Mitsubishi MELSEC-Q QD77MS

5 - 166
Chapter 5 Data Used for Positioning Control
Setting item Setting details
•
Use this data item to set the amount of movement by inching.
•
The machine performs a JOG operation if "0" is set.
•
Set a value within the following range:
Pr.1
Unit
setting
mm
(
×
10
-1
µm)
inch
(
×
10
-5
inch)
degree
(
×
10
-5
degree)
PLS
(PLS)
Setting range 0 to 65535 0 to 65535 0 to 65535 0 to 65535
Cd.16
Inching movement amount
Fetch cycle: At start
•
Use this data item to set the JOG speed.
•
Set a value within the following range:
Pr.1
Unit
setting
mm
(
×
10
-2
mm/min)
inch
(
×
10
-3
inch/min)
Degree
(
×
10
-3
degree/min)
PLS
(PLS/s)
Setting range
1 to
2000000000
1 to
2000000000
1 to
2000000000
1 to 1000000000
Cd.17
JOG speed
: When "
Pr.83
Speed control 10 x multiplier setting for degree axis" is valid,
this will be the setting range
1 to 2000000000 (
×
10
-2
degree/min).
Fetch cycle: At start
Cd.18
Interrupt request during
continuous operation
•
To interrupt a continuous operation, set "1" to this data item.
•
After processing the interruption request ("1"), the QD77MS automatically resets
the value to "0".
Fetch cycle: Operation cycle
