Motorola APX 7000 Detailed Service Manual

8-174 Schematics, Boards Overlays, and Parts Lists: Transceiver (RF) Boards: UHF1/UHF2
MNUE7367A UHF1/UHF2 Transceiver (RF)
Board Parts List
Ref. Des. Part Number Description
C101 2113944A46 CAP CER CHP 330.0 PF 50V 5%
C200 2113945B02 CAP CER CHP 10,000PF 25V
10%
C201 2188468Y01 CAP CER 25V X7R 0805 1UF
C202 2188468Y01 CAP CER 25V X7R 0805 1UF
C203 2188468Y01 CAP CER 25V X7R 0805 1UF
C204 2113955D35 CAP,FXD,4.7UF,+10%,-10%, 16V-
DC,1206,X7R,-55DEG CMIN,
125DEG CMAX
C205 2113955D35 CAP,FXD,4.7UF,+10%,-10%, 16V-
DC,1206,X7R,-55DEG CMIN,
125DEG CMAX
C206 2113945B02 CAP CER CHP 10,000PF 25V
10%
C207 2113956B91 CAP,FXD,1UF,+10%,-10%,16V-
DC,0603,X5R,-55DEG CMIN,
85DEG CMAX,PB
C208 2113956B91 CAP,FXD,1UF,+10%,-10%,16V-
DC,0603,X5R,-55DEG CMIN,
85DEG CMAX,PB
C209 2113956B91 CAP,FXD,1UF,+10%,-10%,16V-
DC,0603,X5R,-55DEG CMIN,
85DEG CMAX,PB
C210 2113956B91 CAP,FXD,1UF,+10%,-10%,16V-
DC,0603,X5R,-55DEG CMIN,
85DEG CMAX,PB
C212 2113946D07 CAP,CHIP,4.7UF,+10%,-10%,
6.3V-DC,0603,X5R,-55DEG
CMIN,85DEG CMA
C213 2113944A46 CAP CER CHP 330.0 PF 50V 5%
C214 2113944A31 CAP CER CHP 33.0PF 50V 5%
C215 2113944A46 CAP CER CHP 330.0 PF 50V 5%
C216 2113944A31 CAP CER CHP 33.0PF 50V 5%
C217 2113956B91 CAP,FXD,1UF,+10%,-10%,16V-
DC,0603,X5R,-55DEG CMIN,
85DEG CMAX,PB
C501 2115153H43 CAP, CERAMIC, COG
C502 2115153H28 CAP, CERAMIC, COG
C503 2115153H40 CAP, CERAMIC, COG
C504 2113944A40 CAP CER CHP 100.0PF 50V 5%
C505 2113946B04 CAP CER CHP 0.10UF 10V 10%
C506 2113946B04 CAP CER CHP 0.10UF 10V 10%
C507 2115153H43 CAP, CERAMIC, COG
C508 2113945A09 CAP CER CHP 1000PF 50V 10%
C509 2113945A09 CAP CER CHP 1000PF 50V 10%
C510 2113944A52 CAP CER CHP 1000.0 PF 50V 5%
C511 2113944A40 CAP CER CHP 100.0PF 50V 5%
C512 2113944A31 CAP CER CHP 33.0PF 50V 5%
C513 2113944A40 CAP CER CHP 100.0PF 50V 5%
C514 2113944A52 CAP CER CHP 1000.0 PF 50V 5%
C515 2113944A21 CAP CER CHP 6.8PF 50V
+/- 0.5PF
C516 2113944A11 CAP CER CHP 2.7PF 50V
+/- 0.25PF
C517 2113946B04 CAP CER CHP 0.10UF 10V 10%
C518 2113945A09 CAP CER CHP 1000PF 50V 10%
C519 2113944A28 CAP CER CHP 18.0PF 50V 5%
C520 2113945A09 CAP CER CHP 1000PF 50V 10%
C521 2113945A09 CAP CER CHP 1000PF 50V 10%
C522 2113944A27 CAP CER CHP 15.0PF 50V 5%
C523 2113944A48 CAP CER CHP 470.0 PF 50V 5%
C524 2113944A30 CAP CER CHP 27.0PF 50V 5%
C525 2115153H34 CAP, CERAMIC, COG
C527 2115153H10 CAP, CERAMIC, COG
C528 2113944A40 CAP CER CHP 100.0PF 50V 5%
C529 2113944A40 CAP CER CHP 100.0PF 50V 5%
C530 2113944A84 CAP,FXD,43PF,+5%,-5%,50V-DC,
0402,C0G,-55DEG CMIN,
125DEG CMAX,PB
C531 2115153H03 CAP, CERAMIC, COG
C601 2113945B02 CAP CER CHP 10,000PF 25V
10%
C602 2113945B02 CAP CER CHP 10,000PF 25V
10%
C603 2113945B02 CAP CER CHP 10,000PF 25V
10%
C604 2113945B02 CAP CER CHP 10,000PF 25V
10%
C605 2113944A15 CAP CER CHP 3.9PF 50V
+/- 0.25PF
C606 2113946B04 CAP CER CHP 0.10UF 10V 10%
C607 2113944A40 CAP CER CHP 100.0PF 50V 5%
C608 2113944A12 CAP CER CHP 3.0PF 50V
+/- 0.25PF
Ref. Des. Part Number Description
C609 2113944A30 CAP CER CHP 27.0PF 50V 5%
C610 2113944A40 CAP CER CHP 100.0PF 50V 5%
C611 2113944A40 CAP CER CHP 100.0PF 50V 5%
C612 2113945B02 CAP CER CHP 10,000PF 25V
10%
C613 2113944A40 CAP CER CHP 100.0PF 50V 5%
C614 2113945B02 CAP CER CHP 10,000PF 25V
10%
C615 2113944A42 CAP CER CHP 150.0PF 50V 5%
C616 2113945A11 CAP CER CHP 2200PF 50V 10%
C617 2113946B04 CAP CER CHP 0.10UF 10V 10%
C618 2113944A31 CAP CER CHP 33.0PF 50V 5%
C619 2113944A35 CAP CER CHP 62.0PF 50V 5%
C620 2113946B04 CAP CER CHP 0.10UF 10V 10%
C621 2113946B04 CAP CER CHP 0.10UF 10V 10%
C622 2113946C07 CAP,FXD,.33UF,+10%,-10%, 10V-
DC,0603,X5R,-55DEG CMIN,
85DEG CMAX
C623 2113945B02 CAP CER CHP 10,000PF 25V
10%
C624 2113946C07 CAP,FXD,.33UF,+10%,-10%, 10V-
DC,0603,X5R,-55DEG CMIN,
85DEG CMAX
C625 2113944A28 CAP CER CHP 18.0PF 50V 5%
C626 2113945A09 CAP CER CHP 1000PF 50V 10%
C627 2113945A09 CAP CER CHP 1000PF 50V 10%
C628 2113945B02 CAP CER CHP 10,000PF 25V
10%
C629 2113946B04 CAP CER CHP 0.10UF 10V 10%
C630 2113946B04 CAP CER CHP 0.10UF 10V 10%
C631 2113944A27 CAP CER CHP 15.0PF 50V 5%
C632 2113944A40 CAP CER CHP 100.0PF 50V 5%
C633 2113945B02 CAP CER CHP 10,000PF 25V
10%
C634 2113946B04 CAP CER CHP 0.10UF 10V 10%
C635 2113945B02 CAP CER CHP 10,000PF 25V
10%
C636 2113946B04 CAP CER CHP 0.10UF 10V 10%
C637 2113946B04 CAP CER CHP 0.10UF 10V 10%
C638 2113945A12 CAP CER CHP 3300PF 50V 10%
C639 2113945B02 CAP CER CHP 10,000PF 25V
10%
Ref. Des. Part Number Description
C640 2113946B04 CAP CER CHP 0.10UF 10V 10%
C641 2113944A31 CAP CER CHP 33.0PF 50V 5%
C642 2113944A48 CAP CER CHP 470.0 PF 50V 5%
C643 2113944A48 CAP CER CHP 470.0 PF 50V 5%
C701 2113944A44 CAP CER CHP 220.0 PF 50V 5%
C702 2113944A44 CAP CER CHP 220.0 PF 50V 5%
C704 2113944A35 CAP CER CHP 62.0PF 50V 5%
C705 2113944A44 CAP CER CHP 220.0 PF 50V 5%
C709 2113944A44 CAP CER CHP 220.0 PF 50V 5%
C710 2113944A49 CAP CER CHP 560.0 PF 50V 5%
C711 2113944A34 CAP CER CHP 56.0PF 50V 5%
C712 NOT PLACED –
C715 2113945C31 CAP,FXD,.1UF,+10%,-10%,50V-
DC,0603,X7R,-55DEG CMIN,
125DEG CMAX
C716 2113945C31 CAP,FXD,.1UF,+10%,-10%,50V-
DC,0603,X7R,-55DEG CMIN,
125DEG CMAX
C717 2113945C31 CAP,FXD,.1UF,+10%,-10%,50V-
DC,0603,X7R,-55DEG CMIN,
125DEG CMAX
C718 2113945C31 CAP,FXD,.1UF,+10%,-10%,50V-
DC,0603,X7R,-55DEG CMIN,
125DEG CMAX
C719 2113945C31 CAP,FXD,.1UF,+10%,-10%,50V-
DC,0603,X7R,-55DEG CMIN,
125DEG CMAX
C724 2113955D37 CAP,FXD,10UF,+10%,-10%,16V-
DC,1206,X7R,-55DEG CMIN,
125DEG CMAX
C725 2113945C31 CAP,FXD,.1UF,+10%,-10%,50V-
DC,0603,X7R,-55DEG CMIN,
125DEG CMAX
C726 2113945C31 CAP,FXD,.1UF,+10%,-10%,50V-
DC,0603,X7R,-55DEG CMIN,
125DEG CMAX
C730 2113945C31 CAP,FXD,.1UF,+10%,-10%,50V-
DC,0603,X7R,-55DEG CMIN,
125DEG CMAX
C731 2113945C31 CAP,FXD,.1UF,+10%,-10%,50V-
DC,0603,X7R,-55DEG CMIN,
125DEG CMAX
C732 2113944A32 CAP CER CHP 39.0PF 50V 5%
C734 2113945C31 CAP,FXD,.1UF,+10%,-10%,50V-
DC,0603,X7R,-55DEG CMIN,
125DEG CMAX
Ref. Des. Part Number Description
