1.3.4ReplacingtheBattery
1.3.4ReplacingtheBattery
EnsurethattheBatterySwapmodeproceduresarefollowed,otherwisethebackupbatterywilldeplete
quickly.
ProcedureSteps
1PressthePowerbuttonuntilthemenudisplays.
2TouchBatteryswap.TheRightandLeftLEDslightred.
3WaituntiltheLEDsturnsoff.
4Liftthebatterylatch.
Figure1-4LiftBatteryLatch
MN000111A01-August2013
1-7
