Chapter 9 Major Positioning Control
Speed-position switching signal setting
(1) The following table shows the items that must be set to use the external
command signals [DI] as speed-position switching signals.
Buffer memory address
Setting item
Setting
value
Setting details
QD77MS2
QD77MS4
QD77MS16
Pr.42
External
command
function selection
2
Speed-position, position-speed
switching request.
62+150n
Cd.8
External
command valid
1
Validates an external
command.
1505+100n 4305+100n
Cd.45
Speed-position
switching device
selection
0
Use the external command
signal for switching from speed
control to position control.
1566+100n 4366+100n
(Note): Set the external command signal [DI] in " Pr.95 External command signal selection" at QD77MS16 use.
Refer to Section 5.2 "List of parameters" and Section 5.7 "List of control data" for information on the
setting details.
(2) The following table shows the items that must be set to use the near-point dog
signal (DOG) as speed-position switching signals.
Buffer memory address
Setting item
Setting
value
Setting details
QD77MS2
QD77MS4
QD77MS16
Cd.45
Speed-position
switching device
selection
1
Use the near-point dog signal
for switching from speed
control to position control
1566+100n 4366+100n
(Note): The setting is not required for " Pr.42 External command function selection" and " Cd.8 External command
valid
".
Refer to Section 5.7 "List of control data" for information on the setting details.
(3) The following table shows the items that must be set to use "
Cd.46 Speed-
position switching command" as speed-position switching signals.
Buffer memory address
Setting item
Setting
value
Setting details
QD77MS2
QD77MS4
QD77MS16
Cd.45
Speed-position
switching device
selection
2
Use the "
Cd.46 Speed-position
switching command
" for
switching from speed control
to position control
1566+100n 4366+100n
(Note): The setting is not required for " Pr.42 External command function selection" and " Cd.8 External command
valid
".
Refer to Section 5.7 "List of control data" for information on the setting details.
