Motorola APX 7000 Detailed Service Manual

8-268 Schematics, Boards Overlays, and Parts Lists: Transceiver (RF) Boards: UHF2/VHF
R1911 0613952Q73 RES,MF,1KOHM,5%,.0625W,SM,
0402,200PPM/CEL,PB-FREE
R1921 0613952R22 RES,MF,75KOHM,5%,.0625W,SM
,0402,200PPM/CEL,PB-FREE
R1922 0613952R27 RES,MF,120KOHM,5%,.0625W,S
M,0402,200PPM/CEL,PB-FREE
R1923 0613952R01 RES,MF,10KOHM,5%,.0625W,SM
,0402,200PPM/CEL,PB-FREE
R1924 0613952Q37 RES,MF,33OHM,5%,.0625W,SM,
0402,200PPM/CEL,PB-FREE
R1925 0613952Q11 RES,MF,2.7OHM,5%,.0625W,SM,
0402,200PPM/CEL,PB-FREE
R1935 0613952Q75 RES,MF,1.2KOHM,5%,.0625W,
SM,0402,200PPM/CEL,PB-FREE
R1936 0613952R66 RES,MF,0OHM,5%,.0625W,SM,
0402,PB-FREE
SH1 2675871B01 SHLD,STL,SN PLT,SHIELD, FGU
SH10 2675859B01 SHLD,STL,SN PLT,SHIELD, OUT
MATCH
SH11 2675877B01 SHLD,STL,SN PLT,SHIELD, ALC
SH12 2675933B01 SHLD,SHIELD, IF AMP
SH13 2675870B01 SHLD,STL,SN PLT,SHIELD, HAR
FLTR
SH14 2671905H01 SHLD,CAN,STL,15.32MMLG,
8.3MMW,2.35MM,SHIELD,
REGLTR
SH2 2675872B01 SHLD,STL,SN PLT,SHIELD, XTAL
SH3 2675873B01 SHLD,STL,SN PLT,SHIELD,
ABACUS
SH4 2675878B01 SHLD,STL,SN PLT,SHIELD,
FRNT END
SH5 2675879B01 SHLD,STL,SN PLT,SHIELD,
DRVR PA
SH6 2675876B01 SHLD,STL,SN PLT,SHIELD, VCO
SH7 2675874B01 SHLD,STL,SN PLT,SHIELD, MXR
SH8 2675932B01 SHLD,SHIELD, 2ND LO VCO
SH9 2675934B01 SHLD,SHIELD, DC
T503 2575851B01 XFMR,BALUN,RF XFMR BALUN
T504 2575851B01 XFMR,BALUN,RF XFMR BALUN
T505 2575851B01 XFMR,BALUN,RF XFMR BALUN
U101 5105443X07 IC,SERIAL EEPROM,32/64 KBIT,
DFN,EEPROM 32KBIT SER SPI
BUS
Ref. Des. Part Number Description
U200 5188493T01 IC,VREG/SWG,LP2989,SM,MINI
SO-8 HI PRCN REG 5V
U201 5175771A99 IC,LNR V REGLTR,FXD,100MA,
VFBGA,LOW NOISE, 100MA
LINEAR REGL
U202 5175772B02 IC,LNR V REGLTR,FXD,1.8V,
100MA,VFBGA,LINEAR REGLTR
100MA 1.8
U203 5175772B01 IC,LNR V REGLTR,FXD,1.5V,
350MA,VFBGA,LINEAR V
REGLTR 350MA
U302 4885316E32 XSTR,BIP RF SML SGNL,
SLCN,BFR380F,SM,SMT,6V,380
W,80A,14MHZ,TR
U501 5180428L15 SW,RF SWITCH,SPDT,SMT,6W,
3V
U502 5103535B53 IC,INVTR,DL,NC7WZ04L6X,
2PER PKG,SC70
U506 5164852H82 IC,MXR,IC, MIXER/ BFR
U601 5102495J14 IC,IF,IF DIGITILIZING
SUBSYSTEM IC,AD9864,QFN
U602 4885316E32 XSTR,BIP RF SML SGNL, SLCN,
BFR380F,SM,SMT,6V,380W,80A,
14MHZ,TR
U603 5109522E84 IC,DUAL SCHMITT TRIG MICRO
PAK
U604 5109522E84 IC,DUAL SCHMITT TRIG MICRO
PAK
U605 5164852H16 IC,TRANSLATING,2PER PKG,
LVC2T45,TRANSCEIVER W/
VOLTAGE TRANSLATI
U606 5164852H16 IC,TRANSLATING,2PER PKG
,LVC2T45,TRANSCEIVER W/
VOLTAGE TRANSLATI
U607 5186311J24 IC,BFR,1PER PKG,NC7SZ125,
ACTIVE HIGH,BFR,3ST,SM,5.5
U702 5164015H28 IC,CUST,MULTI PROTOCOL/
BAND TRANSCVR IC,SM,BGA,
TRIDENT, INTEG
U703 5175772B06 IC,SERIAL INTERFACE I/O
EXPANDER,QFN,24BITS,28-
PORT I/O EXPA
U708 5171972L01 IC,SW,SP3T RF SW
U709 5171972L01 IC,SW,SP3T RF SW
U710 5171972L01 IC,SW,SP3T RF SW
U711 5171972L01 IC,SW,SP3T RF SW
Ref. Des. Part Number Description
U746 4805218N63 XSTR,GEN PURPOSE SMALL
SIG,SOT-323,BROADBAND &
XSTR BF
U901 5175143H01 IC,WIDE SPLY RANGE OP AMP
U902 51012101001 IC,SM,VHF/UHF/800/900 MHZ
LDMOS DRVR IC
U1101 5188032U43 IC,SENSING CIRCUIT,INA138,
SM,SOT-23/5,1PER PKG,PB
FREE
U1102 5175772B03 RF SWITCH,RF SWITCH,10W,
RECONFIGURABLE 10W SP5T/
3T RF SWITC
U1103 5185070Y01 IC,TEMP SENS
U1104 5185941F56 IC,OP AMP,1PER PKG,RAIL-
RAIL,SOIC,IC SNGL LV LP OP
AMP
U1105 5180390L83 IC,CNTLR,SM,1PER PKG
U1106 5175772B05 IC,LTC5532ES6,SOT-23,1PER
PKG,PRCN RF DET
U1109 5114007M32 IC,OR,2PER PKG,SM,US8,PB-
FREE
U1110 5180428L15 SW,RF SWITCH,SPDT,SMT,
6W,3V
U1111 5175771A26 IC,SW,50OHM,CMOS FET SW
SPDT, 10WATTS
U1112 5175772B04 IC,HMC468LP3E,QFN,1 DB LSB
GAAS MMIC ATTEN
U1113 5185941F56 IC,OP AMP,1PER PKG,RAIL-
RAIL,SOIC,IC SNGL LV LP OP
AMP
U1114 5185941F56 IC,OP AMP,1PER PKG,RAIL-
RAIL,SOIC,IC SNGL LV LP OP
AMP
U1116 5109522E93 GATE,OR,SN74LVC1G32YZPR,
1PER PKG,SM,2 INPUT IN NANO
PKG
U1117 5103535B53 IC,INVTR,DL,NC7WZ04L6X,2PE
R PKG,SC70
U1118 5188085K11 IC,NAND,SINGLE 2 INPUT,
SN74LVC1G00YZPR,SM,GATE,P
OS,5 DSBGA,PB-
U1119 5186311J53 IC,AND,DUAL 2-INPUT AND
GATE,NC7WZ08,2PER PKG,SM,
MSOP
U1121 5114000B52 IC,XOR,LOGIC LEVEL SHIFTER,
1PER PKG,SM,SOT-353,PB-
FREE
Ref. Des. Part Number Description
U1122 5180428L15 SW,RF SWITCH,SPDT,SMT,6W,
3V
U1123 5188085K11 IC,NAND,SINGLE 2 INPUT,
SN74LVC1G00YZPR,SM,GATE,P
OS,5 DSBGA,PB-
U1125 5175206H01 IC,DAC,W/ 5 PPM/C INT REF
U1126 5109817F77 IC,COMPTR,LMV7275,SC70-5
U1127 5171779H01 IC,ANLG SW,SC70,SC70-6, 1PER
PKG,SPDT ANLG SW
U1128 5188085K11 IC,NAND,SINGLE 2 INPUT,
SN74LVC1G00YZPR,SM,GATE,P
OS,5 DSBGA,PB-
U1129 5175143H01 IC,WIDE SPLY RANGE OP AMP
U1130 5175143H01 IC,WIDE SPLY RANGE OP AMP
U1131 5109817F77 IC,COMPTR,LMV7275,SC70-5
U1132 5114007M28 IC,F-F/D,1PER PKG,17SZ74,
N-I,SM,SOIC8,PB-FREE
U1133 5171779H01 IC,ANLG SW,SC70,SC70-6, 1PER
PKG,SPDT ANLG SW
U1136 5109522E94 GATE,AND,1PER PKG,SM,2
INPUT IN NANO PKG
U1137 5164852H16 IC,TRANSLATING,2PER PKG,
LVC2T45,TRANSCEIVER W/
VOLTAGE TRANSLATI
U1138 5164852H16 IC,TRANSLATING,2PER PKG,
LVC2T45,TRANSCEIVER W/
VOLTAGE TRANSLATI
U1139 5164852H16 IC,TRANSLATING,2PER PKG,
LVC2T45,TRANSCEIVER W/
VOLTAGE TRANSLATI
U1140 5171779H01 IC,ANLG SW,SC70,SC70-6,1PER
PKG,SPDT ANLG SW
U1141 5185941F56 IC,OP AMP,1PER PKG,RAIL-
RAIL,SOIC,IC SNGL LV LP OP
AMP
U1142 5185941F56 IC,OP AMP,1PER PKG,RAIL-
RAIL,SOIC,IC SNGL LV LP OP
AMP
U1143 5185941F56 IC,OP AMP,1PER PKG,RAIL-
RAIL,SOIC,IC SNGL LV LP OP
AMP
U1144 5171779H01 IC,ANLG SW,SC70,SC70-6, 1PER
PKG,SPDT ANLG SW
U1145 5171779H01 IC,ANLG SW,SC70,SC70-6,1PER
PKG,SPDT ANLG SW
Ref. Des. Part Number Description

Motorola APX 7000 Specifications

General

Digital Technology	P25 Phase 1 and Phase 2
Emergency Button	Yes
Frequency Range	136-174 MHz (VHF), 380-470 MHz (UHF Range 1), 450-520 MHz (UHF Range 2), 764-870 MHz (700/800 MHz)
Display	Color LCD
Encryption	AES, DES
Water Resistance	IP67
GPS	Yes
Bluetooth	Yes
Operating Temperature	-30°C to +60°C
Weight	391 g (with standard battery)
