Motorola APX 7000 Detailed Service Manual

8-262 Schematics, Boards Overlays, and Parts Lists: Transceiver (RF) Boards: UHF2/VHF
C906 2113944C04 CAP,CHIP,330PF,+5%,-5%,50V-
DC,0603,C0G,-55DEG CMIN,
125DEG CMAX
C907 2113944C04 CAP,CHIP,330PF,+5%,-5%,50V-
DC,0603,C0G,-55DEG CMIN,
125DEG CMAX
C908 2113944C04 CAP,CHIP,330PF,+5%,-5%,50V-
DC,0603,C0G,-55DEG CMIN,
125DEG CMAX
C909 2113944C04 CAP,CHIP,330PF,+5%,-5%,50V-
DC,0603,C0G,-55DEG CMIN,
125DEG CMAX
C910 2113944C23 CAP,CHIP,5.1PF,.5PF+/-,50V-DC,
0603,C0G,-55DEG CMIN,
125DEG CMAX
C911 2113945L49 CAP,FXD,.01UF,+5%,-5%,50V-
DC,0603,X7R,-55DEG CMIN,
125DEG CMAX,P
C912 NOT PLACED –
C913 2113944M29 CAP,FXD,30PF,+2%,-2%,50V-DC,
0603,C0G,-55DEG CMIN,
125DEG CMAX,PB
C914 2113944M18 CAP,FXD,10PF,+2.5%,-2.5%, 50V-
DC,0603,C0G,-55DEG CMIN,
125DEG CMA
C915 2113944C04 CAP,CHIP,330PF,+5%,-5%,50V-
DC,0603,C0G,-55DEG CMIN,
125DEG CMAX
C916 2113944M40 CAP,FXD,82PF,+2%,-2%,50V-DC,
0603,C0G,-55DEG CMIN,
125DEG CMAX,PB
C917 NOT PLACED –
C918 2113944C04 CAP,CHIP,330PF,+5%,-5%,50V-
DC,0603,C0G,-55DEG CMIN,
125DEG CMAX
C919 2113944M22 CAP,FXD,15PF,+2%,-2%,50V-DC,
0603,C0G,-55DEG CMIN,
125DEG CMAX,PB
C920 21009257002 CAP,CER,39PF,+5%,-5%,50V-DC,
0805,-55DEG CMIN,125DEG
CMAX,0805
C921 21009257002 CAP,CER,39PF,+5%,-5%,50V-DC,
0805,-55DEG CMIN,125DEG
CMAX,0805
C922 2113944M29 CAP,FXD,30PF,+2%,-2%,50V-DC
0603,C0G,-55DEG CMIN,
125DEG CMAX,PB
Ref. Des. Part Number Description
C923 2113944M15 CAP,FXD,7.5PF,.1PF+/-,50V-DC,
0603,C0G,-55DEG CMIN,
125DEG CMAX
C924 2113944M19 CAP,FXD,11PF,+2%,-2%,50V-
DC,0603,C0G,-55DEG CMIN,
125DEG CMAX,PB
C925 2113944C04 CAP,CHIP,330PF,+5%,-5%,50V-
DC,0603,C0G,-55DEG CMIN,
125DEG CMAX
C927 NOT PLACED –
C928 2113944M23 CAP,FXD,16PF,+2%,-2%,50V-DC,
0603,C0G,-55DEG CMIN,
125DEG CMAX,PB
C929 2113945A12 CAP,CHIP,3300PF,+10%,-10%,
50V-DC,0402,X7R,-55DEG CMIN,
125DEG CM
C930 2113945A12 CAP,CHIP,3300PF,+10%,-10%,
50V-DC,0402,X7R,-55DEG CMIN,
125DEG CM
C1101 2113945B02 CAP,CHIP,.01UF,+10%,-10%, 25V-
DC,0402,X7R,-55DEG CMIN,
125DEG CMA
C1102 2188468Y01 CAP,CHIP,1UF,+10,-10,25V-DC,
0805,X7R
C1103 2113945B02 CAP,CHIP,.01UF,+10%,-10%, 25V-
DC,0402,X7R,-55DEG CMIN,
125DEG CMA
C1104 NOT PLACED –
C1105 2113944A19 CAP,CHIP,5.6PF,.5PF+/-,50V-DC,
0402,C0G,-55DEG CMIN,
125DEG CMAX
C1106 2113945B02 CAP,CHIP,.01UF,+10%,-10%, 25V-
DC,0402,X7R,-55DEG CMIN,
125DEG CMA
C1107 2113944A40 CAP,CHIP,100PF,+5%,-5%,50V-
DC,0402,C0G,-55DEG CMIN,
125DEG CMAX
C1108 2113946B02 CAP,CHIP,.047UF,+10%,-10%,
10V-DC,0402,X5R,-55DEG
CMIN,85DEG CMA
C1109 2113944A40 CAP,CHIP,100PF,+5%,-5%,50V-
DC,0402,C0G,-55DEG CMIN,
125DEG CMAX
C1110 2113944A40 CAP,CHIP,100PF,+5%,-5%,50V-
DC,0402,C0G,-55DEG CMIN,
125DEG CMAX
Ref. Des. Part Number Description
C1111 2113945Y02 CAP,FXD,.1UF,+10%,-10%,16V-
DC,0402,X7R,-55DEG CMIN,
125DEG CMAX
C1112 2113945B01 CAP,CHIP,6800PF,+10%,-10%,
25V-DC,0402,X7R,-55DEG CMIN,
125DEG CM
C1113 2113945B02 CAP,CHIP,.01UF,+10%,-10%, 25V-
DC,0402,X7R,-55DEG CMIN,
125DEG CMA
C1116 2113945Y02 CAP,FXD,.1UF,+10%,-10%,16V-
DC,0402,X7R,-55DEG CMIN,
125DEG CMAX
C1117 2113945A12 CAP,CHIP,3300PF,+10%,-10%,
50V-DC,0402,X7R,-55DEG CMIN,
125DEG CM
C1118 2113945B02 CAP,CHIP,.01UF,+10%,-10%, 25V-
DC,0402,X7R,-55DEG CMIN,
125DEG CMA
C1119 2113945B02 CAP,CHIP,.01UF,+10%,-10%, 25V-
DC,0402,X7R,-55DEG CMIN,
125DEG CMA
C1120 2113945B02 CAP,CHIP,.01UF,+10%,-10%, 25V-
DC,0402,X7R,-55DEG CMIN,
125DEG CMA
C1122 2175390H01 CAP,CER,2.2PF,50V-DC,C0G,
CAP,2.2 PF, 0402, CERAMIC, 50V
C1123 2113945B02 CAP,CHIP,.01UF,+10%,-10%, 25V-
DC,0402,X7R,-55DEG CMIN,
125DEG CMA
C1124 2113945A13 CAP,CHIP,4700PF,+10%,-10%,
50V-DC,0402,X7R,-55DEG CMIN,
125DEG CM
C1125 NOT PLACED –
C1126 2113945A09 CAP,CHIP,1000PF,+10%,-10%,
50V-DC,0402,X7R,-55DEG
CMIN,125DEG CM
C1127 2113945Y02 CAP,FXD,.1UF,+10%,-10%,16V-
DC,0402,X7R,-55DEG CMIN,
125DEG CMAX
C1128 2113945B02 CAP,CHIP,.01UF,+10%,-10%, 25V-
DC,0402,X7R,-55DEG CMIN,
125DEG CMA
C1129 2113945B02 CAP,CHIP,.01UF,+10%,-10%, 25V-
DC,0402,X7R,-55DEG CMIN,
125DEG CMA
C1130 2113945B02 CAP,CHIP,.01UF,+10%,-10%, 25V-
DC,0402,X7R,-55DEG CMIN,
125DEG CMA
Ref. Des. Part Number Description
C1132 NOT PLACED –
C1134 2113945B01 CAP,CHIP,6800PF,+10%,-10%,
25V-DC,0402,X7R,-55DEG CMIN,
125DEG CM
C1135 NOT PLACED –
C1137 2113945B04 CAP,FXD,.022UF,+10%,-10%,
25V-DC,0402,X7R,-55DEG CMIN,
125DEG CMA
C1138 2113945B04 CAP,FXD,.022UF,+10%,-10%,
25V-DC,0402,X7R,-55DEG CMIN,
125DEG CMA
C1139 2113944A25 CAP,CHIP,10PF,+5%,-5%,50V-
DC,0402,C0G,-55DEG CMIN,
125DEG CMAX,P
C1140 2113945A13 CAP,CHIP,4700PF,+10%,-10%,
50V-DC,0402,X7R,-55DEG CMIN,
125DEG CM
C1141 2113945Y02 CAP,FXD,.1UF,+10%,-10%,16V-
DC,0402,X7R,-55DEG CMIN,
125DEG CMAX
C1142 2113945A09 CAP,CHIP,1000PF,+10%,-10%,
50V-DC,0402,X7R,-55DEG CMIN,
125DEG CM
C1149 2113944A40 CAP,CHIP,100PF,+5%,-5%,50V-
DC,0402,C0G,-55DEG CMIN,
125DEG CMAX
C1150 2175392H01 CAP,CER,1.2PF,50V-DC, C0G,
CAP, 1.2PF, 0402, CERAMIC, 50V
C1152 2113945A11 CAP,CHIP,2200PF,+10%,-10%,
50V-DC,0402,X7R,-55DEG CMIN,
125DEG CM
C1203 2113944M19 CAP,FXD,11PF,+2%,-2%,50V-DC,
0603,C0G,-55DEG CMIN,
125DEG CMAX,PB
C1204 2113944M13 CAP,FXD,6.2PF,.1PF+/-,50V-DC,
0603,C0G,-55DEG CMIN,
125DEG CMAX
C1207 2113944M27 CAP,FXD,24PF,+2%,-2%,50V-DC,
0603,C0G,-55DEG CMIN,
125DEG CMAX,PB
C1220 2113944M16 CAP,FXD,8.2PF,.1PF+/-,50V-DC,
0603,C0G,-55DEG CMIN,
125DEG CMAX
C1221 2113944M27 CAP,FXD,24PF,+2%,-2%,50V-DC,
0603,C0G,-55DEG CMIN,
125DEG CMAX,PB
Ref. Des. Part Number Description
