Appendix - 33
Appendices
• MR-J3BUS5M-A to MR-J3BUS20M-A
• MR-J3BUS30M-B to MR-J3BUS50M-B
Refer to the table of this section (1) for cable length (L).
Variation [mm(inch)]
SSCNET Cable
A B
MR-J3BUS5M-A to MR-J3BUS20M-A 100(3.94) 30(1.18)
MR-J3BUS30M-B to MR-J3BUS50M-B 150(5.91) 50(1.97)
[Unit : mm(inch)]
(A)
(A)
L
(B)(B)
(Note)
Protective tube
(Note): Dimension of connector part is the same as that of MR-J3BUS015M.
POINT
Keep the cap and the tube for protecting light cord end of SSCNET cable in a
plastic bag with a zipper of SSCNET
cable to prevent them from becoming dirty.
(b) SSCNET
cable connector
[Unit : mm(inch)]
20.9 0.2
(0.82 0.01)
17.6 0.2
(0.69 0.01)
8
(0.31)
2.3
(0.09)
1.7
(0.07)
4.8(0.19)
13.4
(0.53)
15
(0.59)
6.7
(0.26)
9.3(0.37)
To Next Page
