Motorola APX 7000 Detailed Service Manual

Schematics, Boards Overlays, and Parts Lists: Transceiver (RF) Boards: UHF2/VHF 8-267
R815 0613952Q34 RES,MF,24OHM,5%,.0625W,SM,
0402,200PPM/CEL,PB-FREE
R818 0613952Q23 RES,MF,8.2OHM,5%,.0625W,SM,
0402,200PPM/CEL,PB-FREE
R819 0613952Q59 RES,MF,270OHM,5%,.0625W,SM,
0402,200PPM/CEL,PB-FREE
R822 0613952R08 RES,MF,20KOHM,5%,.0625W,SM
,0402,200PPM/CEL,PB-FREE
R823 0613952R19 RES,MF,56KOHM,5%,.0625W,SM
,0402,200PPM/CEL,PB-FREE
R827 0613952Q92 RES,MF,6.2KOHM,5%,.0625W,S
M,0402,200PPM/CEL,PB-FREE
R832 0613952Q29 RES,MF,15OHM,5%,.0625W,SM,
0402,200PPM/CEL,PB-FREE
R833 0613952Q49 RES,MF,100OHM,5%,.0625W,SM,
0402,200PPM/CEL,PB-FREE
R840 0613952Q29 RES,MF,15OHM,5%,.0625W,SM,
0402,200PPM/CEL,PB-FREE
R848 0613952Q29 RES,MF,15OHM,5%,.0625W,SM,
0402,200PPM/CEL,PB-FREE
R849 0613952Q67 RES,MF,560OHM,5%,.0625W,SM,
0402,200PPM/CEL,PB-FREE
R901 0613952R01 RES,MF,10KOHM,5%,.0625W,SM
,0402,200PPM/CEL,PB-FREE
R902 0613952R01 RES,MF,10KOHM,5%,.0625W,SM
,0402,200PPM/CEL,PB-FREE
R903 0613952R01 RES,MF,10KOHM,5%,.0625W,SM
,0402,200PPM/CEL,PB-FREE
R904 0613952R13 RES,MF,33KOHM,5%,.0625W,SM
,0402,200PPM/CEL,PB-FREE
R905 0613952Q73 RES,MF,1KOHM,5%,.0625W,SM,
0402,200PPM/CEL,PB-FREE
R906 0613952Q61 RES,MF,330OHM,5%,.0625W,SM,
0402,200PPM/CEL,PB-FREE
R1101 0613952R25 RES,MF,100KOHM,5%,.0625W,
SM,0402,200PPM/CEL,PB-FREE
R1102 0613952R25 RES,MF,100KOHM,5%,.0625W,
SM,0402,200PPM/CEL,PB-FREE
R1103 `06009259001 RES,SHUNT,.02OHM,.25W,SMD,
LOW RESISTANCE THK FLM
RES
R1104 0613952Q49 RES,MF,100OHM,5%,.0625W,SM,
0402,200PPM/CEL,PB-FREE
R1105 0613952Q49 RES,MF,100OHM,5%,.0625W,SM,
0402,200PPM/CEL,PB-FREE
Ref. Des. Part Number Description
R1106 0613952Q25 RES,MF,10OHM,5%,.0625W,SM,
0402,200PPM/CEL,PB-FREE
R1107 0613952Q45 RES,MF,68OHM,5%,.0625W,SM,
0402,200PPM/CEL,PB-FREE
R1108 0613952R23 RES,MF,82KOHM,5%,.0625W,SM
,0402,200PPM/CEL,PB-FREE
R1110 0613952R01 RES,MF,10KOHM,5%,.0625W,SM
,0402,200PPM/CEL,PB-FREE
R1112 NOT PLACED –
R1114 0613952Q49 RES,MF,100OHM,5%,.0625W,SM,
0402,200PPM/CEL,PB-FREE
R1115 0613952Q49 RES,MF,100OHM,5%,.0625W,SM,
0402,200PPM/CEL,PB-FREE
R1116 0613952R01 RES,MF,10KOHM,5%,.0625W,SM
,0402,200PPM/CEL,PB-FREE
R1117 0613952R22 RES,MF,75KOHM,5%,.0625W,SM
,0402,200PPM/CEL,PB-FREE
R1121 0613952R12 RES,MF,30KOHM,5%,.0625W,SM
,0402,200PPM/CEL,PB-FREE
R1122 0613952R22 RES,MF,75KOHM,5%,.0625W,SM
,0402,200PPM/CEL,PB-FREE
R1124 0613952Q42 RES,MF,51OHM,5%,.0625W,SM,
0402,200PPM/CEL,PB-FREE
R1125 0613952R17 RES,MF,47KOHM,5%,.0625W,SM
,0402,200PPM/CEL,PB-FREE
R1126 0613952R08 RES,MF,20KOHM,5%,.0625W,SM
,0402,200PPM/CEL,PB-FREE
R1127 0613952R08 RES,MF,20KOHM,5%,.0625W,SM
,0402,200PPM/CEL,PB-FREE
R1128 0613952R01 RES,MF,10KOHM,5%,.0625W,SM
,0402,200PPM/CEL,PB-FREE
R1129 NOT PLACED –
R1130 NOT PLACED –
R1135 0613952R66 RES,MF,0OHM,5%,.0625W,SM,
0402,PB-FREE
R1136 0613952R01 RES,MF,10KOHM,5%,.0625W,SM
,0402,200PPM/CEL,PB-FREE
R1137 0613952R01 RES,MF,10KOHM,5%,.0625W,SM
,0402,200PPM/CEL,PB-FREE
R1138 0613952R25 RES,MF,100KOHM,5%,.0625W,
SM,0402,200PPM/CEL,PB-FREE
R1139 0613952R25 RES,MF,100KOHM,5%,.0625W,
SM,0402,200PPM/CEL,PB-FREE
R1140 0613952R25 RES,MF,100KOHM,5%,.0625W,
SM,0402,200PPM/CEL,PB-FREE
Ref. Des. Part Number Description
R1141 0613952R42 RES,MF,510KOHM,5%,.0625W,
SM,0402,200PPM/CEL,PB-FREE
R1142 0613952R25 RES,MF,100KOHM,5%,.0625W,
SM,0402,200PPM/CEL,PB-FREE
R1143 0613952R25 RES,MF,100KOHM,5%,.0625W,
SM,0402,200PPM/CEL,PB-FREE
R1144 0613952R25 RES,MF,100KOHM,5%,.0625W,
SM,0402,200PPM/CEL,PB-FREE
R1145 0613952R25 RES,MF,100KOHM,5%,.0625W,
SM,0402,200PPM/CEL,PB-FREE
R1146 0613952R25 RES,MF,100KOHM,5%,.0625W,
SM,0402,200PPM/CEL,PB-FREE
R1151 0613952R01 RES,MF,10KOHM,5%,.0625W,SM
,0402,200PPM/CEL,PB-FREE
R1152 0613952R01 RES,MF,10KOHM,5%,.0625W,SM
,0402,200PPM/CEL,PB-FREE
R1154 0613952R01 RES,MF,10KOHM,5%,.0625W,SM
,0402,200PPM/CEL,PB-FREE
R1160 0613952R03 RES,MF,12KOHM,5%,.0625W,SM
,0402,200PPM/CEL,PB-FREE
R1161 0613952R01 RES,MF,10KOHM,5%,.0625W,SM
,0402,200PPM/CEL,PB-FREE
R1162 0613952R29 RES,MF,150KOHM,5%,.0625W,
SM,0402,200PPM/CEL,PB-FREE
R1163 0613952R01 RES,MF,10KOHM,5%,.0625W,SM
,0402,200PPM/CEL,PB-FREE
R1164 0613952R01 RES,MF,10KOHM,5%,.0625W,SM
,0402,200PPM/CEL,PB-FREE
R1165 0613952Q56 RES,MF,200OHM,5%,.0625W,SM,
0402,200PPM/CEL,PB-FREE
R1166 0613952Q56 RES,MF,200OHM,5%,.0625W,SM,
0402,200PPM/CEL,PB-FREE
R1167 0613952R01 RES,MF,10KOHM,5%,.0625W,SM
,0402,200PPM/CEL,PB-FREE
R1168 0613952R66 RES,MF,0OHM,5%,.0625W,SM,
0402,PB-FREE
R1169 0613952P52 RES,MF,340KOHM,1%,.0625W,
SM,0402,200PPM/CEL,PB-FREE
R1170 0613952N88 RES,MF,80.6KOHM,1%,.0625W,
SM,0402,200PPM/CEL,PB-FREE
R1171 0613952R66 RES,MF,0OHM,5%,.0625W,SM,
0402,PB-FREE
R1172 0613952Q89 RES,MF,4.7KOHM,5%,.0625W,
SM,0402,200PPM/CEL,PB-FREE
R1174 0613952R01 RES,MF,10KOHM,5%,.0625W,SM
,0402,200PPM/CEL,PB-FREE
Ref. Des. Part Number Description
R1175 0613952R66 RES,MF,0OHM,5%,.0625W,SM,
0402,PB-FREE
R1176 0613952Q73 RES,MF,1KOHM,5%,.0625W,SM,
0402,200PPM/CEL,PB-FREE
R1177 0613952R66 RES,MF,0OHM,5%,.0625W,SM,
0402,PB-FREE
R1178 0613952R01 RES,MF,10KOHM,5%,.0625W,SM
,0402,200PPM/CEL,PB-FREE
R1179 0613952R66 RES,MF,0OHM,5%,.0625W,SM,
0402,PB-FREE
R1180 0613952R66 RES,MF,0OHM,5%,.0625W,SM,
0402,PB-FREE
R1181 NOT PLACED –
R1182 0613952R01 RES,MF,10KOHM,5%,.0625W,SM
,0402,200PPM/CEL,PB-FREE
R1183 0613952Q73 RES,MF,1KOHM,5%,.0625W,SM,
0402,200PPM/CEL,PB-FREE
R1184 0613952Q81 RES,MF,2.2KOHM,5%,.0625W,
SM,0402,200PPM/CEL,PB-FREE
R1304 NOT PLACED –
R1307 0613952Q73 RES,MF,1KOHM,5%,.0625W,SM,
0402,200PPM/CEL,PB-FREE
R1500 0613952R66 RES,MF,0OHM,5%,.0625W,SM,
0402,PB-FREE
R1501 NOT PLACED –
R1502 0613952Q73 RES,MF,1KOHM,5%,.0625W,SM,
0402,200PPM/CEL,PB-FREE
R1503 0613952R06 RES,MF,16KOHM,5%,.0625W,SM
,0402,200PPM/CEL,PB-FREE
R1504 0613952R13 RES,MF,33KOHM,5%,.0625W,SM
,0402,200PPM/CEL,PB-FREE
R1505 0613952R01 RES,MF,10KOHM,5%,.0625W,SM
,0402,200PPM/CEL,PB-FREE
R1506 0613952R04 RES,MF,13KOHM,5%,.0625W,SM
,0402,200PPM/CEL,PB-FREE
R1906 0613952R01 RES,MF,10KOHM,5%,.0625W,SM
,0402,200PPM/CEL,PB-FREE
R1907 0613952R01 RES,MF,10KOHM,5%,.0625W,SM
,0402,200PPM/CEL,PB-FREE
R1908 0613952R01 RES,MF,10KOHM,5%,.0625W,SM
,0402,200PPM/CEL,PB-FREE
R1909 0613952R01 RES,MF,10KOHM,5%,.0625W,SM
,0402,200PPM/CEL,PB-FREE
R1910 0613952Q73 RES,MF,1KOHM,5%,.0625W,SM,
0402,200PPM/CEL,PB-FREE
Ref. Des. Part Number Description
