Motorola APX 7000 Detailed Service Manual

8-264 Schematics, Boards Overlays, and Parts Lists: Transceiver (RF) Boards: UHF2/VHF
C1956 2115153H28 CAP,CER CHIP,4PF,.1PF+/-,
+.1%,-.1%,50V-DC,0402,C0G
C1957 2115153H21 CAP,FXD,5.6PF,.1PF+/-,50V-DC,
0402,C0G
C1958 2115153H38 CAP,FXD,16PF,+1%,-1%,50V-DC,
0402,C0G
C1959 2115153H12 CAP,FXD,2.4PF,.1PF+/-,+4.2%,
-4.2%,50V-DC,0402,C0G
C1960 2115153H07 CAP,FXD,1.5PF,.1PF+/-,50V-DC,
0402,C0G
C1961 2115153H12 CAP,FXD,2.4PF,.1PF+/-,+4.2%,
-4.2%,50V-DC,0402,C0G
C1963 2115153H21 CAP,FXD,5.6PF,.1PF+/-,50V-DC,
0402,C0G
D200 4813978A19 DIODE,RECT,MBR120,SM,SOD-
123,1A,20V,SHTK,PB-FREE
D722 4815011H01 DIODE,SWG,SM,300MA,80V,
TRP
D723 4815011H01 DIODE,SWG,SM,300MA,80V,
TRP
E200 2405688Z01 IDCTR,BEAD,FERR BEAD
E201 2405688Z01 IDCTR,BEAD,FERR BEAD
E301 2480640Z01 FLTR,FERR,SM,SUR MT FERR
BEAD
E501 2480640Z01 FLTR,FERR,SM,SUR MT FERR
BEAD
E601 2480640Z01 FLTR,FERR,SM,SUR MT FERR
BEAD
E602 2480640Z01 FLTR,FERR,SM,SUR MT FERR
BEAD
E603 2480640Z01 FLTR,FERR,SM,SUR MT FERR
BEAD
E604 2480640Z01 FLTR,FERR,SM,SUR MT FERR
BEAD
E605 2480640Z01 FLTR,FERR,SM,SUR MT FERR
BEAD
E606 2480640Z01 FLTR,FERR,SM,SUR MT FERR
BEAD
E607 2480640Z01 FLTR,FERR,SM,SUR MT FERR
BEAD
E608 2480640Z01 FLTR,FERR,SM,SUR MT FERR
BEAD
E609 2480640Z01 FLTR,FERR,SM,SUR MT FERR
BEAD
E1101 2405688Z01 IDCTR,BEAD,FERR BEAD
Ref. Des. Part Number Description
E1921 2480640Z01 FLTR,FERR,SM,SUR MT FERR
BEAD
F200 6575834B01 FUSE,FST BLW,2A,32V,FUSE
SUR MT
FL1301 9189697V15 FLTR,1.57542GHZ NOM,
1.57642GHZ MIN,1.57442GHZ
MAX,50OHM,SM,PB
FL501 91009300001 FLTR,BANDPASS,109.65MHZ
NOM,FILTER,MONOLITHIC
CRYSTAL,BAND
J101 0909901V02 CONN,RCPT,SMT MCX
J102 0975886B01 RF CONN,F,RECEPTACLE,
COAX CBL
L200 2571269C01 IDCTR,COIL,1.5UH,20%,2.9A,
.059OHM,FERR,SM,WW PWR
W18 COMP
L301 2414032F35 IDCTR,WW,120NH,5%,400MA,
.51OHM,CER,35 Q,860MHZ SRF,
SM,PB-FR
L302 2460591H08 IDCTR,AW,36.6NH,AIR,10
TURNS,28 AWG,SM,HI Q, SUR
MT COIL
L303 2460591H08 IDCTR,AW,36.6NH,AIR,10
TURNS,28 AWG,SM,HI Q, SUR
MT COIL
L304 2414017N22 IDCTR,CHIP,68NH,5%,400MA,
1.2OHM,CER,14 Q,800MHZ SRF,
SM,0603
L305 2415429H34 IDCTR,WW,72NH,5%,400MA,
.49OHM,CER,SM,0603,CHIP
L306 2414017P13 IDCTR,CHIP,10NH,5%,300MA,
.46OHM,CER,9 Q,2.5GHZ SRF,
SM,0402,P
L307 2414032F35 IDCTR,WW,120NH,5%,400MA,
.51OHM,CER,35 Q,860MHZ SRF,
SM,PB-FR
L308 2414032F35 IDCTR,WW,120NH,5%,400MA,
.51OHM,CER,35 Q,860MHZ SRF,
SM,PB-FR
L309 2415429H28 IDCTR,WW,39NH,5%,600MA,
CER,SM,CHIP
L310 2415429H28 IDCTR,WW,39NH,5%,600MA,
CER,SM,CHIP
L501 2415429H23 IDCTR,WW,24NH,5%,700MA,
.135OHM,CER,SM,0603,CHIP
L502 2415429H30 IDCTR,WW,47NH,5%,600MA,
CER,SM,CHIP
Ref. Des. Part Number Description
L503 2414032F38 IDCTR,WW,220NH,5%,400MA,
.7OHM,CER,30 Q,630MHZ SRF,
SM,PB-FRE
L504 2414032F41 IDCTR,WW,390NH,10%,200MA,
1.5OHM,CER,40 Q,730MHZ SRF,
SM,PB-F
L505 2415429H39 IDCTR,WW,150NH,5%,280MA,
.92OHM,CER,SM,0603,CHIP
L506 2415429H39 IDCTR,WW,150NH,5%,280MA,
.92OHM,CER,SM,0603,CHIP
L507 2415427H36 IDCTR,WW,33NH,5%,400MA,
CER,SM,0402,CHIP
L508 2478390A22 IDCTR,WW,20NH,2%,.042OHM,
CER,14GHZ SRF,0402 CHIP
IDCTR
L509 2478390A11 IDCTR,WW,8.7NH,2%,.042OHM,
CER,14GHZ SRF,0402 CHIP
IDCTR
L511 2478057A14 IDCTR,WW,8.2NH,2%,.054OHM,
CER,46 Q,5.9GHZ SRF,PCMT,
8.2NH S
L601 2415429H43 IDCTR,WW,220NH,5%,300MA,
2.1OHM,CER,0 AWG,SM,0603,
CHIP
L602 2466505A01 CHIP INDUCTOR,CHIP,10UH,
5%,150MA,FERR,0 AWG,SM, PB-
FREE
L603 2466505A01 CHIP INDUCTOR,CHIP,10UH,
5%,150MA,FERR,0 AWG,SM, PB-
FREE
L604 2414032D16 IDCTR,WW,120NH,5%,800MA,
.26OHM,CER,42 Q,1GHZ SRF,
SM,PB-FREE
L605 2414017Q54 IDCTR,FXD,3.9UH,10%,30MA,
.9OHM,FERR,45 Q,38MHZ SRF,
SM,0805,P
L701 2415429H47 IDCTR,WW,390NH,5%,100MA,
CER,SM,CHIP
L720 2480646Z20 IDCTR,FXD,2.2UH,10%,15MA,
SM,MULTI-LAYER CHIP
L727 2480646Z20 IDCTR,FXD,2.2UH,10%,15MA,
SM,MULTI-LAYER CHIP
L728 2415429H47 IDCTR,WW,390NH,5%,100MA,
CER,SM,CHIP
L733 2480646Z20 IDCTR,FXD,2.2UH,10%,15MA,
SM,MULTI-LAYER CHIP
L735 2480646Z20 IDCTR,FXD,2.2UH,10%,15MA,
SM,MULTI-LAYER CHIP
Ref. Des. Part Number Description
L738 2480646Z20 IDCTR,FXD,2.2UH,10%,15MA,
SM,MULTI-LAYER CHIP
L741 2480646Z20 IDCTR,FXD,2.2UH,10%,15MA,
SM,MULTI-LAYER CHIP
L753 2415347H06 IDCTR,WW,2.2UH,5%,320MA,
1.2OHM,CER,SM,IDCTR,
2200NH
L802 2415429H26 IDCTR,WW,33NH,5%,600MA,
.22OHM,CER,SM,0603,CHIP
L806 2415429H47 IDCTR,WW,390NH,5%,100MA,
CER,SM,CHIP
L817 2414032F41 IDCTR,WW,390NH,10%,200MA,
1.5OHM,CER,40 Q,730MHZ SRF,
SM,PB-F
L821 2415429H47 IDCTR,WW,390NH,5%,100MA,
CER,SM,CHIP
L846 2414032F41 IDCTR,WW,390NH,10%,200MA,
1.5OHM,CER,40 Q,730MHZ SRF,
SM,PB-F
L901 2414017N10 IDCTR,CHIP,6.8NH,5%,600MA,
.22OHM,CER,10 Q,2.7GHZ SRF,
SM,0603
L902 2415429H37 IDCTR,WW,110NH,5%,300MA
.61OHM,CER,SM,0603,CHIP
L903 2414015A07 IDCTR,FXD,180NH,2%,750MA,
.77OHM,CER,25 Q,700MHZ SRF,
SM,1008
L904 2414017N18 IDCTR,CHIP,33NH,5%,600MA,
.71OHM,CER,12 Q,1.1GHZ
SRF,SM,0603
L905 2414017N16 IDCTR,CHIP,22NH,5%,600MA,
.54OHM,CER,12 Q,1.3GHZ SRF,
SM,0603
L906 2460591E24 IDCTR,AW,23.75NH,COIL 23.75
L907 2471968L13 IDCTR,AW,5.5NH,2%,4A,SM,
LOW PROFILE MINI SPR IDCTR
L908 2415428H01 IDCTR,AW,1.65NH,10%,1.6A,
AIR,2 TURNS,SM,AIR WOUND
IDCTR
L909 2471968L11 IDCTR,AW,13NH,2%,4A,
.0039OHM,AIR,5 TURNS,100 Q,
3GHZ SRF,SM,1
L910 2415385H03 IDCTR,AW,18.5NH,2%,4A,AIR,
SM
L1101 2415429H30 IDCTR,WW,47NH,5%,600MA,
CER,SM,CHIP
Ref. Des. Part Number Description
