Motorola APX 7000 Detailed Service Manual

Schematics, Boards Overlays, and Parts Lists: Transceiver (RF) Boards: UHF2/VHF 8-265
L1102 2415429H10 IDCTR,WW,6.8NH,5%,700MA,
.11OHM,CER,SM,0603,CHIP
L1103 2475393H01 IDCTR,COIL,4.7NH,2%,750MA,
.07OHM,SM,INDUCTOR, 4.7NH,
040
L1104 0613952R66 RES,MF,0OHM,5%,.0625W,SM,
0402,PB-FREE
L1108 2409348J04 IDCTR,5%,SM,AIR CORE 2214
L1114 2475394H01 IDCTR,COIL,11NH,2%,.14OHM,
SM,INDUCTOR, 11NH, 0402,
+/-2
L1203 2460591D81 IDCTR,AW,43NH,HI Q REELED
SUR MT AIR WOUND
L1209 2460591D81 IDCTR,AW,43NH,HI Q REELED
SUR MT AIR WOUND
L1211 2460591D81 IDCTR,AW,43NH,HI Q REELED
SUR MT AIR WOUND
L1301 2488090Y07 IDCTR,CHIP,3.3NH,5%,300MA,C
ER,SM,0402,MULAY PB FREE
L1302 2488090Y25 IDCTR,CHIP,100NH,5%,90MA,
CER,SM,0402,MULAY PB FREE
L1303 2414017P25 IDCTR,CHIP,100NH,5%,100MA,
5.5OHM,CER,8 Q,650MHZ SRF,
SM,0402
L1305 2475391H01 IDCTR,WW,18UH,2%,.27OHM,
INDUCTOR, 18 NH, CHIP, 0402, 2
L1306 2488090Y10 IDCTR,CHIP,5.6NH,5%,300MA,
CER,SM,0402,MULAY PB FREE
L1500 2414015A07 IDCTR,FXD,180NH,2%,750MA,
.77OHM,CER,25 Q,700MHZ
SRF,SM,1008
L1501 2415429H18 IDCTR,WW,15NH,5%,700MA,
.17OHM,CER,SM,0603,CHIP
L1502 2415429H03 IDCTR,WW,3.3NH,5%,700MA,
CER,SM,0603,CHIP
L1503 2415429H17 IDCTR,WW,12NH,5%,700MA,
.13OHM,CER,SM,0603,CHIP
L1504 2415429H02 IDCTR,WW,1.8NH,5%,700MA,
.045OHM,CER,SM,0603,CHIP
L1505 2460591E24 IDCTR,AW,23.75NH,COIL 23.75
L1507 2415385H01 IDCTR,AW,8NH,2%,4A,.0026OH
M,AIR,3 TURNS,RH,140 Q, 5GHZ
SRF,SM,8
L1510 2415429H37 IDCTR,WW,110NH,5%,300MA,
.61OHM,CER,SM,0603,CHIP
Ref. Des. Part Number Description
L1700 2471902Y05 IDCTR,AW,12.1NH,5%,4.4A,
.007OHM,4.3GHZ SRF,SM,
PB-FREE
L1701 2471902Y05 IDCTR,AW,12.1NH,5%,4.4A,
.007OHM,4.3GHZ SRF,SM,
PB-FREE
L1702 2471902Y05 IDCTR,AW,12.1NH,5%,4.4A,
.007OHM,4.3GHZ SRF,SM,
PB-FREE
L1908 2478057A06 IDCTR,WW,4.3NH,2%,.08OHM,
CER,30 Q,7.5GHZ SRF,PCMT,
4.3 NH S
L1909 2478057A23 IDCTR,WW,18NH,2%,.066OHM,
CER,41 Q,3.3GHZ SRF,PCMT,
18 NH SU
L1910 2478057A23 IDCTR,WW,18NH,2%,.066OHM,
CER,41 Q,3.3GHZ SRF,PCMT,
18 NH SU
L1912 2478057A05 IDCTR,WW,3.9NH,2%,.039OHM,
CER,35 Q,7.5GHZ SRF,PCMT,
3.9 NH
L1913 2478057A23 IDCTR,WW,18NH,2%,.066OHM,
CER,41 Q,3.3GHZ SRF,PCMT,
18 NH SU
L1914 2478057A23 IDCTR,WW,18NH,2%,.066OHM,
CER,41 Q,3.3GHZ SRF,PCMT,
18 NH SU
L1915 2478057A35 IDCTR,WW,47NH,2%,680MA,
.24OHM,CER,5GHZ SRF,SM,
0306 HI Q CH
L1916 2414017P14 IDCTR,CHIP,12NH,5%,300MA,
.6OHM,CER,9 Q,2GHZ SRF,SM,
0402,PB-F
L1917 2478057A36 IDCTR,WW,51NH,2%,660MA,
.28OHM,CER,5GHZ SRF,SM,
0306 HI Q CH
L1919 2414017P14 IDCTR,CHIP,12NH,5%,300MA,
.6OHM,CER,9 Q,2GHZ SRF,SM,
0402,PB-F
L1934 2478057A38 IDCTR,WW,72NH,2%,550MA,
.42OHM,CER,1.9GHZ SRF,SM,
0306 HI Q
L1935 2478057A26 IDCTR,WW,24NH,2%,.074OHM,
CER,42 Q,2.95GHZ SRF,PCMT,
24 NH S
L1936 2415429H01 IDCTR,WW,1.6NH,5%,700MA,
.03OHM,CER,SM,0603,CHIP
L1938 NOT PLACED –
Ref. Des. Part Number Description
M1 3275623B02 GSKT,CUST,PAD, THRM ELEC
M2 75009299001 PAD,THRM INTFC - CNDT,PAD,
THRM
M3 1104959T01 COATING-CONTACT
M101 2871616H01 CONN,N/A,GLD,CONNECTOR,
BPLUS
M103 3987977Y04 CONT,CONN,1CONT,ANT UNIV
4.5MM,UC 1.8
M104 NOT PLACED –
M105 3987977Y04 CONT,CONN,1CONT,ANT UNIV
4.5MM,UC 1.8
M106 NOT PLACED –
P101 2887818K05 RECTANGULAR CONNECTOR,
STKNG,MIX,40CONT,VERT,SMD
PASTE 1085674C03 PROD CONSUM,SLDR,T MELT =
217C
PCB 84012125001 PCB,XCVR,10 LAYER,BOARD,
PC, PORT VHF & UHF2
Q201 4813970A59 XSTR,FET GP PWR,P-CH,
ENHN,SM,SOT-23,20V,.4W,PB-
FREE
Q201 4805656W87 DIODE,VCTR, @ 15V,1SV279,
SOD-523/SC-79,SOD-523/SC-79
Q201 4813970A59 XSTR,FET GP PWR,P-CH,
ENHN,SM,SOT-23,20V,.4W,PB-
FREE
Q201 4805656W87 DIODE,VCTR, @ 15V,1SV279,
SOD-523/SC-79,SOD-523/SC-79
Q202 4813973A32 XSTR,BIP GP SS,NPN,SM,SC-70,
SMT,50V,.202W,100MA,PB-FREE
Q202 4813973A32 XSTR,BIP GP SS,NPN,SM,SC-70,
SMT,50V,.202W,100MA,PB-FREE
Q301 4813973A32 XSTR,BIP GP SS,NPN,SM,SC-70,
SMT,50V,.202W,100MA,PB-FREE
Q301 4813973A32 XSTR,BIP GP SS,NPN,SM,
SC-70,SMT,50V,.202W, 00MA,
PB-FREE
Q302 4813973M75 XSTR,BIP GP SS,PNP,BC858,
SOT-563,SMT,-30V,.357W,
-100MA,100MHZ
Q302 4813973M75 XSTR,BIP GP SS,PNP,BC858,
SOT-563,SMT,-30V,.357W,
-100MA,100MHZ
Q501 4813973M75 XSTR,BIP GP SS,PNP,BC858,
SOT-563,SMT,-30V,.357W,
-100MA,100MHZ
Ref. Des. Part Number Description
Q501 4813973M75 XSTR,BIP GP SS,PNP, BC858,
SOT-563,SMT,-30V, .357W,
-100MA,100MHZ
Q503 4885316E32 XSTR,BIP RF SML SGNL, SLCN,
BFR380F,SM,SMT,6V,380W, 80A,
14MHZ,TR
Q503 4885316E32 XSTR,BIP RF SML SGNL, SLCN,
BFR380F,SM,SMT,6V,380W, 80A,
14MHZ,TR
Q601 4813973A04 XSTR,BIP GP SS,NPN,TA13, SM,
SOT-23,SMT,30V,.225W, 300MA,
125MHZ,P
Q601 4813973A04 XSTR,BIP GP SS,NPN,TA13, SM,
SOT-23,SMT,30V,.225W, 300MA,
125MHZ,P
Q703 4813973M75 XSTR,BIP GP SS,PNP,BC858,
SOT-563,SMT,-30V,.357W,
-100MA,100MHZ
Q703 4813973M75 XSTR,BIP GP SS,PNP,BC858,
SOT-563,SMT,-30V,.357W,
-100MA,100MHZ
Q712 4813973M75 XSTR,BIP GP SS,PNP,BC858,
SOT-563,SMT,-30V,.357W,
-100MA,100MHZ
Q712 4813973M75 XSTR,BIP GP SS,PNP,BC858,
SOT-563,SMT,-30V,.357W,
-100MA,100MHZ
Q713 4805585Q32 XSTR,BIP RF SML SGNL,NPN,
NE662M04, SM,SOT-343,3.3V,
TRANSITO
Q713 4805585Q32 XSTR,BIP RF SML SGNL,NPN,
NE662M04,SM,SOT-343,3.3V,
TRANSITO
Q714 4889394V04 XSTR,FET GP SS,MOSFET,
N-CH,ENHN,SM,20V,.25W,
PB-FREE TWO FETS
Q714 4889394V04 XSTR,FET GP SS,MOSFET,
N-CH,ENHN,SM,20V,.25W,PB-
FREE TWO FETS
Q774 4885061Y01 XSTR,BIP RF SML SGNL,NPN,
SM,12GHZ
Q774 4885061Y01 XSTR,BIP RF SML SGNL,NPN,
SM,12GHZ
Q842 4805585Q32 XSTR,BIP RF SML SGNL,NPN,
NE662M04,SM,SOT-343,3.3V,
TRANSITO
Q842 4805585Q32 XSTR,BIP RF SML SGNL,NPN,
NE662M04,SM,SOT-343,3.3V,
TRANSITO
Ref. Des. Part Number Description

Motorola APX 7000 Specifications

General

Digital Technology	P25 Phase 1 and Phase 2
Emergency Button	Yes
Frequency Range	136-174 MHz (VHF), 380-470 MHz (UHF Range 1), 450-520 MHz (UHF Range 2), 764-870 MHz (700/800 MHz)
Display	Color LCD
Encryption	AES, DES
Water Resistance	IP67
GPS	Yes
Bluetooth	Yes
Operating Temperature	-30°C to +60°C
Weight	391 g (with standard battery)
