Motorola APX 7000 Detailed Service Manual

Schematics, Boards Overlays, and Parts Lists: Transceiver (RF) Boards: UHF1/UHF2 8-175
C736 2113945B02 CAP CER CHP 10,000PF 25V
10%
C737 2113945C31 CAP,FXD,.1UF,+10%,-10%,50V-
DC,0603,X7R,-55DEG CMIN,
125DEG CMAX
C739 2113944A17 CAP CER CHP 4.7PF 50V +/-
0.25PF
C742 2113945C31 CAP,FXD,.1UF,+10%,-10%,50V-
DC,0603,X7R,-55DEG CMIN,
125DEG CMAX
C744 2113955D37 CAP,FXD,10UF,+10%,-10%,16V-
DC,1206,X7R,-55DEG CMIN,
125DEG CMAX
C747 2113944A44 CAP CER CHP 220.0 PF 50V 5%
C748 2113944A44 CAP CER CHP 220.0 PF 50V 5%
C749 2113945C31 CAP,FXD,.1UF,+10%,-10%,50V-
DC,0603,X7R,-55DEG CMIN,
125DEG CMAX
C750 2113945C31 CAP,FXD,.1UF,+10%,-10%,50V-
DC,0603,X7R,-55DEG CMIN,
125DEG CMAX
C752 2113944A43 CAP CER CHP 180.0PF 50V 5%
C754 NOT PLACED –
C756 2113955D37 CAP,FXD,10UF,+10%,-10%,16V-
DC,1206,X7R,-55DEG CMIN,
125DEG CMAX
C757 2113945C31 CAP,FXD,.1UF,+10%,-10%,50V-
DC,0603,X7R,-55DEG CMIN,
125DEG CMAX
C758 2113946B02 CAP CER CHP 0.047UF 10V 10,
C759 2113945G95 CAP,FXD,.22UF,+10%,-10%, 50V-
DC,0805,X7R,-55DEG CMIN,
125DEG CMAX
C760 2113944G97 CAP,FXD,.082UF,+5%,-5%,50V-
DC,1206,C0G,-55DEG CMIN,
125DEG CMAX
C762 2113945C26 CAP,FXD,.039UF,+10%,-10%,
50V-DC,0603,X7R,-55DEG CMIN,
125DEG CMA
C763 2113944G97 CAP,FXD,.082UF,+5%,-5%,50V-
DC,1206,C0G,-55DEG CMIN,
125DEG CMAX
C765 2113944G97 CAP,FXD,.082UF,+5%,-5%,50V-
DC,1206,C0G,-55DEG CMIN,
125DEG CMAX
C766 2113945C01 CAP CER CHP 6800PF 50V 10%
Ref. Des. Part Number Description
C768 2113944G97 CAP,FXD,.082UF,+5%,-5%,50V-
DC,1206,C0G,-55DEG CMIN,
125DEG CMAX
C769 2113945C20 CAP,FXD,.016UF,+10%,-10%,
50V-DC,0603,X7R,-55DEG CMIN,
125DEG CMA
C770 2113944G97 CAP,FXD,.082UF,+5%,-5%,50V-
DC,1206,C0G,-55DEG CMIN,
125DEG CMAX
C771 2113944A40 CAP CER CHP 100.0PF 50V 5%
C775 2113945A09 CAP CER CHP 1000PF 50V 10%
C777 2113944A31 CAP CER CHP 33.0PF 50V 5%
C779 2113944A40 CAP CER CHP 100.0PF 50V 5%
C783 2113944C53 CAP CER CHP 1500.OPF 50V 5
C789 2113946B04 CAP CER CHP 0.10UF 10V 10%
C790 2113946B04 CAP CER CHP 0.10UF 10V 10%
C791 2113946B04 CAP CER CHP 0.10UF 10V 10%
C792 2113946B04 CAP CER CHP 0.10UF 10V 10%
C793 2113944A40 CAP CER CHP 100.0PF 50V 5%
C794 NOT PLACED –
C795 NOT PLACED –
C796 2113944A40 CAP CER CHP 100.0PF 50V 5%
C797 2113944A40 CAP CER CHP 100.0PF 50V 5%
C798 NOT PLACED –
C799 NOT PLACED –
C800 NOT PLACED –
C801 NOT PLACED –
C802 2113946B06 CAP,CHIP,.22UF,+10%,-10%,10V-
DC,0402,X5R,-55DEG CMIN,
85DEG CMAX
C803 NOT PLACED –
C804 2113944A40 CAP CER CHP 100.0PF 50V 5%
C805 NOT PLACED –
C806 2113946B06 CAP,CHIP,.22UF,+10%,-10%, 10V-
DC,0402,X5R,-55DEG CMIN,
85DEG CMAX
C810 2113944A44 CAP CER CHP 220.0 PF 50V 5%
C813 2113944A63 CAP,FXD,1PF,.25PF+/-,50V-DC,
0402,C0G,-55DEG CMIN,
125DEG CMAX,P
C814 2113945A09 CAP CER CHP 1000PF 50V 10%
C816 2113944A31 CAP CER CHP 33.0PF 50V 5%
Ref. Des. Part Number Description
C820 2113944A44 CAP CER CHP 220.0 PF 50V 5%
C830 2113944A44 CAP CER CHP 220.0 PF 50V 5%
C831 2113944A40 CAP CER CHP 100.0PF 50V 5%
C836 2113944A33 CAP CER CHP 47.0PF 50V 5%
C838 2113945A09 CAP CER CHP 1000PF 50V 10%
C844 2113944A33 CAP CER CHP 47.0PF 50V 5%
C851 2113944A44 CAP CER CHP 220.0 PF 50V 5%
C1101 2113945B02 CAP CER CHP 10,000PF 25V
10%
C1102 2188468Y01 CAP CER 25V X7R 0805 1UF
C1103 2113945B02 CAP CER CHP 10,000PF 25V
10%
C1104 NOT PLACED –
C1105 2113944A19 CAP CER CHP 5.6PF 50V
+/- 0.5PF
C1106 2113945B02 CAP CER CHP 10,000PF 25V
10%
C1107 2113944A40 CAP CER CHP 100.0PF 50V 5%
C1108 2113946B03 CAP CER CHP 0.068UF 10V 10
C1109 2113944A40 CAP CER CHP 100.0PF 50V 5%
C1110 2113944A40 CAP CER CHP 100.0PF 50V 5%
C1111 2113945Y02 CAP,FXD,.1UF,+10%,-10%,16V-
DC,0402,X7R,-55DEG CMIN,
125DEG CMAX
C1112 2113945B01 CAP CER CHP 6800PF 25V 10%
C1113 2113945B02 CAP CER CHP 10,000PF 25V
10%
C1116 2113945Y02 CAP,FXD,.1UF,+10%,-10%,16V-
DC,0402,X7R,-55DEG CMIN,
125DEG CMAX
C1117 2113945A12 CAP CER CHP 3300PF 50V 10%
C1118 2113945B02 CAP CER CHP 10,000PF 25V
10%
C1119 2113945B02 CAP CER CHP 10,000PF 25V
10%
C1120 2113945B02 CAP CER CHP 10,000PF 25V
10%
C1122 2175390H01 CAP, 2.2 PF, 0402, CERAMIC,
50V
C1123 2113945B02 CAP CER CHP 10,000PF 25V
10%
C1124 2113945A13 CAP CER CHP 4700PF 50V 10%
Ref. Des. Part Number Description
C1125 2113944A19 CAP CER CHP 5.6PF 50V
+/- 0.5PF
C1126 2113945A09 CAP CER CHP 1000PF 50V 10%
C1127 2113945Y02 CAP,FXD,.1UF,+10%,-10%,16V-
DC,0402,X7R,-55DEG CMIN,
125DEG CMAX
C1128 2113945B02 CAP CER CHP 10,000PF 25V
10%
C1129 2113945B02 CAP CER CHP 10,000PF 25V
10%
C1130 2113945B02 CAP CER CHP 10,000PF 25V
10%
C1132 NOT PLACED –
C1134 2113945B02 CAP CER CHP 10,000PF 25V
10%
C1135 NOT PLACED –
C1137 2113945B04 CAP,FXD,.022UF,+10%,-10%,
25V-DC,0402,X7R,-55DEG
CMIN,125DEG CMA
C1138 2113945B04 CAP,FXD,.022UF,+10%,-10%,
25V-DC,0402,X7R,-55DEG
CMIN,125DEG CMA
C1139 2113944A25 CAP CER CHP 10.0PF 50V +/-
0.5PF
C1140 2113945A13 CAP CER CHP 4700PF 50V 10%
C1141 2113945Y02 CAP,FXD,.1UF,+10%,-10%,16V-
DC,0402,X7R,-55DEG CMIN,
125DEG CMAX
C1142 2113945A09 CAP CER CHP 1000PF 50V 10%
C1149 2113944A40 CAP CER CHP 100.0PF 50V 5%
C1150 2175392H01 CAP, 1.2PF, 0402, CERAMIC, 50V
C1301 2113944M20 CAP,FXD,12PF,+2%,-2%,50V-
DC,0603,C0G,-55DEG CMIN,
125DEG CMAX,PB
C1302 2188881Y12 CAPACITOR CERAMIC NPO
HIGH FREQUENCY 16 VOLT
(REPLACES 2104801Z12)
C1303 2113944A26 CAP CER CHP 12.0PF 50V 5%
C1304 2113945A09 CAP CER CHP 1000PF 50V 10%
C1305 2113944A30 CAP CER CHP 27.0PF 50V 5%
C1306 2113945B02 CAP CER CHP 10,000PF 25V
10%
C1307 2113944A26 CAP CER CHP 12.0PF 50V 5%
C1308 2113944A28 CAP CER CHP 18.0PF 50V 5%
Ref. Des. Part Number Description

Motorola APX 7000 Specifications

General

Digital Technology	P25 Phase 1 and Phase 2
Emergency Button	Yes
Frequency Range	136-174 MHz (VHF), 380-470 MHz (UHF Range 1), 450-520 MHz (UHF Range 2), 764-870 MHz (700/800 MHz)
Display	Color LCD
Encryption	AES, DES
Water Resistance	IP67
GPS	Yes
Bluetooth	Yes
Operating Temperature	-30°C to +60°C
Weight	391 g (with standard battery)
