Motorola APX 7000 Detailed Service Manual

8-176 Schematics, Boards Overlays, and Parts Lists: Transceiver (RF) Boards: UHF1/UHF2
C1309 2175389H01 CAP,.5PF, CHIP, 0402, CERAMIC,
50 V
C1310 2113944A17 CAP CER CHP 4.7PF 50V +/-
0.25PF
C1500 2113944C45 CAP CER CHP 100.0PF 50V 5%
C1501 2113945C02 CAP CER CHP 10,000PF 50V
10%
C1502 2113944C45 CAP CER CHP 100.0PF 50V 5%
C1503 2113944C45 CAP CER CHP 100.0PF 50V 5%
C1504 2113945C02 CAP CER CHP 10,000PF 50V
10%
C1505 2113944C45 CAP CER CHP 100.0PF 50V 5%
C1506 2113944A40 CAP CER CHP 100.0PF 50V 5%
C1507 2113944A40 CAP CER CHP 100.0PF 50V 5%
C1508 2113944C12 CAP CER CHP 1.8PF 50V +/-
0.25PF
C1509 2113944C41 CAP CER CHP 68.0PF 50V 5%
C1510 2113944M26 CAP,FXD,22PF,+2%,-2%,50V-DC,
0603,C0G,-55DEG CMIN,
125DEG CMAX,PB
C1511 2113944M30 CAP,FXD,33PF,+2%,-2%,50V-DC,
0603,C0G,-55DEG CMIN,
125DEG CMAX,PB
C1512 NOT PLACED –
C1513 2113944C45 CAP CER CHP 100.0PF 50V 5%
C1514 2113945C02 CAP CER CHP 10,000PF 50V
10%
C1515 NOT PLACED –
C1516 21007088001 0805 CAPACITOR
C1517 2171741M08 HIGH Q CAP, 22 PF
C1518 21007088007 0805 CAPACITOR
C1519 NOT PLACED –
C1520 21007088005 0805 CAPACITOR
C1521 2113944C45 CAP CER CHP 100.0PF 50V 5%
C1522 2113944A40 CAP CER CHP 100.0PF 50V 5%
C1523 NOT PLACED –
C1525 NOT PLACED –
C1526 2113945Y02 CAP,FXD,.1UF,+10%,-10%,16V-
DC,0402,X7R,-55DEG CMIN,
125DEG CMAX
C1527 21007088006 0805 CAPACITOR
C1598 2113945A12 CAP CER CHP 3300PF 50V 10%
Ref. Des. Part Number Description
C1599 2113945A12 CAP CER CHP 3300PF 50V 10%
C1601 2113944M42 CAP,FXD,100PF,+2%,-2%,50V-
DC,0603,C0G,-55DEG CMIN,
125DEG CMAX,P
C1602 2113944M42 CAP,FXD,100PF,+2%,-2%,50V-
DC,0603,C0G,-55DEG CMIN,
125DEG CMAX,P
C1603 2113945L49 CAP,FXD,.01UF,+5%,-5%,50V-
DC,0603,X7R,-55DEG CMIN,
125DEG CMAX,P
C1604 2113944M42 CAP,FXD,100PF,+2%,-2%,50V-
DC,0603,C0G,-55DEG CMIN,
125DEG CMAX,P
C1605 2113945B02 CAP CER CHP 10,000PF 25V
10%
C1606 2113944A40 CAP CER CHP 100.0PF 50V 5%
C1607 2113944M42 CAP,FXD,100PF,+2%,-2%,50V-
DC,0603,C0G,-55DEG CMIN,
125DEG CMAX,P
C1608 2113944M42 CAP,FXD,100PF,+2%,-2%,50V-
DC,0603,C0G,-55DEG CMIN,
125DEG CMAX,P
C1609 2113944A40 CAP CER CHP 100.0PF 50V 5%
C1610 2113944M14 CAP,FXD,6.8PF,.1PF+/-,50V-DC,
0603,C0G,-55DEG CMIN,
125DEG CMAX
C1611 2113945L49 CAP,FXD,.01UF,+5%,-5%,50V-
DC,0603,X7R,-55DEG CMIN,
125DEG CMAX,P
C1612 NOT PLACED –
C1613 2113944M30 CAP,FXD,33PF,+2%,-2%,50V-DC,
,C0G,-55DEG CMIN, 125DEG
CMAX,PB
C1614 2113944M36 CAP,FXD,56PF,+2%,-2%,50V-DC,
0603,C0G,-55DEG CMIN,
125DEG CMAX,PB
C1615 2113944A40 CAP CER CHP 100.0PF 50V 5%
C1616 2113944M34 CAP,FXD,47PF,+2%,-2%,50V-DC,
0603,C0G,-55DEG CMIN,
125DEG CMAX,PB
C1617 2113945B02 CAP CER CHP 10,000PF 25V
10%
C1618 2113944M42 CAP,FXD,100PF,+2%,-2%,50V-
DC,0603,C0G,-55DEG CMIN,
125DEG CMAX,P
C1619 NOT PLACED –
C1620 2171741M01 HIGH Q CAP
Ref. Des. Part Number Description
C1621 2171741M08 HIGH Q CAP, 22 PF
C1622 2113944M23 CAP,FXD,16PF,+2%,-2%,50V-DC,
0603,C0G,-55DEG CMIN,
125DEG CMAX,PB
C1623 2113944C08 CAP CER CHP 1.2PF 50V
+/- 0.25PF
C1624 2113944M22 CAP,FXD,15PF,+2%,-2%,50V-DC,
0603,C0G,-55DEG CMIN,
125DEG CMAX,PB
C1625 2113944M42 CAP,FXD,100PF,+2%,-2%,50V-
DC, ,C0G,-55DEG CMIN, 125DEG
CMAX,P
C1628 2113944M08 CAP,FXD,3.9PF,.1PF+/-,50V-DC,
0603,C0G,-55DEG CMIN,
125DEG CMAX
C1629 2113945A12 CAP CER CHP 3300PF 50V 10%
C1630 2113945A12 CAP CER CHP 3300PF 50V 10%
C1700 2113944M06 CAP,FXD,3.3PF,.1PF+/-,50V-DC,
0603,C0G,-55DEG CMIN,
125DEG CMAX
C1701 2113944M14 CAP,FXD,6.8PF,.1PF+/-,50V-DC,
0603,C0G,-55DEG CMIN,
125DEG CMAX
C1702 2113944M15 CAP,FXD,7.5PF,.1PF+/-,50V-DC,
0603,C0G,-55DEG CMIN,
125DEG CMAX
C1703 2113944M06 CAP,FXD,3.3PF,.1PF+/-,50V-DC,
0603,C0G,-55DEG CMIN,
125DEG CMAX
C1704 2113944M02 CAP,FXD,2.2PF,.1PF+/-,50V-DC,
0603,C0G,-55DEG CMIN,
125DEG CMAX
C1705 2113944C67 CAP,FXD,1.5PF,.1PF+/-,50V-DC,
0603,C0G,-55DEG CMIN,
125DEG CMAX
C1706 NOT PLACED –
C1707 2113944C45 CAP CER CHP 100.0PF 50V 5%
C1803 2113944M08 CAP,FXD,3.9PF,.1PF+/-,50V-DC
,0603,C0G,-55DEG CMIN,
125DEG CMAX
C1804 2113944M08 CAP,FXD,3.9PF,.1PF+/-,50V-DC,
0603,C0G,-55DEG CMIN,
125DEG CMAX
C1807 2113944M14 CAP,FXD,6.8PF,.1PF+/-,50V-DC,
0603,C0G,-55DEG CMIN,
125DEG CMAX
Ref. Des. Part Number Description
C1820 2113944M08 CAP,FXD,3.9PF,.1PF+/-,50V-DC,
0603,C0G,-55DEG CMIN,
125DEG CMAX
C1821 2113944M17 CAP,FXD,9.1PF,.1PF+/-,50V-DC,
0603,C0G,-55DEG CMIN,
125DEG CMAX
C1822 2113944M42 CAP,FXD,100PF,+2%,-2%,50V-
DC,0603,C0G,-55DEG CMIN,
125DEG CMAX,P
C1826 2113944M04 CAP,FXD,2.7PF,.1PF+/-,50V-DC,
0603,C0G,-55DEG CMIN,
125DEG CMAX
C1827 2113944M10 CAP,FXD,4.7PF,.1PF+/-,50V-DC,
0603,C0G,-55DEG CMIN,
125DEG CMAX
C1920 2113946D07 CAP,CHIP,4.7UF,+10%,-10%,
6.3V-DC,0603,X5R,-55DEG
CMIN,85DEG CMA
C1922 2113944A40 CAP CER CHP 100.0PF 50V 5%
C1923 2113944A40 CAP CER CHP 100.0PF 50V 5%
C1924 2113946D07 CAP,CHIP,4.7UF,+10%,-10%,
6.3V-DC,0603,X5R,-55DEG
CMIN,85DEG CMA
C1925 2113944A40 CAP CER CHP 100.0PF 50V 5%
C1926 2113946B04 CAP CER CHP 0.10UF 10V 10%
C1928 2115153H28 CAP, CERAMIC, COG
C1929 2115153H30 CAP, CERAMIC, COG
C1931 2171051Y05 CAP,CER CHIP,180PF,+1%,-1%,
50V-DC,0402,-55DEG CMIN,
125DEG CM
C1935 2115153H12 CAP, CERAMIC, COG
C1936 2115153H31 CAP, CERAMIC, COG
C1938 2115153H07 CAP, CERAMIC, COG
C1939 2115153H12 CAP, CERAMIC, COG
C1940 2113944A40 CAP CER CHP 100.0PF 50V 5%
C1941 2113946B04 CAP CER CHP 0.10UF 10V 10%
C1942 2115153H38 CAP, CERAMIC, COG
C1952 2115153H30 CAP, CERAMIC, COG
C1953 2115153H28 CAP, CERAMIC, COG
C1954 2113944A40 CAP CER CHP 100.0PF 50V 5%
C1955 2113946B04 CAP CER CHP 0.10UF 10V 10%
C1956 2115153H28 CAP, CERAMIC, COG
C1957 2115153H21 CAP, CERAMIC, COG
C1958 2115153H38 CAP, CERAMIC, COG
Ref. Des. Part Number Description
