Motorola APX 7000 Detailed Service Manual

Schematics, Boards Overlays, and Parts Lists: Transceiver (RF) Boards: UHF2/VHF 8-261
C730 2113945C31 CAP,FXD,.1UF,+10%,-10%,50V-
DC,0603,X7R,-55DEG CMIN,
125DEG CMAX
C731 2113945C31 CAP,FXD,.1UF,+10%,-10%,50V-
DC,0603,X7R,-55DEG CMIN,
125DEG CMAX
C732 2113944A32 CAP,CHIP,39PF,+5%,-5%,50V-
DC,0402,C0G,-55DEG CMIN,
125DEG CMAX,P
C734 2113945C31 CAP,FXD,.1UF,+10%,-10%,50V-
DC,0603,X7R,-55DEG CMIN,
125DEG CMAX
C736 2113945B02 CAP,CHIP,.01UF,+10%,-10%, 25V-
DC,0402,X7R,-55DEG CMIN,
125DEG CMA
C737 2113945C31 CAP,FXD,.1UF,+10%,-10%,50V-
DC,0603,X7R,-55DEG CMIN,
125DEG CMAX
C739 2113944A17 CAP,CHIP,4.7PF,.25PF+/-,50V-
DC,0402,C0G,-55DEG CMIN,
125DEG CMA
C742 2113945C31 CAP,FXD,.1UF,+10%,-10%,50V-
DC,0603,X7R,-55DEG CMIN,
125DEG CMAX
C744 2113955D37 CAP,FXD,10UF,+10%,-10%,16V-
DC,1206,X7R,-55DEG CMIN,
125DEG CMAX
C747 2113944A44 CAP,CHIP,220PF,+5%,-5%,50V-
DC,0402,C0G,-55DEG CMIN,
125DEG CMAX
C748 2113944A44 CAP,CHIP,220PF,+5%,-5%,50V-
DC,0402,C0G,-55DEG CMIN,
125DEG CMAX
C749 2113945C31 CAP,FXD,.1UF,+10%,-10%,50V-
DC,0603,X7R,-55DEG CMIN,
125DEG CMAX
C750 2113945C31 CAP,FXD,.1UF,+10%,-10%,50V-
DC,0603,X7R,-55DEG CMIN,
125DEG CMAX
C752 2113944A43 CAP,CHIP,180PF,+5%,-5%,50V-
DC,0402,C0G,-55DEG CMIN,
125DEG CMAX
C754 NOT PLACED –
C756 2113955D37 CAP,FXD,10UF,+10%,-10%,16V-
DC,1206,X7R,-55DEG CMIN,
125DEG CMAX
C757 2113945C31 CAP,FXD,.1UF,+10%,-10%,50V-
DC,0603,X7R,-55DEG CMIN,
125DEG CMAX
Ref. Des. Part Number Description
C758 2113946B02 CAP,CHIP,.047UF,+10%,-10%,
10V-DC,0402,X5R,-55DEG CMIN,
85DEG CMA
C759 2113945G95 CAP,FXD,.22UF,+10%,-10%, 50V-
DC,0805,X7R,-55DEG CMIN,
125DEG CMAX
C760 2113944G97 CAP,FXD,.082UF,+5%,-5%,50V-
DC,1206,C0G,-55DEG CMIN,
125DEG CMAX
C762 2113945C26 CAP,FXD,.039UF,+10%,-10%,
50V-DC,0603,X7R,-55DEG CMIN,
125DEG CMA
C763 2113944G97 CAP,FXD,.082UF,+5%,-5%,50V-
DC,1206,C0G,-55DEG CMIN,
125DEG CMAX
C765 2113944G97 CAP,FXD,.082UF,+5%,-5%,50V-
DC,1206,C0G,-55DEG CMIN,
125DEG CMAX
C766 2113945C01 CAP,CHIP,6800PF,+10%,-10%,
50V-DC,0603,X7R,-55DEG CMIN,
125DEG CM
C768 2113944G97 CAP,FXD,.082UF,+5%,-5%,50V-
DC,1206,C0G,-55DEG CMIN,
125DEG CMAX
C769 2113945C20 CAP,FXD,.016UF,+10%,-10%,
50V-DC,0603,X7R,-55DEG CMIN,
125DEG CMA
C770 2113944G97 CAP,FXD,.082UF,+5%,-5%,50V-
DC,1206,C0G,-55DEG CMIN,
125DEG CMAX
C771 2113944A40 CAP,CHIP,100PF,+5%,-5%,50V-
DC,0402,C0G,-55DEG CMIN,
125DEG CMAX
C775 2113945A09 CAP,CHIP,1000PF,+10%,-10%,
50V-DC,0402,X7R,-55DEG CMIN,
125DEG CM
C777 2113944A31 CAP,CHIP,33PF,+5%,-5%,50V-
DC,0402,C0G,-55DEG CMIN,
125DEG CMAX,P
C779 2113944A40 CAP,CHIP,100PF,+5%,-5%,50V-
DC,0402,C0G,-55DEG CMIN,
125DEG CMAX
C783 2113944C53 CAP,CHIP,1500PF,+5%,-5%, 50V-
DC,0603,C0G,-55DEG CMIN,
125DEG CMAX
C789 2113946B04 CAP,CHIP,.1UF,+10%,-10%,10V-
DC,0402,X5R,-55DEG CMIN,
85DEG CMAX
Ref. Des. Part Number Description
C790 2113946B04 CAP,CHIP,.1UF,+10%,-10%,10V-
DC,0402,X5R,-55DEG CMIN,
85DEG CMAX
C791 2113946B04 CAP,CHIP,.1UF,+10%,-10%,10V-
DC,0402,X5R,-55DEG CMIN,
85DEG CMAX
C792 2113946B04 CAP,CHIP,.1UF,+10%,-10%,10V-
DC,0402,X5R,-55DEG CMIN,
85DEG CMAX
C793 2113944A40 CAP,CHIP,100PF,+5%,-5%,50V-
DC,0402,C0G,-55DEG CMIN,
125DEG CMAX
C794 NOT PLACED –
C795 2113944A40 CAP,CHIP,100PF,+5%,-5%,50V-
DC,0402,C0G,-55DEG CMIN,
125DEG CMAX
C796 2113944A40 CAP,CHIP,100PF,+5%,-5%,50V-
DC,0402,C0G,-55DEG CMIN,
125DEG CMAX
C797 2113944A40 CAP,CHIP,100PF,+5%,-5%,50V-
DC,0402,C0G,-55DEG CMIN,
125DEG CMAX
C798 2113945A09 CAP,CHIP,1000PF,+10%,-10%,
50V-DC,0402,X7R,-55DEG CMIN,
125DEG CM
C799 2113944A40 CAP,CHIP,100PF,+5%,-5%,50V-
DC,0402,C0G,-55DEG CMIN,
125DEG CMAX
C800 2113944A29 CAP,CHIP,22PF,+5%,-5%,50V-
DC,0402,C0G,-55DEG CMIN,
125DEG CMAX,P
C801 2113944A21 CAP,CHIP,6.8PF,.5PF+/-,50V-DC,
0402,C0G,-55DEG CMIN,
125DEG CMAX
C802 2113946B06 CAP,CHIP,.22UF,+10%,-10%, 10V-
DC,0402,X5R,-55DEG CMIN,
85DEG CMAX
C803 2113944A29 CAP,CHIP,22PF,+5%,-5%,50V-DC
0402,C0G,-55DEG CMIN,
125DEG CMAX,P
C804 2113944A40 CAP,CHIP,100PF,+5%,-5%,50V-
DC,0402,C0G,-55DEG CMIN,
125DEG CMAX
C805 2113944A40 CAP,CHIP,100PF,+5%,-5%,50V-
DC,0402,C0G,-55DEG CMIN,
125DEG CMAX
C806 2113946B06 CAP,CHIP,.22UF,+10%,-10%, 10V-
DC,0402,X5R,-55DEG CMIN,
85DEG CMAX
Ref. Des. Part Number Description
C810 2113944A44 CAP,CHIP,220PF,+5%,-5%,50V-
DC,0402,C0G,-55DEG CMIN,
125DEG CMAX
C813 2113944A63 CAP,FXD,1PF,.25PF+/-,50V-DC,
0402,C0G,-55DEG CMIN,
125DEG CMAX,P
C814 2113945A09 CAP,CHIP,1000PF,+10%,-10%,
50V-DC,0402,X7R,-55DEG CMIN,
125DEG CM
C816 2113944A31 CAP,CHIP,33PF,+5%,-5%,50V-
DC,0402,C0G,-55DEG CMIN,
125DEG CMAX,P
C820 2113944A44 CAP,CHIP,220PF,+5%,-5%,50V-
DC,0402,C0G,-55DEG CMIN,
125DEG CMAX
C830 2113944A44 CAP,CHIP,220PF,+5%,-5%,50V-
DC,0402,C0G,-55DEG CMIN,
125DEG CMAX
C831 2113944A40 CAP,CHIP,100PF,+5%,-5%,50V-
DC,0402,C0G,-55DEG CMIN,
125DEG CMAX
C836 2113944A33 CAP,CHIP,47PF,+5%,-5%,50V-
DC,0402,C0G,-55DEG CMIN,
125DEG CMAX,P
C838 2113945A09 CAP,CHIP,1000PF,+10%,-10%,
50V-DC,0402,X7R,-55DEG CMIN,
125DEG CM
C844 2113944A33 CAP,CHIP,47PF,+5%,-5%,50V-
DC,0402,C0G,-55DEG CMIN,
125DEG CMAX,P
C851 2113944A44 CAP,CHIP,220PF,+5%,-5%,50V-
DC,0402,C0G,-55DEG CMIN,
125DEG CMAX
C901 2113944M40 CAP,FXD,82PF,+2%,-2%,50V-DC,
0603,C0G,-55DEG CMIN,
125DEG CMAX,PB
C902 2113944C04 CAP,CHIP,330PF,+5%,-5%,50V-
DC,0603,C0G,-55DEG CMIN,
125DEG CMAX
C903 2113945L49 CAP,FXD,.01UF,+5%,-5%,50V-
DC,0603,X7R,-55DEG CMIN,
125DEG CMAX,P
C904 2113944M36 CAP,FXD,56PF,+2%,-2%,50V-DC,
0603,C0G,-55DEG CMIN,
125DEG CMAX,PB
C905 2113945L49 CAP,FXD,.01UF,+5%,-5%,50V-
DC, 0603,X7R,-55DEG CMIN,
125DEG CMAX,P
Ref. Des. Part Number Description

Motorola APX 7000 Specifications

General

Digital Technology	P25 Phase 1 and Phase 2
Emergency Button	Yes
Frequency Range	136-174 MHz (VHF), 380-470 MHz (UHF Range 1), 450-520 MHz (UHF Range 2), 764-870 MHz (700/800 MHz)
Display	Color LCD
Encryption	AES, DES
Water Resistance	IP67
GPS	Yes
Bluetooth	Yes
Operating Temperature	-30°C to +60°C
Weight	391 g (with standard battery)
