1 - 12
Chapter 1 Product Outline
(3) Fixed-feed control
This performs positioning for the specified increment of travel.
Stop position
[1-axis fixed-feed control]
Positioning direction
V
Start
t
ON
OFF
Start
command
Operation timing
Travel along axis 2
Reverse
direction
Stop position
Movement direction for
a positive movement amount
Positioning
direction
Travel along
axis 1
[2-axis fixed-feed control]
Forward directionReverse direction
Forward
direction
Forward
direction
Reverse
direction
Movement direction for
a negative movement amount
(4) Speed control
After command is executed, control continues with the command speed until the
stop command is input.
V
t
ON
ON
ON
OFF
OFF
OFF
Positioning start
signal
BUSY signal
Axis stop signal
(By the sequence
program creation)
