MLC LC100 - Page 120

120
LC100 Instruction manual
T-11
Factory setting
A – Close button priority off
B – Automatic reset EN81 error and give output FO-79 - after service travel
C – Deactivating phase control from LC100- plate
D – Weight scale deactivating
E –
F –
G – Enable recall drive until arrival reference switch.
H – Enable releveling when elevator is overloaded.
T-12
Output tables bin/gray codes
Output table selection for the display;
Bin=0 – first station start with binary 0001
Bin=1 – first station start with binary 0000
Gry=1 – standardy gray code output
Gry=2 – shifted gray code output (Turkey market)
T-13
Simulator enable
0/1
Enable possibility to show simulator mode in LC100 menu.
T-14
Control times valve down A3
0-2,50 s
P
T-15
Delay on order direction ALGI
0-2,50 s
Start delay in up direction for hydraulic elevator VVVF – typ C.
f
