Motorola APX 7000 Detailed Service Manual

8-298 Schematics, Boards Overlays, and Parts Lists: VOCON Boards
C5016 2113946B04 CAP,CHIP,.1UF,+10%,-10%, 10V-
DC,0402,X5R,-55DEG CMIN,
85DEG CMAX
C5017 2113946B04 CAP,CHIP,.1UF,+10%,-10%, 10V-
DC,0402,X5R,-55DEG CMIN,
85DEG CMAX
C5018 2113946B04 CAP,CHIP,.1UF,+10%,-10%, 10V-
DC,0402,X5R,-55DEG CMIN,
85DEG CMAX
C5019 2113946B04 CAP,CHIP,.1UF,+10%,-10%, 10V-
DC,0402,X5R,-55DEG CMIN,
85DEG CMAX
C5020 2113946B04 CAP,CHIP,.1UF,+10%,-10%, 10V-
DC,0402,X5R,-55DEG CMIN,
85DEG CMAX
C5021 2113946B04 CAP,CHIP,.1UF,+10%,-10%, 10V-
DC,0402,X5R,-55DEG CMIN,
85DEG CMAX
C5022 2113946B04 CAP,CHIP,.1UF,+10%,-10%, 10V-
DC,0402,X5R,-55DEG CMIN,
85DEG CMAX
C5023 2113946B04 CAP,CHIP,.1UF,+10%,-10%, 10V-
DC,0402,X5R,-55DEG CMIN,
85DEG CMAX
C5024 2113946B04 CAP,CHIP,.1UF,+10%,-10%, 10V-
DC,0402,X5R,-55DEG CMIN,
85DEG CMAX
C5025 2113946B04 CAP,CHIP,.1UF,+10%,-10%, 10V-
DC,0402,X5R,-55DEG CMIN,
85DEG CMAX
C5026 2113946B04 CAP,CHIP,.1UF,+10%,-10%, 10V-
DC,0402,X5R,-55DEG CMIN,
85DEG CMAX
C5027 2113946B04 CAP,CHIP,.1UF,+10%,-10%, 10V-
DC,0402,X5R,-55DEG CMIN,
85DEG CMAX
C5028 2113946B04 CAP,CHIP,.1UF,+10%,-10%, 10V-
DC,0402,X5R,-55DEG CMIN,
85DEG CMAX
C6101 NOT PLACED –
C6102 NOT PLACED –
C6103 NOT PLACED –
C6104 2113946B04 CAP,CHIP,.1UF,+10%,-10%, 10V-
DC,0402,X5R,-55DEG CMIN,
85DEG CMAX
Ref.
Des.
Part Number Description
C6105 2113946B04 CAP,CHIP,.1UF,+10%,-10%, 10V-
DC,0402,X5R,-55DEG CMIN,
85DEG CMAX
C6106 2113946B04 CAP,CHIP,.1UF,+10%,-10%, 10V-
DC,0402,X5R,-55DEG CMIN,
85DEG CMAX
C6107 2113946B04 CAP,CHIP,.1UF,+10%,-10%, 10V-
DC,0402,X5R,-55DEG CMIN,
85DEG CMAX
C6108 2113946B04 CAP,CHIP,.1UF,+10%,-10%, 10V-
DC,0402,X5R,-55DEG CMIN,
85DEG CMAX
C6109 2113946B04 CAP,CHIP,.1UF,+10%,-10%, 10V-
DC,0402,X5R,-55DEG CMIN,
85DEG CMAX
C6110 2113946B04 CAP,CHIP,.1UF,+10%,-10%, 10V-
DC,0402,X5R,-55DEG CMIN,
85DEG CMAX
C6111 2113946B04 CAP,CHIP,.1UF,+10%,-10%, 10V-
DC,0402,X5R,-55DEG CMIN,
85DEG CMAX
C6112 2113946B04 CAP,CHIP,.1UF,+10%,-10%, 10V-
DC,0402,X5R,-55DEG CMIN,
85DEG CMAX
C6113 2113946B04 CAP,CHIP,.1UF,+10%,-10%, 10V-
DC,0402,X5R,-55DEG CMIN,
85DEG CMAX
C6114 2113946B04 CAP,CHIP,.1UF,+10%,-10%, 10V-
DC,0402,X5R,-55DEG CMIN,
85DEG CMAX
C6115 2113946B04 CAP,CHIP,.1UF,+10%,-10%, 10V-
DC,0402,X5R,-55DEG CMIN,
85DEG CMAX
C6201 2113944A40 CAP,CHIP,100PF,+5%,-10%, 50V-
DC,0402,C0G,-55DEG
CMIN,125DEG CMAX
C6202 2113945A09 CAP,CHIP,1000PF,+10%,-10%,
50V-DC,0402,X7R,-55DEG
CMIN,125DEG CM
C6203 2113946B04 CAP,CHIP,.1UF,+10%,-10%, 10V-
DC,0402,X5R,-55DEG CMIN,
85DEG CMAX
C6301 2113946B04 CAP,CHIP,.1UF,+10%,-10%, 10V-
DC,0402,X5R,-55DEG CMIN,
85DEG CMAX
C6302 2113946B04 CAP,CHIP,.1UF,+10%,-10%, 10V-
DC,0402,X5R,-55DEG CMIN,
85DEG CMAX
Ref.
Des.
Part Number Description
C6303 2113946B04 CAP,CHIP,.1UF,+10%,-10%, 10V-
DC,0402,X5R,-55DEG CMIN,
85DEG CMAX
C6304 2113946B04 CAP,CHIP,.1UF,+10%,-10%, 10V-
DC,0402,X5R,-55DEG CMIN,
85DEG CMAX
C6305 2113946S35 CAP,CHIP,1UF,+10%,-10%, 16V-
DC,0603,X5R,-55DEG CMIN,
85DEG CMAX,P
C6306 2113946S35 CAP,CHIP,1UF,+10%,-10%, 16V-
DC,0603,X5R,-55DEG CMIN,
85DEG CMAX,P
C6307 2113946B04 CAP,CHIP,.1UF,+10%,-10%, 10V-
DC,0402,X5R,-55DEG CMIN
,85DEG CMAX
C6308 2113946B04 CAP,CHIP,.1UF,+10%,-10%, 10V-
DC,0402,X5R,-55DEG CMIN,
85DEG CMAX
C6309 2113946B04 CAP,CHIP,.1UF,+10%,-10%, 10V-
DC,0402,X5R,-55DEG CMIN,
85DEG CMAX
C6310 2113946B04 CAP,CHIP,.1UF,+10%,-10%, 10V-
DC,0402,X5R,-55DEG CMIN,
85DEG CMAX
C6311 2113946B04 CAP,CHIP,.1UF,+10%,-10%, 10V-
DC,0402,X5R,-55DEG CMIN,
85DEG CMAX
C6401 NOT PLACED –
C6402 2113956A51 CAP,FXD,1UF,+10%,-10%, 6.3V-
DC,0402,X5R,-55DEG CMIN,
85DEG CMAX,P
C6403 2113946B04 CAP,CHIP,.1UF,+10%,-10%, 10V-
DC,0402,X5R,-55DEG CMIN,
85DEG CMAX
C6404 2113946B04 CAP,CHIP,.1UF,+10%,-10%, 10V-
DC,0402,X5R,-55DEG CMIN,
85DEG CMAX
C6405 NOT PLACED –
C6406 2113946B04 CAP,CHIP,.1UF,+10%,-10%, 10V-
DC,0402,X5R,-55DEG CMIN,
85DEG CMAX
C6407 2113946B04 CAP,CHIP,.1UF,+10%,-10%, 10V-
DC,0402,X5R,-55DEG CMIN,
85DEG CMAX
C6408 2113946B04 CAP,CHIP,.1UF,+10%,-10%, 10V-
DC,0402,X5R,-55DEG CMIN,
85DEG CMAX
Ref.
Des.
Part Number Description
C6409 NOT PLACED –
C6410 2113946B04 CAP,CHIP,.1UF,+10%,-10%, 10V-
DC,0402,X5R,-55DEG CMIN,
85DEG CMAX
C6411 2113946B04 CAP,CHIP,.1UF,+10%,-10%, 10V-
DC,0402,X5R,-55DEG CMIN,
85DEG CMAX
C6412 NOT PLACED –
C6413 2113946B04 CAP,CHIP,.1UF,+10%,-10%, 10V-
DC,0402,X5R,-55DEG CMIN,
85DEG CMAX
C6414 2113946B04 CAP,CHIP,.1UF,+10%,-10%, 10V-
DC,0402,X5R,-55DEG CMIN,
85DEG CMAX
C6415 NOT PLACED –
C6416 2113945B04 CAP,FXD,.022UF,+10%,-10%,
25V-DC,0402,X7R,-55DEG
CMIN,125DEG CMA
C6417 2113945B04 CAP,FXD,.022UF,+10%,-10%,
25V-DC,0402,X7R,-55DEG
CMIN,125DEG CMA
C6418 2113946B04 CAP,CHIP,.1UF,+10%,-10%, 10V-
DC,0402,X5R,-55DEG CMIN,
85DEG CMAX
C6419 2113946B04 CAP,CHIP,.1UF,+10%,-10%, 10V-
DC,0402,X5R,-55DEG CMIN,
85DEG CMAX
C6420 2113945B04 CAP,FXD,.022UF,+10%,-10%,
25V-DC,0402,X7R,-55DEG
CMIN,125DEG CMA
C6421 2113946B04 CAP,CHIP,.1UF,+10%,-10%, 10V-
DC,0402,X5R,-55DEG CMIN,
85DEG CMAX
C6422 2113946C02 CAP,CHIP,.22UF,+10%,-10%, 10V-
DC,0603,X5R,-55DEG
CMIN,85DEG CMAX
C6423 2113946B04 CAP,CHIP,.1UF,+10%,-10%, 10V-
DC,0402,X5R,-55DEG CMIN,
85DEG CMAX
C6424 2113944A40 CAP,CHIP,100PF,+5%,-10%, 50V-
DC,0402,C0G,-55DEG
CMIN,125DEG CMAX
C6425 2113944A40 CAP,CHIP,100PF,+5%,-10%, 50V-
DC,0402,C0G,-55DEG
CMIN,125DEG CMAX
Ref.
Des.
Part Number Description
