Schematics, Boards Overlays, and Parts Lists: VOCON Boards 8-297

MNCN6200A VOCON Board Parts List

Ref.

Des.

Part Number Description

C1001 NOT PLACED –

C1002 NOT PLACED –

C1003 NOT PLACED –

C1004 NOT PLACED –

C1005 NOT PLACED –

C1006 NOT PLACED –

C2101 NOT PLACED –

C2102 NOT PLACED –

C2103 2113944A31 CAP,CHIP,33PF,+5%,-10%, 50V-

DC,0402,C0G,-55DEG CMIN,

125DEG CMAX,P

C2104 2113946B04 CAP,CHIP,.1UF,+10%,-10%, 10V-

DC,0402,X5R,-55DEG CMIN,

85DEG CMAX

C2105 2113944A46 CAP,CHIP,330PF,+5%,-10%, 50V-

DC,0402,C0G,-55DEG

CMIN,125DEG CMAX

C2106 NOT PLACED –

C2107 2113944A46 CAP,CHIP,330PF,+5%,-10%, 50V-

DC,0402,C0G,-55DEG

CMIN,125DEG CMAX

C2108 2113944A46 CAP,CHIP,330PF,+5%,-10%, 50V-

DC,0402,C0G,-55DEG

CMIN,125DEG CMAX

C2109 2113944A46 CAP,CHIP,330PF,+5%,-10%, 50V-

DC,0402,C0G,-55DEG

CMIN,125DEG CMAX

C2110 2113944A46 CAP,CHIP,330PF,+5%,-10%, 50V-

DC,0402,C0G,-55DEG

CMIN,125DEG CMAX

C2111 2113944A46 CAP,CHIP,330PF,+5%,-10%, 50V-

DC,0402,C0G,-55DEG

CMIN,125DEG CMAX

C2112 NOT PLACED –

C2113 2113944A46 CAP,CHIP,330PF,+5%,-10%, 50V-

DC,0402,C0G,-55DEG

CMIN,125DEG CMAX

C2201 2113946B04 CAP,CHIP,.1UF,+10%,-10%, 10V-

DC,0402,X5R,-55DEG

CMIN,85DEG CMAX

C2202 2113946B04 CAP,CHIP,.1UF,+10%,-10%, 10V-

DC,0402,X5R,-55DEG

CMIN,85DEG CMAX

C2203 2113946B04 CAP,CHIP,.1UF,+10%,-10%, 10V-

DC,0402,X5R,-55DEG

CMIN,85DEG CMAX

C2204 NOT PLACED –

C2205 NOT PLACED –

C2206 NOT PLACED –

C2207 NOT PLACED –

C2208 NOT PLACED –

C2209 NOT PLACED –

C2210 NOT PLACED –

C2211 2113946B04 CAP,CHIP,.1UF,+10%,-10%, 10V-

DC,0402,X5R,-55DEG CMIN,

85DEG CMAX

C2212 2113946B04 CAP,CHIP,.1UF,+10%,-10%, 10V-

DC,0402,X5R,-55DEG CMIN,

85DEG CMAX

C2213 2113946B04 CAP,CHIP,.1UF,+10%,-10%, 10V-

DC,0402,X5R,-55DEG CMIN,

85DEG CMAX

C2214 2113946B04 CAP,CHIP,.1UF,+10%,-10%, 10V-

DC,0402,X5R,-55DEG CMIN,

85DEG CMAX

C2215 2113946B04 CAP,CHIP,.1UF,+10%,-10%, 10V-

DC,0402,X5R,-55DEG CMIN,

85DEG CMAX

C2216 2113946B04 CAP,CHIP,.1UF,+10%,-10%, 10V-

DC,0402,X5R,-55DEG CMIN,

85DEG CMAX

C2301 NOT PLACED –

C2302 NOT PLACED –

C2303 NOT PLACED –

C2304 NOT PLACED –

C2305 NOT PLACED –

C2306 NOT PLACED –

C2307 NOT PLACED –

C2308 NOT PLACED –

C2309 NOT PLACED –

C2310 NOT PLACED –

C2311 NOT PLACED –

C2312 NOT PLACED –

C2313 NOT PLACED –

C2314 NOT PLACED –

Ref.

Des.

Part Number Description

C2315 NOT PLACED –

C2316 NOT PLACED –

C2317 NOT PLACED –

C2318 NOT PLACED –

C2319 NOT PLACED –

C2320 NOT PLACED –

C2321 NOT PLACED –

C2322 NOT PLACED –

C2323 2113944A46 CAP,CHIP,330PF,+5%,-10%, 50V-

DC,0402,C0G,-55DEG

CMIN,125DEG CMAX

C2324 2113944A46 CAP,CHIP,330PF,+5%,-10%, 50V-

DC,0402,C0G,-55DEG

CMIN,125DEG CMAX

C2325 2113944A46 CAP,CHIP,330PF,+5%,-10%, 50V-

DC,0402,C0G,-55DEG

CMIN,125DEG CMAX

C3001 NOT PLACED –

C3002 NOT PLACED –

C3003 NOT PLACED –

C3004 NOT PLACED –

C3005 NOT PLACED –

C3006 NOT PLACED –

C3007 NOT PLACED –

C3008 NOT PLACED –

C3009 NOT PLACED –

C4001 2113946B04 CAP,CHIP,.1UF,+10%,-10%, 10V-

DC,0402,X5R,-55DEG

CMIN,85DEG CMAX

C4002 2113944A31 CAP,CHIP,33PF,+5%,-10%, 50V-

DC,0402,C0G,-55DEG

CMIN,125DEG CMAX,P

C4003 2113944A46 CAP,CHIP,330PF,+5%,-10%, 50V-

DC,0402,C0G,-55DEG

CMIN,125DEG CMAX

C4004 2113946B04 CAP,CHIP,.1UF,+10%,-10%, 10V-

DC,0402,X5R,-55DEG

CMIN,85DEG CMAX

C4005 2113946B04 CAP,CHIP,.1UF,+10%,-10%, 10V-

DC,0402,X5R,-55DEG

CMIN,85DEG CMAX

C4006 2113946B04 CAP,CHIP,.1UF,+10%,-10%, 10V-

DC,0402,X5R,-55DEG

CMIN,85DEG CMAX

Ref.

Des.

Part Number Description

C4007 2113946B04 CAP,CHIP,.1UF,+10%,-10%, 10V-

DC,0402,X5R,-55DEG

CMIN,85DEG CMAX

C5001 2113945A09 CAP,CHIP,1000PF,+10%,-10%,

50V-DC,0402,X7R,-55DEG

CMIN,125DEG CM

C5002 2113945B02 CAP,CHIP,.01UF,+10%,-10%, 25V-

DC,0402,X7R,-55DEG

CMIN,125DEG CMA

C5003 2113946B04 CAP,CHIP,.1UF,+10%,-10%, 10V-

DC,0402,X5R,-55DEG CMIN,

85DEG CMAX

C5004 2113956B33 CAP,FXD,2.2UF,+10%,-10%, 16V-

DC,0603,X5R,-55DEG

CMIN,85DEG CMAX

C5005 2113946B04 CAP,CHIP,.1UF,+10%,-10%, 10V-

DC,0402,X5R,-55DEG CMIN,

85DEG CMAX

C5006 2113946B04 CAP,CHIP,.1UF,+10%,-10%, 10V-

DC,0402,X5R,-55DEG CMIN,

85DEG CMAX

C5007 2113946B04 CAP,CHIP,.1UF,+10%,-10%, 10V-

DC,0402,X5R,-55DEG CMIN,

85DEG CMAX

C5008 2113946B04 CAP,CHIP,.1UF,+10%,-10%, 10V-

DC,0402,X5R,-55DEG CMIN,

85DEG CMAX

C5009 2113946B04 CAP,CHIP,.1UF,+10%,-10%, 10V-

DC,0402,X5R,-55DEG CMIN,

85DEG CMAX

C5010 2113946B04 CAP,CHIP,.1UF,+10%,-10%, 10V-

DC,0402,X5R,-55DEG CMIN,

85DEG CMAX

C5011 2113946B04 CAP,CHIP,.1UF,+10%,-10%, 10V-

DC,0402,X5R,-55DEG CMIN,

85DEG CMAX

C5012 2113946B04 CAP,CHIP,.1UF,+10%,-10%, 10V-

DC,0402,X5R,-55DEG CMIN,

85DEG CMAX

C5013 2113946B04 CAP,CHIP,.1UF,+10%,-10%, 10V-

DC,0402,X5R,-55DEG CMIN,

85DEG CMAX

C5014 2113946B04 CAP,CHIP,.1UF,+10%,-10%, 10V-

DC,0402,X5R,-55DEG CMIN,

85DEG CMAX

C5015 2113946B04 CAP,CHIP,.1UF,+10%,-10%, 10V-

DC,0402,X5R,-55DEG CMIN,

85DEG CMAX

Ref.

Des.

Part Number Description

Digital Technology	P25 Phase 1 and Phase 2
Emergency Button	Yes
Frequency Range	136-174 MHz (VHF), 380-470 MHz (UHF Range 1), 450-520 MHz (UHF Range 2), 764-870 MHz (700/800 MHz)
Display	Color LCD
Encryption	AES, DES
Water Resistance	IP67
GPS	Yes
Bluetooth	Yes
Operating Temperature	-30°C to +60°C
Weight	391 g (with standard battery)

Motorola APX 7000 Detailed Service Manual
