Mitsubishi MELSEC-Q QD77MS - Page 916

Appendix - 7
Appendices
Buffer memory address
QD77MS2
QD77MS4
QD77MS16
Compatibility
of setting value
of QD77MS2/
QD77MS4 and
QD77MS16
Item
Memory
area
800+100n
801+100n
2400+100n
2401+100n
Md.20
Current feed value
802+100n
803+100n
2402+100n
2403+100n
Md.21
Machine feed value
804+100n
805+100n
2404+100n
2405+100n
Md.22
Feedrate
806+100n 2406+100n
Md.23
Axis error No.
807+100n 2407+100n
Md.24
Axis warning No.
808+100n 2408+100n
Md.25
Valid M code
809+100n 2409+100n
Md.26
Axis operation status
810+100n
811+100n
2410+100n
2411+100n
Md.27
Current speed
812+100n
813+100n
2412+100n
2413+100n
Md.28
Axis feedrate
814+100n
815+100n
2414+100n
2415+100n
Md.29
Speed-position switching control positioning amount
816+100n 2416+100n
Md.30 External input signal
817+100n 2417+100n
Md.31
Status
818+100n
819+100n
2418+100n
2419+100n
Md.32 Target value
820+100n
821+100n
2420+100n
2421+100n
Md.33
Target speed
824+100n
825+100n
2424+100n
2425+100n
Md.34
Movement amount after near-point dog ON
826+100n 2426+100n
Md.35
Torque limit stored value/forward torque limit stored
value
827+100n 2427+100n
Md.36
Special start data instruction code setting value
828+100n 2428+100n
Md.37
Special start data instruction parameter setting
value
829+100n 2429+100n
Md.38
Start positioning data No. setting value.
830+100n 2430+100n
Md.39
In speed limit flag
831+100n 2431+100n
Md.40
In speed change processing flag
832+100n 2432+100n
Md.41
Special start repetition counter
833+100n 2433+100n
Md.42
Control system repetition counter
834+100n 2434+100n
Md.43
Start data pointer being executed
835+100n 2435+100n
Md.44
Positioning data No. being executed
836+100n 2436+100n
Md.45
Block No. being executed
837+100n 2437+100n
Md.46
Last executed positioning data No.
Axis monitor data
Monitor data
n: Axis No.-1
: Compatible : Partly compatible : Not compatible
