Motorola APX 7000 Detailed Service Manual

Schematics, Boards Overlays, and Parts Lists: Transceiver (RF) Boards: UHF2/VHF 8-263
C1222 2113944C04 CAP,CHIP,330PF,+5%,-5%,50V-
DC,0603,C0G,-55DEG CMIN,
125DEG CMAX
C1226 2113944M11 CAP,FXD,5.1PF,.1PF+/-,50V-DC,
0603,C0G,-55DEG CMIN,
125DEG CMAX
C1227 2113944M17 CAP,FXD,9.1PF,.1PF+/-,50V-DC,
0603,C0G,-55DEG CMIN,
125DEG CMAX
C1301 2113944M20 CAP,FXD,12PF,+2%,-2%,50V-
DC,0603,C0G,-55DEG CMIN,
125DEG CMAX,PB
C1302 2114036F74 CAP,FXD,1.8PF,.05PF+/-,25V-
DC,0402,C0G,-55DEG CMIN,
125DEG CMAX
C1303 2113944A26 CAP,CHIP,12PF,+5%,-5%,50V-
DC,0402,C0G,-55DEG CMIN,
125DEG CMAX,P
C1304 2113945A09 CAP,CHIP,1000PF,+10%,-10%,
50V-DC,0402,X7R,-55DEG CMIN,
125DEG CM
C1305 2113944A30 CAP,CHIP,27PF,+5%,-5%,50V-
DC,0402,C0G,-55DEG CMIN,
125DEG CMAX,P
C1306 2113945B02 CAP,CHIP,.01UF,+10%,-10%, 25V-
DC,0402,X7R,-55DEG CMIN,
125DEG CMA
C1307 2113944A26 CAP,CHIP,12PF,+5%,-5%,50V-
DC,0402,C0G,-55DEG CMIN,
125DEG CMAX,P
C1308 2113944A28 CAP,CHIP,18PF,+5%,-5%,50V-
DC,0402,C0G,-55DEG CMIN,
125DEG CMAX,P
C1309 2175389H01 CAP,.5PF,CAP,.5PF, CHIP, 0402,
CERAMIC, 50 V
C1310 2113944A17 CAP,CHIP,4.7PF,.25PF+/-,50V-
DC,0402,C0G,-55DEG CMIN,
125DEG CMA
C1500 2113944C45 CAP,CHIP,100PF,+5%,-5%,50V-
DC,0603,C0G,-55DEG CMIN,
125DEG CMAX
C1501 2113945C02 CAP,CHIP,.01UF,+10%,-10%, 50V-
DC,0603,X7R,-55DEG
CMIN,125DEG CMA
C1502 2113944C45 CAP,CHIP,100PF,+5%,-5%,50V-
DC,0603,C0G,-55DEG CMIN,
125DEG CMAX
Ref. Des. Part Number Description
C1503 2113944C45 CAP,CHIP,100PF,+5%,-5%,50V-
DC,0603,C0G,-55DEG CMIN,
125DEG CMAX
C1504 2113945C02 CAP,CHIP,.01UF,+10%,-10%, 50V-
DC,0603,X7R,-55DEG CMIN,
125DEG CMA
C1505 2113944C45 CAP,CHIP,100PF,+5%,-5%,50V-
DC,0603,C0G,-55DEG CMIN,
125DEG CMAX
C1506 2113944A40 CAP,CHIP,100PF,+5%,-5%,50V-
DC,0402,C0G,-55DEG CMIN,
125DEG CMAX
C1507 2113944A40 CAP,CHIP,100PF,+5%,-5%,50V-
DC,0402,C0G,-55DEG CMIN,
125DEG CMAX
C1508 2113944C12 CAP,CHIP,1.8PF,.25PF+/-,50V-
DC,0603,C0G,-55DEG CMIN,
125DEG CMA
C1509 2113944C41 CAP,CHIP,68PF,+5%,-5%,50V-
DC,0603,C0G,-55DEG CMIN,
125DEG CMAX,P
C1510 2113944M26 CAP,FXD,22PF,+2%,-2%,50V-
DC,0603,C0G,-55DEG CMIN,
125DEG CMAX,PB
C1511 2113944M30 CAP,FXD,33PF,+2%,-2%,50V-
DC,0603,C0G,-55DEG CMIN,
125DEG CMAX,PB
C1512 NOT PLACED –
C1513 2113944C45 CAP,CHIP,100PF,+5%,-5%,50V-
DC,0603,C0G,-55DEG CMIN,
125DEG CMAX
C1514 2113945C02 CAP,CHIP,.01UF,+10%,-10%, 50V-
DC,0603,X7R,-55DEG CMIN,
125DEG CMA
C1515 NOT PLACED –
C1516 21007088001 CAP,CER CHIP,33PF,+5%,-5%,
50V-DC,C0G,-55DEG CMIN,
125DEG CMAX,0
C1517 21007088008 CAP,CER CHIP,18PF,+5%,-5%,
100V-DC,0805,COG,-55DEG
CMIN,125DEG C
C1518 21007088007 CAP,CER CHIP,7.5PF,.5PF+/-,
100V-DC,C0G,-55DEG CMIN,
125DEG CMA
C1519 NOT PLACED –
C1520 21007088005 CAP,CER CHIP,8.2PF,.5PF+/-,
100V-DC,C0G,-55DEG CMIN,
125DEG CMA
Ref. Des. Part Number Description
C1521 2113944C45 CAP,CHIP,100PF,+5%,-5%,50V-
DC,0603,C0G,-55DEG CMIN,
125DEG CMAX
C1522 2113944A40 CAP,CHIP,100PF,+5%,-5%,50V-
DC,0402,C0G,-55DEG CMIN,
125DEG CMAX
C1523 NOT PLACED –
C1525 NOT PLACED –
C1526 2113945Y02 CAP,FXD,.1UF,+10%,-10%,16V-
DC,0402,X7R,-55DEG CMIN,
125DEG CMAX
C1527 21007088006 CAP,CER CHIP,10PF,+5%,-5%,
100V-DC,C0G,-55DEG CMIN,
125DEG CMAX
C1598 2113945A12 CAP,CHIP,3300PF,+10%,-10%,
50V-DC,0402,X7R,-55DEG CMIN,
125DEG CM
C1599 2113945A12 CAP,CHIP,3300PF,+10%,-10%,
50V-DC,0402,X7R,-55DEG
CMIN,125DEG CM
C1700 2113944M06 CAP,FXD,3.3PF,.1PF+/-,50V-DC,
0603,C0G,-55DEG CMIN,
125DEG CMAX
C1701 2113944M14 CAP,FXD,6.8PF,.1PF+/-,50V-DC,
0603,C0G,-55DEG CMIN,
125DEG CMAX
C1702 2113944M15 CAP,FXD,7.5PF,.1PF+/-,50V-DC,
0603,C0G,-55DEG CMIN,
125DEG CMAX
C1703 2113944M06 CAP,FXD,3.3PF,.1PF+/-,50V-DC,
0603,C0G,-55DEG CMIN,
125DEG CMAX
C1704 2113944M02 CAP,FXD,2.2PF,.1PF+/-,50V-DC,
0603,C0G,-55DEG CMIN,
125DEG CMAX
C1705 2113944C67 CAP,FXD,1.5PF,.1PF+/-,50V-DC,
0603,C0G,-55DEG CMIN,
125DEG CMAX
C1706 NOT PLACED –
C1707 2113944C45 CAP,CHIP,100PF,+5%,-5%,50V-
DC,0603,C0G,-55DEG CMIN,
125DEG CMAX
C1920 2113946D07 CAP,CHIP,4.7UF,+10%,-10%,
6.3V-DC,0603,X5R,-55DEG
CMIN,85DEG CMA
C1922 2113944A40 CAP,CHIP,100PF,+5%,-5%,50V-
DC,0402,C0G,-55DEG CMIN,
125DEG CMAX
Ref. Des. Part Number Description
C1923 2113944A40 CAP,CHIP,100PF,+5%,-5%,50V-
DC,0402,C0G,-55DEG CMIN,
125DEG CMAX
C1924 2113946D07 CAP,CHIP,4.7UF,+10%,-10%,
6.3V-DC,0603,X5R,-55DEG
CMIN,85DEG CMA
C1925 2113944A40 CAP,CHIP,100PF,+5%,-5%,50V-
DC,0402,C0G,-55DEG CMIN,
125DEG CMAX
C1926 2113946B04 CAP,CHIP,.1UF,+10%,-10%,10V-
DC,0402,X5R,-55DEG CMIN,
85DEG CMAX
C1928 2115153H28 CAP,CER CHIP,4PF,.1PF+/-,
+.1%,-.1%,50V-DC,0402,C0G
C1929 2115153H30 CAP,FXD,6PF,.1PF+/-,+.1%,
-.1%,50V-DC,0402,C0G
C1931 2171051Y05 CAP,CER CHIP,180PF,+1%,
-1%,50V-DC,0402,COG,-55DEG
CMIN,125DEG C
C1935 2115153H12 CAP,FXD,2.4PF,.1PF+/-,+4.2%,
-4.2%,50V-DC,0402,C0G
C1936 2115153H31 CAP,FXD,7PF,.1PF+/-,50V-DC,
0402,C0G,-55DEG CMIN, 25DEG
CMAX
C1938 2115153H07 CAP,FXD,1.5PF,.1PF+/-,50V-DC,
0402,C0G
C1939 2115153H12 CAP,FXD,2.4PF,.1PF+/-,+4.2%,
-4.2%,50V-DC,0402,C0G
C1940 2113944A40 CAP,CHIP,100PF,+5%,-5%,50V-
DC,0402,C0G,-55DEG CMIN,
125DEG CMAX
C1941 2113946B04 CAP,CHIP,.1UF,+10%,-10%,10V-
DC,0402,X5R,-55DEG CMIN,
85DEG CMAX
C1942 2115153H38 CAP,FXD,16PF,+1%,-1%,50V-DC,
0402,C0G
C1952 2115153H30 CAP,FXD,6PF,.1PF+/-,+.1%,
-.1%,50V-DC,0402,C0G
C1953 2115153H28 CAP,CER CHIP,4PF,.1PF+/-,
+.1%,-.1%,50V-DC,0402,C0G
C1953 2115153H28 CAP,CER CHIP,4PF,.1PF+/-,
+.1%,-.1%,50V-DC,0402,C0G
C1954 2113944A40 CAP,CHIP,100PF,+5%,-5%,50V-
DC,0402,C0G,-55DEG CMIN,
125DEG CMAX
C1955 2113946B04 CAP,CHIP,.1UF,+10%,-10%,10V-
DC,0402,X5R,-55DEG CMIN,
85DEG CMAX
Ref. Des. Part Number Description

Motorola APX 7000 Specifications

General

Digital Technology	P25 Phase 1 and Phase 2
Emergency Button	Yes
Frequency Range	136-174 MHz (VHF), 380-470 MHz (UHF Range 1), 450-520 MHz (UHF Range 2), 764-870 MHz (700/800 MHz)
Display	Color LCD
Encryption	AES, DES
Water Resistance	IP67
GPS	Yes
Bluetooth	Yes
Operating Temperature	-30°C to +60°C
Weight	391 g (with standard battery)
