Motorola APX 7000 Detailed Service Manual

Schematics, Boards Overlays, and Parts Lists: Transceiver (RF) Boards: UHF2/VHF 8-269
U1146 5109522E93 GATE,OR,SN74LVC1G32YZPR,
1PER PKG,SM,2 INPUT IN NANO
PKG
U1147 5109522E94 GATE,AND,1PER PKG,SM,2
INPUT IN NANO PKG
U1148 5185941F56 IC,OP AMP,1PER PKG,RAIL-
RAIL,SOIC,IC SNGL LV LP OP
AMP
U1304 5105739X13 IC,AMP,SIGE,QFN,QFN,18DB,
1.57GHZMIN,1.57GHZMAX,.9DB,
SIGE GPS LO
U1500 51012101001 IC,SM,VHF/UHF/800/900 MHZ
LDMOS DRVR IC
U1501 5175143H01 IC,WIDE SPLY RANGE OP AMP
U1932 4885316E32 XSTR,BIP RF SML SGNL,SLCN,
BFR380F,SM,SMT,6V,380W,80A,
14MHZ,TR
VR101 4813977M29 DIODE,VREF,MBZ5250,SM,SOT-
23,20V,.225W,ZEN
VR200 4813977M29 DIODE,VREF,MBZ5250,SM,SOT-
23,20V,.225W,ZEN
VR602 4805656W87 DIODE,VCTR, @ 15V,1SV279,
SOD-523/SC-79,SOD-523/SC-79
VR1905 4815096H01 DIODE,VCTR, @ 10V,1SV305G,
SM,VCTR DIODE 1SV305
VR1906 4815096H01 DIODE,VCTR, @ 10V,1SV305G,
SM,VCTR DIODE 1SV305
VR1907 4815096H01 DIODE,VCTR, @ 10V,1SV305G,
SM,VCTR DIODE 1SV305
VR1908 4815096H01 DIODE,VCTR, @ 10V,1SV305G,
SM,VCTR DIODE 1SV305
VR1910 4815096H01 DIODE,VCTR, @ 10V,1SV305G,
SM,VCTR DIODE 1SV305
VR1920 4815096H01 DIODE,VCTR, @ 10V,1SV305G,
SM,VCTR DIODE 1SV305
Y701 4871886H01 OSC,TCXO,16.8MHZ,SM,16.8
MHZ VCTXO .8PPM
Y704 5164852H68 OSC,VOLTAGE CONTROLLED,
411MHZ MAX,270MHZ MIN,SM,
M9LX7WX2.5H,I
Y705 5164852H66 OSC,VOLTAGE CONTROLLED,
520MHZ MAX,380MHZ MIN,SM,
M9LX7WX2.5H,I
Y706 NOT PLACED –
Y707 5164852H67 OSC,VOLTAGE CONTROLLED,
824MHZ MAX,245MHZ MIN,SM,
M9LX7WX2.5H,I
Ref. Des. Part Number Description

Motorola APX 7000 Specifications

General

Digital Technology	P25 Phase 1 and Phase 2
Emergency Button	Yes
Frequency Range	136-174 MHz (VHF), 380-470 MHz (UHF Range 1), 450-520 MHz (UHF Range 2), 764-870 MHz (700/800 MHz)
Display	Color LCD
Encryption	AES, DES
Water Resistance	IP67
GPS	Yes
Bluetooth	Yes
Operating Temperature	-30°C to +60°C
Weight	391 g (with standard battery)
