Motorola APX 7000 Detailed Service Manual

8-266 Schematics, Boards Overlays, and Parts Lists: Transceiver (RF) Boards: UHF2/VHF
Q901 5185633C90 AMP MDL,MODULE,RING, XSTR,
FET RF POWER, VHF
Q1101 4813973A32 XSTR,BIP GP SS,NPN,SM,
SC-70,SMT,50V,.202W,100MA,
PB-FREE
Q1102 4813973A32 XSTR,BIP GP SS,NPN,SM,
SC-70,SMT,50V,.202W,100MA,
PB-FREE
Q1103 4813970A59 XSTR,FET GP PWR,P-CH,
ENHN,SM,SOT-23,20V,.4W,PB-
FREE
Q1104 4813970A59 XSTR,FET GP PWR,P-CH,
ENHN,SM,SOT-23,20V,.4W,PB-
FREE
Q1105 NOT PLACED –
Q1500 5185633C92 AMP MDL,MODULE,RING, XSTR,
FET RF POWER, UHF
Q1920 4813973A32 XSTR,BIP GP SS,NPN,SM,
SC-70,SMT,50V,.202W,100MA,
PB-FREE
Q1922 4813973M75 XSTR,BIP GP SS,PNP,BC858,
SOT-563,SMT,-30V,.357W,
-100MA,100MHZ
R101 0613952R01 RES,MF,10KOHM,5%,.0625W,
SM,0402,200PPM/CEL,PB-FREE
R103 0613952R01 RES,MF,10KOHM,5%,.0625W,SM
,0402,200PPM/CEL,PB-FREE
R201 0613952R25 RES,MF,100KOHM,5%,.0625W,
SM,0402,200PPM/CEL,PB-FREE
R202 0613952Q89 RES,MF,4.7KOHM,5%,.0625W,
SM,0402,200PPM/CEL,PB-FREE
R301 0613952R22 RES,MF,75KOHM,5%,.0625W,SM
,0402,200PPM/CEL,PB-FREE
R302 0613952R27 RES,MF,120KOHM,5%,.0625W,
SM,0402,200PPM/CEL,PB-FREE
R303 0613952R01 RES,MF,10KOHM,5%,.0625W,SM
,0402,200PPM/CEL,PB-FREE
R304 0613952Q37 RES,MF,33OHM,5%,.0625W,SM,
0402,200PPM/CEL,PB-FREE
R305 0613952Q89 RES,MF,4.7KOHM,5%,.0625W,S
M,0402,200PPM/CEL,PB-FREE
R306 0613952Q25 RES,MF,10OHM,5%,.0625W,SM,
0402,200PPM/CEL,PB-FREE
R308 0613952Q25 RES,MF,10OHM,5%,.0625W,SM,
0402,200PPM/CEL,PB-FREE
R309 0613952Q25 RES,MF,10OHM,5%,.0625W,SM,
0402,200PPM/CEL,PB-FREE
Ref. Des. Part Number Description
R501 NOT PLACED –
R502 0613952Q45 RES,MF,68OHM,5%,.0625W,SM,
0402,200PPM/CEL,PB-FREE
R503 0613952R10 RES,MF,24KOHM,5%,.0625W,SM
,0402,200PPM/CEL,PB-FREE
R504 0613952Q85 RES,MF,3.3KOHM,5%,.0625W,
SM,0402,200PPM/CEL,PB-FREE
R505 0613952R31 RES,MF,180KOHM,5%,.0625W,
SM,0402,200PPM/CEL,PB-FREE
R506 0613952Q53 RES,MF,150OHM,5%,.0625W,SM,
0402,200PPM/CEL,PB-FREE
R507 0613952Q83 RES,MF,2.7KOHM,5%,.0625W,
SM,0402,200PPM/CEL,PB-FREE
R508 0613952Q41 RES,MF,47OHM,5%,.0625W,SM,
0402,200PPM/CEL,PB-FREE
R509 0613952Q25 RES,MF,10OHM,5%,.0625W,SM,
0402,200PPM/CEL,PB-FREE
R511 0613952Q13 RES,MF,3.3OHM,5%,.0625W,SM,
0402,200PPM/CEL,PB-FREE
R512 NOT PLACED –
R597 0613952R66 RES,MF,0OHM,5%,.0625W,SM,
0402,PB-FREE
R601 0613952Q41 RES,MF,47OHM,5%,.0625W,SM,
0402,200PPM/CEL,PB-FREE
R602 0613952Q63 RES,MF,390OHM,5%,.0625W,SM,
0402,200PPM/CEL,PB-FREE
R603 0613952R25 RES,MF,100KOHM,5%,.0625W,
SM,0402,200PPM/CEL,PB-FREE
R604 0613952Q63 RES,MF,390OHM,5%,.0625W,SM,
0402,200PPM/CEL,PB-FREE
R605 0613952R01 RES,MF,10KOHM,5%,.0625W,SM
,0402,200PPM/CEL,PB-FREE
R606 0613952R01 RES,MF,10KOHM,5%,.0625W,SM
,0402,200PPM/CEL,PB-FREE
R607 0613952R25 RES,MF,100KOHM,5%,.0625W,
SM,0402,200PPM/CEL,PB-FREE
R608 0613952R01 RES,MF,10KOHM,5%,.0625W,SM
,0402,200PPM/CEL,PB-FREE
R609 0613952Q81 RES,MF,2.2KOHM,5%,.0625W,
SM,0402,200PPM/CEL,PB-FREE
R610 0613952R25 RES,MF,100KOHM,5%,.0625W
,SM,0402,200PPM/CEL,PB-FREE
R611 0613952R01 RES,MF,10KOHM,5%,.0625W,SM
,0402,200PPM/CEL,PB-FREE
R612 0613952Q94 RES,MF,7.5KOHM,5%,.0625W,S
M,0402,200PPM/CEL,PB-FREE
Ref. Des. Part Number Description
R613 0613952Q82 RES,MF,2.4KOHM,5%,.0625W,
SM,0402,200PPM/CEL,PB-FREE
R614 0613952R66 RES,MF,0OHM,5%,.0625W,SM,
0402,PB-FREE
R615 NOT PLACED –
R616 NOT PLACED –
R617 NOT PLACED –
R618 NOT PLACED –
R619 NOT PLACED –
R620 NOT PLACED –
R621 NOT PLACED –
R623 NOT PLACED –
R624 NOT PLACED –
R698 0613952R66 RES,MF,0OHM,5%,.0625W,SM,
0402,PB-FREE
R699 0613952Q15 CER CHIP RES 3.9 OHM 5 0402
R701 0613952Q49 RES,MF,100OHM,5%,.0625W,SM,
0402,200PPM/CEL,PB-FREE
R702 0613952R66 RES,MF,0OHM,5%,.0625W,SM,
0402,PB-FREE
R703 0613952Q42 RES,MF,51OHM,5%,.0625W,SM,
0402,200PPM/CEL,PB-FREE
R704 0613952Q42 RES,MF,51OHM,5%,.0625W,SM,
0402,200PPM/CEL,PB-FREE
R705 0613952Q25 RES,MF,10OHM,5%,.0625W,SM,
0402,200PPM/CEL,PB-FREE
R706 0613952R66 RES,MF,0OHM,5%,.0625W,SM,
0402,PB-FREE
R707 0613952R66 RES,MF,0OHM,5%,.0625W,SM,
0402,PB-FREE
R708 0613952Q49 RES,MF,100OHM,5%,.0625W,SM,
0402,200PPM/CEL,PB-FREE
R709 0613952Q45 RES,MF,68OHM,5%,.0625W,SM,
0402,200PPM/CEL,PB-FREE
R710 0613952Q56 RES,MF,200OHM,5%,.0625W,SM,
0402,200PPM/CEL,PB-FREE
R711 0613952Q45 RES,MF,68OHM,5%,.0625W,SM,
0402,200PPM/CEL,PB-FREE
R712 0613952Q67 RES,MF,560OHM,5%,.0625W,SM,
0402,200PPM/CEL,PB-FREE
R713 0613952Q25 RES,MF,10OHM,5%,.0625W,SM,
0402,200PPM/CEL,PB-FREE
R714 0613952Q67 RES,MF,560OHM,5%,.0625W,SM,
0402,200PPM/CEL,PB-FREE
Ref. Des. Part Number Description
R721 0613952R01 RES,MF,10KOHM,5%,.0625W,SM
,0402,200PPM/CEL,PB-FREE
R729 0613952R09 RES,MF,22KOHM,5%,.0625W,SM
,0402,200PPM/CEL,PB-FREE
R743 0613952R17 RES,MF,47KOHM,5%,.0625W,SM
,0402,200PPM/CEL,PB-FREE
R745 0613952R09 RES,MF,22KOHM,5%,.0625W,SM
,0402,200PPM/CEL,PB-FREE
R751 0613952Q59 RES,MF,270OHM,5%,.0625W,SM,
0402,200PPM/CEL,PB-FREE
R752 0613952Q91 RES,MF,5.6KOHM,5%,.0625W,
SM,0402,200PPM/CEL,PB-FREE
R753 NOT PLACED –
R754 NOT PLACED –
R755 0613952R15 RES,MF,39KOHM,5%,.0625W,SM
,0402,200PPM/CEL,PB-FREE
R759 0613952Q69 RES,MF,680OHM,5%,.0625W,SM,
0402,200PPM/CEL,PB-FREE
R761 0613952Q57 RES,MF,220OHM,5%,.0625W,SM,
0402,200PPM/CEL,PB-FREE
R762 0613952R02 RES,MF,11KOHM,5%,.0625W,SM
,0402,200PPM/CEL,PB-FREE
R764 0613952Q75 RES,MF,1.2KOHM,5%,.0625W,
SM,0402,200PPM/CEL,PB-FREE
R767 0613952Q45 RES,MF,68OHM,5%,.0625W,SM,
0402,200PPM/CEL,PB-FREE
R772 0613952Q37 RES,MF,33OHM,5%,.0625W,SM,
0402,200PPM/CEL,PB-FREE
R773 0613952Q91 RES,MF,5.6KOHM,5%,.0625W,
SM,0402,200PPM/CEL,PB-FREE
R776 0613952Q39 RES,MF,39OHM,5%,.0625W,SM,
0402,200PPM/CEL,PB-FREE
R778 0613952Q55 RES,MF,180OHM,5%,.0625W,SM,
0402,200PPM/CEL,PB-FREE
R807 0613952R09 RES,MF,22KOHM,5%,.0625W,SM
,0402,200PPM/CEL,PB-FREE
R808 0613952R23 RES,MF,82KOHM,5%,.0625W,SM
,0402,200PPM/CEL,PB-FREE
R809 0613952Q91 RES,MF,5.6KOHM,5%,.0625W,
SM,0402,200PPM/CEL,PB-FREE
R811 0613952Q39 RES,MF,39OHM,5%,.0625W,SM,
0402,200PPM/CEL,PB-FREE
R812 0613952Q47 RES,MF,82OHM,5%,.0625W,SM,
0402,200PPM/CEL,PB-FREE
R813 0613952Q69 RES,MF,680OHM,5%,.0625W,SM,
0402,200PPM/CEL,PB-FREE
Ref. Des. Part Number Description

Motorola APX 7000 Specifications

General

Digital Technology	P25 Phase 1 and Phase 2
Emergency Button	Yes
Frequency Range	136-174 MHz (VHF), 380-470 MHz (UHF Range 1), 450-520 MHz (UHF Range 2), 764-870 MHz (700/800 MHz)
Display	Color LCD
Encryption	AES, DES
Water Resistance	IP67
GPS	Yes
Bluetooth	Yes
Operating Temperature	-30°C to +60°C
Weight	391 g (with standard battery)
