Motorola APX 7000 Detailed Service Manual

Schematics, Boards Overlays, and Parts Lists: Transceiver (RF) Boards: UHF1/UHF2 8-177
C1959 2115153H12 CAP, CERAMIC, COG
C1960 2115153H07 CAP, CERAMIC, COG
C1961 2115153H12 CAP, CERAMIC, COG
C1963 2115153H21 CAP, CERAMIC, COG
C1964 2115153H28 CAP, CERAMIC, COG
C2020 2113946D07 CAP,CHIP,4.7UF,+10%,-10%,
6.3V-DC,0603,X5R,-55DEG
CMIN,85DEG CMA
C2022 2113944A40 CAP CER CHP 100.0PF 50V 5%
C2023 2113944A40 CAP CER CHP 100.0PF 50V 5%
C2024 2113946D07 CAP,CHIP,4.7UF,+10%,-10%,
6.3V-DC,0603,X5R,-55DEG
CMIN,85DEG CMA
C2025 2113944A40 CAP CER CHP 100.0PF 50V 5%
C2026 2113946B04 CAP CER CHP 0.10UF 10V 10%
C2028 2115153H24 CAP, CERAMIC, COG
C2029 2115153H41 CAP,CERAMIC CHIP,22PF,+1%,
-1%,50V-
C2032 2115153H57 CAP, CERAMIC, COG
C2033 2115153H53 CAP, CERAMIC, COG
C2035 2115153H15 CAP, CERAMIC, COG
C2036 2115153H07 CAP, CERAMIC, COG
C2037 2115153H12 CAP, CERAMIC, COG
C2038 2115153H09 CAP, CERAMIC, COG
C2039 2115153H15 CAP, CERAMIC, COG
C2041 2113946B04 CAP CER CHP 0.10UF 10V 10%
C2042 2115153H13 CAP, CERAMIC, COG
C2044 2115153H26 CAP, CERAMIC, COG
C2052 2115153H41 CAP,CERAMIC CHIP,22PF,+1%,
-1%,50V-
C2053 2115153H24 CAP, CERAMIC, COG
C2054 2113944A40 CAP CER CHP 100.0PF 50V 5%
C2055 2113946B04 CAP CER CHP 0.10UF 10V 10%
C2056 2115153H24 CAP, CERAMIC, COG
C2057 2115153H41 CAP,CERAMIC CHIP,22PF,+1%,
-1%,50V-
C2058 2115153H13 CAP, CERAMIC, COG
C2059 2115153H15 CAP, CERAMIC, COG
C2060 2115153H11 CAP, CERAMIC, COG
C2061 2115153H15 CAP, CERAMIC, COG
Ref. Des. Part Number Description
C2063 2115153H41 CAP,CERAMIC CHIP,22PF,+1%,
- 1%,50V-
C2064 2115153H24 CAP, CERAMIC, COG
D200 4813978A19 DIODE,RECT,MBR120,SM,SOD-
123,1A,20V,SHTK,PB-FREE
D722 4815011H01 DIODE TRIPLE
D723 4815011H01 DIODE TRIPLE
E200 2405688Z01 INDUCTOR FERRITE BEAD
E201 2405688Z01 INDUCTOR FERRITE BEAD
E501 2480640Z01 SURFACE MOUNT FERRITE
BEAD
E601 2480640Z01 SURFACE MOUNT FERRITE
BEAD
E602 2480640Z01 SURFACE MOUNT FERRITE
BEAD
E603 2480640Z01 SURFACE MOUNT FERRITE
BEAD
E604 2480640Z01 SURFACE MOUNT FERRITE
BEAD
E605 2480640Z01 SURFACE MOUNT FERRITE
BEAD
E606 2480640Z01 SURFACE MOUNT FERRITE
BEAD
E607 2480640Z01 SURFACE MOUNT FERRITE
BEAD
E608 2480640Z01 SURFACE MOUNT FERRITE
BEAD
E609 2480640Z01 SURFACE MOUNT FERRITE
BEAD
E1101 2405688Z01 INDUCTOR FERRITE BEAD
E1921 2480640Z01 SURFACE MOUNT FERRITE
BEAD
E2021 2480640Z01 SURFACE MOUNT FERRITE
BEAD
F200 6575834B01 FUSE SURFACE MOUNT
FL1301 9189697V15 FLTR,1.57542GHZ NOM,
1.57642GHZ MIN,1.57442GHZ
MAX,50OHM,SM,P
FL501 4885631B01 XTAL FILT 3 POLE 109.65
MOTORO
J101 0909901V02 RECP SMT MCX
J102 0975886B01 RECEPTACLE, COAX CABLE
L200 2571269C01 INDUCTOR WW POWER 20%
L501 24012011014 0402 HIGH Q CHIP INDUCTOR
Ref. Des. Part Number Description
L502 2415429H30 CHIP INDUCTOR
L503 2414032F38 IDCTR,WW,220NH,5%,400MA,
.7OHM,CER,30 Q,630MHZ
SRF,SM,PB-FRE
L504 2414032F41 IDCTR,WW,390NH,10%,200MA,
1.5OHM,CER,40 Q,730MHZ SRF,
SM,PB-F
L505 2415429H39 CHIP INDUCTOR
L506 2415429H39 CHIP INDUCTOR
L507 2415427H36 CHIP INDUCTOR
L508 2478390A22 0402 CHIP INDUCTOR
L509 2478390A11 0402 CHIP INDUCTOR
L510 24012011020 0402 HIGH Q CHIP INDUCTOR
L511 2478057A13 7.5 NH SURFACE MOUNT
INDUCTOR
L512 2478057A14 8.2NH SURFACE MOUNT
INDUCTOR
L601 2415429H43 CHIP INDUCTOR
L602 2466505A01 COIL INDUCTOR
L603 2466505A01 COIL INDUCTOR
L604 2414032D16 IDCTR,WW,120NH,5%,800MA,
.26OHM,CER,42 Q,1GHZ SRF,
SM,PB-FREE
L605 2414017Q54 IDCTR,FXD,3.9UH,10%,30MA,
.9OHM,FERR,45 Q,38MHZ SRF,
SM,0805,P
L701 2415429H47 CHIP INDUCTOR
L720 2480646Z20 COIL MULTI-LAYER
CHIP(2.20UH)
L727 2480646Z20 COIL MULTI-LAYER
CHIP(2.20UH)
L728 2415429H47 CHIP INDUCTOR
L733 2480646Z20 COIL MULTI-LAYER
CHIP(2.20UH)
L735 2480646Z20 COIL MULTI-LAYER
CHIP(2.20UH)
L738 2480646Z20 COIL MULTI-LAYER
CHIP(2.20UH)
L741 2480646Z20 COIL MULTI-LAYER
CHIP(2.20UH)
L753 2415347H06 IDCTR, 2200NH
L802 NOT PLACED –
L806 2415429H47 CHIP INDUCTOR
Ref. Des. Part Number Description
L817 2414032F41 IDCTR,WW,390NH,10%,200MA,
1.5OHM,CER,40 Q,730MHZ SRF,
SM,PB-F
L821 2415429H47 CHIP INDUCTOR
L846 2414032F41 IDCTR,WW,390NH,10%,200MA,
1.5OHM,CER,40 Q,730MHZ SRF,
SM,PB-F
L1101 2415429H26 CHIP INDUCTOR
L1102 2415429H10 CHIP INDUCTOR
L1103 2475393H01 INDUCTOR, 4.7NH, 0402,
+/-0.1NH
L1104 0613952R66 CER CHIP RES 0.0 +/-0.050 OHM
L1108 2409348J04 IND AIR CORE 5.45NH 5% 2214
L1114 2475394H01 INDUCTOR, 11NH, 0402, +/-2%
L1301 2488090Y07 INDUCTOR,MULTILAYER,3.3NH,
1005,SMD,PB FREE
L1302 2488090Y25 INDUCTOR,MULTILAYER,100NH,
1005,SMD,PB FREE
L1303 2414017P25 IDCTR,CHIP,100NH,5%,100MA,
5.5OHM,CER,8 Q,650MHZ
SRF,SM,0402
L1305 2475391H01 INDUCTOR, 18 NH, CHIP, 0402,
2% TOL
L1306 2488090Y10 INDUCTOR,MULTILAYER,5.6NH,
1005,SMD,PB FREE
L1500 2414015A07 IDCTR,FXD,180NH,2%,750MA,
.77OHM,CER,25 Q,700MHZ SRF,
SM,1008
L1501 2415429H03 CHIP INDUCTOR
L1502 2415429H03 CHIP INDUCTOR
L1503 2415429H18 CHIP INDUCTOR
L1504 2415429H02 CHIP INDUCTOR
L1505 2460591E24 COIL AIR WOUND INDUC 23.75
L1507 2415385H01 8 NH MINISPRING AIR CORE
INDUCTOR
L1510 2415429H37 CHIP INDUCTOR
L1601 2414017H14 IDCTR,CHIP,15NH,5%,3A,
.32OHM,CER,12 Q,1.5GHZ SRF,
SM,0603,PB-
L1602 2415429H37 CHIP INDUCTOR
L1603 2414015A07 IDCTR,FXD,180NH,2%,750MA,
.77OHM,CER,25 Q,700MHZ SRF,
SM,1008
Ref. Des. Part Number Description

Motorola APX 7000 Specifications

General

Digital Technology	P25 Phase 1 and Phase 2
Emergency Button	Yes
Frequency Range	136-174 MHz (VHF), 380-470 MHz (UHF Range 1), 450-520 MHz (UHF Range 2), 764-870 MHz (700/800 MHz)
Display	Color LCD
Encryption	AES, DES
Water Resistance	IP67
GPS	Yes
Bluetooth	Yes
Operating Temperature	-30°C to +60°C
Weight	391 g (with standard battery)
