Motorola APX 7000 Detailed Service Manual

8-178 Schematics, Boards Overlays, and Parts Lists: Transceiver (RF) Boards: UHF1/UHF2
L1604 2414017H07 IDCTR,CHIP,3.9NH,300MA,
.14OHM,CER,10 Q,3.4GHZ SRF,
SM,0603,P
L1605 2414017H07 IDCTR,CHIP,3.9NH,300MA,
.14OHM,CER,10 Q,3.4GHZ SRF,
SM,0603,P
L1606 2460591E24 COIL AIR WOUND INDUC 23.75
L1609 2415428H02 AIR WOUND INDUCTOR
L1610 2415385H01 8 NH MINISPRING AIR CORE
INDUCTOR
L1700 2471902Y05 IDCTR,AW,12.1NH,5%,4.4A,
.007OHM,4.3GHZ SRF,SM,PB-
FREE
L1701 2471902Y05 IDCTR,AW,12.1NH,5%,4.4A,
.007OHM,4.3GHZ SRF,SM,PB-
FREE
L1702 2471902Y05 IDCTR,AW,12.1NH,5%,4.4A,
.007OHM,4.3GHZ SRF,SM,PB-
FREE
L1803 2471884M01 10.2NH SQUARE SPRING
L1809 2471884M01 10.2NH SQUARE SPRING
L1811 2471884M01 10.2NH SQUARE SPRING
L1908 2478057A06 4.3 NH SURFACE MOUNT
INDUCTOR
L1909 2478057A23 18 NH SURFACE MOUNT
INDUCTOR
L1910 2478057A23 18 NH SURFACE MOUNT
INDUCTOR
L1912 2478057A05 3.9 NH SURFACE MOUNT
INDUCTOR
L1913 2478057A23 18 NH SURFACE MOUNT
INDUCTOR
L1914 2478057A23 18 NH SURFACE MOUNT
INDUCTOR
L1915 2478057A35 0306 HIGH Q CHIP INDUCTOR
L1916 2414017P14 IDCTR,CHIP,12NH,5%,300MA,
.6OHM,CER,9 Q,2GHZ SRF,SM,
0402,PB-F
L1917 2478057A36 0306 HIGH Q CHIP INDUCTOR
L1919 2414017P14 IDCTR,CHIP,12NH,5%,300MA,
.6OHM,CER,9 Q,2GHZ SRF,SM,
0402,PB-F
L1934 2478057A38 0306 HIGH Q CHIP INDUCTOR
L1935 2478057A26 24 NH SURFACE MOUNT
INDUCTOR
L1936 2415429H01 CHIP INDUCTOR
Ref. Des. Part Number Description
L1938 NOT PLACED –
L2008 2478057A09 5.6 NH SURFACE MOUNT
INDUCTOR
L2009 2478057A23 18 NH SURFACE MOUNT
INDUCTOR
L2010 2478057A23 18 NH SURFACE MOUNT
INDUCTOR
L2012 2478057A09 5.6 NH SURFACE MOUNT
INDUCTOR
L2013 2478057A23 18 NH SURFACE MOUNT
INDUCTOR
L2014 2478057A23 18 NH SURFACE MOUNT
INDUCTOR
L2015 2478057A41 0306 HIGH Q CHIP INDUCTOR
L2016 2414017P15 IDCTR,CHIP,15NH,5%,300MA,
.65OHM,CER,9 Q,1.95GHZ
SRF,SM,0402
L2017 2478057A40 0306 HIGH Q CHIP INDUCTOR
L2019 2414017P15 IDCTR,CHIP,15NH,5%,300MA,
.65OHM,CER,9 Q,1.95GHZ
SRF,SM,0402
L2034 2478057A29 0306 HIGH Q CHIP INDUCTOR
L2035 2478057A24 22 NH SURFACE MOUNT
INDUCTOR
L2036 2415429H01 CHIP INDUCTOR
M1 3275623B02 PAD, THERMAL ELECTRIC
M2 75009299001 PAD, THERMAL
M3 1104959T01 COATING-CONTACT
M101 2871616H01 CONNECTOR, BPLUS
M103 3987977Y04 CONT,CONN,1CONT,ANT UNIV
4.5MM,UC 1.8
M104 NOT PLACED –
M105 3987977Y04 CONT,CONN,1CONT,ANT UNIV
4.5MM,UC 1.8
M106 NOT PLACED –
P101 2887818K05 PLUG 40PIN MATING CNTCR
1.5MM
PASTE 1085674C03 PASTE/NC-SMQ230
PCB 84012328001 DUAL BAND PORTABLE RADIO
Q201 4813970A59 P-CH FET 1.0A 20V SOT-23 T&R
Q202 4813973A32 XSTR,BIP GP SS,NPN,SM,SC-70,
SMT,50V,.202W,100MA,PB-FREE
Ref. Des. Part Number Description
Q501 4813973M75 XSTR,BIP GP SS,PNP,BC858,
SOT-563,SMT,-30V,.357W,
-100MA,100MHZ
Q503 4885316E32 TRANSISTOR, RF
Q601 4813973A04 XSTR,BIP GP SS,NPN,TA13, SM,
SOT-23,SMT,30V,.225W, 300MA,
125MHZ,P
Q703 4813973M75 XSTR,BIP GP SS,PNP,BC858,
SOT-563,SMT,-30V,.357W,
-100MA,100MHZ
Q712 4813973M75 XSTR,BIP GP SS,PNP,BC858,
SOT-563,SMT,-30V,.357W,
-100MA,100MHZ
Q713 4805585Q32 TRANSITOR, NPN RF
Q714 4889394V04 XSTR,FET GEN PURPOSE
SMALL SIG,MOSFET,N-CH,
ENHN,SM,20V,.25W,P
Q774 4885061Y01 XSTR NPN 6V 30UA 12GHZ PB-
FREE
Q842 4805585Q32 TRANSITOR, NPN RF
Q1101 4813973A32 XSTR,BIP GP SS,NPN,SM,SC-
70,SMT,50V,.202W,100MA,PB-
FREE
Q1102 4813973A32 XSTR,BIP GP SS,NPN,SM,SC-
70,SMT,50V,.202W,100MA,PB-
FREE
Q1103 4813970A59 P-CH FET 1.0A 20V SOT-23 T&R
Q1104 4813970A59 P-CH FET 1.0A 20V SOT-23 T&R
Q1105 NOT PLACED –
Q1500 5185633C92 MODULE,RING,XSTR, FET RF
POWER, UHF
Q1601 5185633C92 MODULE,RING,XSTR, FET RF
POWER, UHF
Q1920 4813973A32 XSTR,BIP GP SS,NPN,SM,SC-70,
SMT,50V,.202W,100MA,PB-FREE
Q1922 4813973M75 XSTR,BIP GP SS,PNP,BC858,
SOT-563,SMT,-30V,.357W,
-100MA,100MHZ
Q2020 4813973A32 XSTR,BIP GP SS,NPN,SM,SC-70,
SMT,50V,.202W,100MA,PB-FREE
Q2022 4813973M75 XSTR,BIP GP SS,PNP,BC858,
SOT-563,SMT,-30V,.357W,
-100MA,100MHZ
R101 0613952R01 CER CHIP RES 10K OHM 5%
0402
R103 0613952R01 CER CHIP RES 10K OHM 5%
0402
Ref. Des. Part Number Description
R201 0613952R25 CER CHIP RES 100K OHM 5%
0402
R202 0613952Q89 CER CHIP RES 4700 OHM 5 0402
R501 NOT PLACED –
R502 0613952Q45 CER CHIP RES 68.0 OHM 5 0402
R503 0613952R10 CER CHIP RES 24K OHM 5 0402
R504 0613952Q85 CER CHIP RES 3300 OHM 5 0402
R505 0613952R31 CER CHIP RES 180K OHM 5%
0402
R506 0613952Q53 CER CHIP RES 150 OHM 5 0402
R507 0613952Q83 CER CHIP RES 2700 OHM 5 0402
R508 0613952Q41 CER CHIP RES 47.0 OHM 5 0402
R509 0613952Q25 CER CHIP RES 10.0 OHM 5 0402
R511 0613952Q13 CER CHIP RES 3.3 OHM 5 0402
R512 NOT PLACED –
R597 0613952R66 CER CHIP RES 0.0 +/-0.050 OHM
R601 0613952Q41 CER CHIP RES 47.0 OHM 5 0402
R602 0613952Q63 CER CHIP RES 390 OHM 5 0402
R603 0613952R25 CER CHIP RES 100K OHM 5%
0402
R604 0613952Q63 CER CHIP RES 390 OHM 5 0402
R605 0613952R01 CER CHIP RES 10K OHM 5%
0402
R606 0613952R01 CER CHIP RES 10K OHM 5%
0402
R607 0613952R25 CER CHIP RES 100K OHM 5%
0402
R608 0613952R01 CER CHIP RES 10K OHM 5%
0402
R609 0613952Q81 CER CHIP RES 2200 OHM 5 0402
R610 0613952R25 CER CHIP RES 100K OHM 5%
0402
R611 0613952R01 CER CHIP RES 10K OHM 5%
0402
R612 0613952Q94 CER CHIP RES 7500 OHM 5 0402
R613 0613952Q82 CER CHIP RES 2400 OHM 5 0402
R614 0613952R66 CER CHIP RES 0.0 +/-0.050 OHM
R615 NOT PLACED –
R616 NOT PLACED –
R617 NOT PLACED –
R618 NOT PLACED –
R619 NOT PLACED –
Ref. Des. Part Number Description

Motorola APX 7000 Specifications

General

Digital Technology	P25 Phase 1 and Phase 2
Emergency Button	Yes
Frequency Range	136-174 MHz (VHF), 380-470 MHz (UHF Range 1), 450-520 MHz (UHF Range 2), 764-870 MHz (700/800 MHz)
Display	Color LCD
Encryption	AES, DES
Water Resistance	IP67
GPS	Yes
Bluetooth	Yes
Operating Temperature	-30°C to +60°C
Weight	391 g (with standard battery)
