Chapter 16 Troubleshooting
Classification
of warnings
Warning
code
Warning name Warning Operation status at warning occurrence
132
Outside mark detection
data axis No. setting
range
When the mark detection data type setting
is not "Optional 2 word buffer memory",
the mark detection data type setting is
outside the range.
Common
warnings
133
Outside mark detection
data buffer memory No.
setting range
When the mark detection data type setting
is "Optional 2 word buffer memory", the
mark detection data buffer memory No. is
outside the range or odd number.
All mark detections are not operated.
300
Speed change during
deceleration
The speed change request is issued
during deceleration stop with JOG start
signal OFF.
The speed change is not carried out.
JOG operation
warnings
301 JOG speed limit value
• The JOG speed
(Note-1)
is exceeded the
speed limit value at start.
• The new speed value
(Note-1)
exceeds
the JOG speed limit value when the
speed is changed during operation.
(Note-1): This speed is a value in which
override value is considered
when override function is used.
("
Cd.13
Positioning operation
speed override" is set other then
100[%].)
• When the speed exceeds the JOG speed
limit, the JOG operation is carried out with
the JOG speed limit value.
• While the speed is limited by the JOG
speed limit value, the "
Md.39 In speed limit
flag
" is turned ON.
Manual pulse
generator
operation
warnings
401
Outside manual pulse
generator input
magnification range
The manual pulse generator 1 pulse input
magnification is set to 0, 10001 or more,
or negative value.
• When input magnification is set at 10001
or more, or negative value:
Re-set to 10000.
• When input magnification is set at 0: Re-
set to 1.
