Motorola APX 7000 Detailed Service Manual

Schematics, Boards Overlays, and Parts Lists: Transceiver (RF) Boards: UHF1/UHF2 8-179
R620 NOT PLACED –
R621 NOT PLACED –
R623 NOT PLACED –
R624 NOT PLACED –
R698 0613952R66 CER CHIP RES 0.0 +/-0.050 OHM
R699 0613952R66 CER CHIP RES 0.0 +/-0.050 OHM
R701 0613952Q49 CER CHIP RES 100 OHM 5 0402
R702 0613952R66 CER CHIP RES 0.0 +/-0.050 OHM
R703 0613952Q42 CER CHIP RES 51.0 OHM 5 0402
R704 0613952Q42 CER CHIP RES 51.0 OHM 5 0402
R705 0613952Q25 CER CHIP RES 10.0 OHM 5 0402
R706 0613952R66 CER CHIP RES 0.0 +/-0.050 OHM
R707 0613952R66 CER CHIP RES 0.0 +/-0.050 OHM
R708 0613952Q49 CER CHIP RES 100 OHM 5 0402
R709 NOT PLACED –
R710 NOT PLACED –
R711 NOT PLACED –
R712 0613952Q67 CER CHIP RES 560 OHM 5 0402
R713 0613952Q25 CER CHIP RES 10.0 OHM 5 0402
R714 0613952Q67 CER CHIP RES 560 OHM 5 0402
R721 0613952R01 CER CHIP RES 10K OHM 5%
0402
R729 0613952R09 CER CHIP RES 22K OHM 5%
0402
R743 0613952R17 CER CHIP RES 47K OHM 5%
0402
R745 0613952R09 CER CHIP RES 22K OHM 5%
0402
R751 0613952Q59 CER CHIP RES 270 OHM 5 0402
R752 0613952Q91 CER CHIP RES 5600 OHM 5 0402
R753 NOT PLACED –
R754 NOT PLACED –
R755 0613952R15 CER CHIP RES 39K OHM 5%
0402
R759 0613952Q69 CER CHIP RES 680 OHM 5 0402
R761 0613952Q57 CER CHIP RES 220 OHM 5 0402
R762 0613952R02 CER CHIP RES 11K OHM 5 0402
R764 0613952Q75 CER CHIP RES 1200 OHM 5 0402
R767 0613952Q45 CER CHIP RES 68.0 OHM 5 0402
R772 0613952Q37 CER CHIP RES 33.0 OHM 5 0402
Ref. Des. Part Number Description
R773 0613952Q91 CER CHIP RES 5600 OHM 5 0402
R776 0613952Q39 CER CHIP RES 39.0 OHM 5 0402
R778 0613952Q55 CER CHIP RES 180 OHM 5 0402
R807 0613952R09 CER CHIP RES 22K OHM 5%
0402
R808 0613952R23 CER CHIP RES 82K OHM 5%
0402
R809 0613952Q91 CER CHIP RES 5600 OHM 5 0402
R811 0613952Q39 CER CHIP RES 39.0 OHM 5 0402
R812 0613952Q47 CER CHIP RES 82.0 OHM 5%
0402
R813 0613952Q69 CER CHIP RES 680 OHM 5 0402
R815 0613952Q34 CER CHIP RES 24.0 OHM 5 0402
R818 0613952Q23 CER CHIP RES 8.2 OHM 5 0402
R819 0613952Q59 CER CHIP RES 270 OHM 5 0402
R822 0613952R08 CER CHIP RES 20K OHM 5 0402
R823 0613952R19 CER CHIP RES 56K OHM 5%
0402
R827 0613952Q92 CER CHIP RES 6200 OHM 5 0402
R832 0613952Q29 CER CHIP RES 15.0 OHM 5 0402
R833 0613952Q49 CER CHIP RES 100 OHM 5 0402
R840 0613952Q29 CER CHIP RES 15.0 OHM 5 0402
R848 0613952Q29 CER CHIP RES 15.0 OHM 5 0402
R849 0613952Q67 CER CHIP RES 560 OHM 5 0402
R1101 0613952R25 CER CHIP RES 100K OHM 5%
0402
R1102 0613952R25 CER CHIP RES 100K OHM 5%
0402
R1103 06009259001 LOW RESISTANCE THICK FILM
RESISTOR
R1104 0613952Q49 CER CHIP RES 100 OHM 5 0402
R1105 0613952Q49 CER CHIP RES 100 OHM 5 0402
R1106 0613952Q21 CER CHIP RES 6.8 OHM 5 0402
R1107 0613952Q45 CER CHIP RES 68.0 OHM 5 0402
R1108 0613952R23 CER CHIP RES 82K OHM 5%
0402
R1110 0613952R01 CER CHIP RES 10K OHM 5%
0402
R1112 NOT PLACED –
R1114 0613952Q49 CER CHIP RES 100 OHM 5 0402
R1115 0613952Q49 CER CHIP RES 100 OHM 5 0402
Ref. Des. Part Number Description
R1116 0613952R01 CER CHIP RES 10K OHM 5%
0402
R1117 0613952R22 CER CHIP RES 75K OHM 5 0402
R1121 0613952R12 CER CHIP RES 30K OHM 5 0402
R1122 0613952R22 CER CHIP RES 75K OHM 5 0402
R1124 0613952Q42 CER CHIP RES 51.0 OHM 5 0402
R1125 0613952R17 CER CHIP RES 47K OHM 5%
0402
R1126 0613952R08 CER CHIP RES 20K OHM 5 0402
R1127 0613952R08 CER CHIP RES 20K OHM 5 0402
R1128 0613952R01 CER CHIP RES 10K OHM 5%
0402
R1129 NOT PLACED –
R1130 NOT PLACED –
R1135 0613952R66 CER CHIP RES 0.0 +/-0.050 OHM
R1136 0613952R01 CER CHIP RES 10K OHM 5%
0402
R1137 0613952R01 CER CHIP RES 10K OHM 5%
0402
R1138 0613952R25 CER CHIP RES 100K OHM 5%
0402
R1139 0613952R25 CER CHIP RES 100K OHM 5%
0402
R1140 0613952R25 CER CHIP RES 100K OHM 5%
0402
R1141 0613952R42 CER CHIP RES 510K OHM 5
0402
R1142 0613952R25 CER CHIP RES 100K OHM 5%
0402
R1143 0613952R25 CER CHIP RES 100K OHM 5%
0402
R1144 0613952R25 CER CHIP RES 100K OHM 5%
0402
R1145 0613952R25 CER CHIP RES 100K OHM 5%
0402
R1146 0613952R25 CER CHIP RES 100K OHM 5%
0402
R1151 0613952R05 CER CHIP RES 15K OHM 5%
0402
R1152 0613952R01 CER CHIP RES 10K OHM 5%
0402
R1154 0613952R01 CER CHIP RES 10K OHM 5%
0402
R1158 NOT PLACED –
Ref. Des. Part Number Description
R1160 0613952R03 CER CHIP RES 12K OHM 5%
0402
R1161 0613952R01 CER CHIP RES 10K OHM 5%
0402
R1162 0613952R29 CER CHIP RES 150K OHM 5%
0402
R1163 0613952R01 CER CHIP RES 10K OHM 5%
0402
R1164 0613952R01 CER CHIP RES 10K OHM 5%
0402
R1165 0613952Q56 CER CHIP RES 200 OHM 5 0402
R1166 0613952Q56 CER CHIP RES 200 OHM 5 0402
R1167 0613952R01 CER CHIP RES 10K OHM 5%
0402
R1168 0613952Q49 CER CHIP RES 100 OHM 5 0402
R1169 0613952P52 CER CHIP RES 340K OHM 1
0402
R1170 0613952N88 CER CHIP RES 80.6K OHM 1
0402
R1171 0613952R66 CER CHIP RES 0.0 +/-0.050 OHM
R1172 0613952Q89 CER CHIP RES 4700 OHM 5 0402
R1174 0613952R01 CER CHIP RES 10K OHM 5%
0402
R1175 0613952R66 CER CHIP RES 0.0 +/-0.050 OHM
R1176 0613952Q73 CER CHIP RES 1000 OHM 5 0402
R1177 0613952R66 CER CHIP RES 0.0 +/-0.050 OHM
R1178 0613952R01 CER CHIP RES 10K OHM 5%
0402
R1179 0613952R66 CER CHIP RES 0.0 +/-0.050 OHM
R1180 0613952R66 CER CHIP RES 0.0 +/-0.050 OHM
R1181 NOT PLACED –
R1182 0613952R01 CER CHIP RES 10K OHM 5%
0402
R1183 0613952Q73 CER CHIP RES 1000 OHM 5 0402
R1184 0613952Q81 CER CHIP RES 2200 OHM 5 0402
R1304 NOT PLACED –
R1307 0613952Q73 CER CHIP RES 1000 OHM 5 0402
R1500 0613952R66 CER CHIP RES 0.0 +/-0.050 OHM
R1501 NOT PLACED –
R1502 0613952Q73 CER CHIP RES 1000 OHM 5 0402
R1503 0613952R02 CER CHIP RES 11K OHM 5 0402
Ref. Des. Part Number Description

Motorola APX 7000 Specifications

General

Digital Technology	P25 Phase 1 and Phase 2
Emergency Button	Yes
Frequency Range	136-174 MHz (VHF), 380-470 MHz (UHF Range 1), 450-520 MHz (UHF Range 2), 764-870 MHz (700/800 MHz)
Display	Color LCD
Encryption	AES, DES
Water Resistance	IP67
GPS	Yes
Bluetooth	Yes
Operating Temperature	-30°C to +60°C
Weight	391 g (with standard battery)
