
value
QD77MS2
QD77MS4
QD77MS16
Set with a decimal.
Setting
value
K
Acceleration/deceleration time change
during speed change, enable/disable selection
1 : Enables modifications to
acceleration/deceleration time
Other than 1: Disables modifications to
acceleration/deceleration time
0 1512+100n 4312+100n
Set with a decimal.
Setting value
Override value (%)
1 to 300
K
100 1513+100n 4313+100n
Set with a decimal.
A
ctual value
Conversion into an integer value
Cd.14 New speed value
10
m
Unit conversion table ( Cd.14 )
m
mm/min
inch/min
degree/min
2
3
3
0
PLS/s
Unit
R
Setting value
(Decimal)
Example: When the " Cd. 14 New speed
value" is set as "20000.00mm
/min", the buffer memory
stores "2000000".
When " Pr.83 Speed
control 10 x multiplier
setting for degree axis"
is valid : "2"
0
1514+100n
1515+100n
4314+100n
4315+100n
Set with a decimal.
Setting
value
Speed change request
1: Executes speed change.
K
The QD77MS resets the value to "0" automatically
when the speed change request has been processed.
(This indicates the completion of speed change request.)
1
0 1516+100n 4316+100n
n: Axis No.-1
