Appendix - 32
Appendices
(a) MR-J3BUSM
1) Model explanation
Type: MR-J3BUS M -
015
Cable length [m(ft.)]
05
1
0.15(0.49)
0.3(0.98)
0.5(1.64)
03
1(3.28)
None
A
Symbol
B
Cable type
Standard cord for inside panel
Standard cable for outside panel
Long distance cable
3 3(9.84)
5
10
5(16.40)
10(32.81)
20 20(65.62)
30
40
30(98.43)
40(131.23)
50 50(164.04)
Symbol
2) Exterior dimensions
• MR-J3BUS015M
[Unit : mm(inch)]
2.3(0.09)
1.7(0.07)
37.65
(1.48)
150
+50
- 0
(5.91)
8
+0
(0.31)
20.9(0.82)
13.4
(0.53)
6.7(0.26)
15
(0.59)
Protective tube
• MR-J3BUS03M to MR-J3BUS3M
Refer to the table of this section (1) for cable length (L).
[Unit : mm(inch)]
L
(Note)
100
(3.94)
100
(3.94)
Protective tube
(Note): Dimension of connector part is the same as that of MR-J3BUS015M.
