3.4BarCodeCapturewithImager
2Pointthetopofthedeviceatabarcode.
Figure3-1BarCodeScanning
3PressandholdtheScanbutton.
Theredlaseraimingpatternturnsontoassistinaiming.Ensurethebarcodeiswithintheareaformedbythe
cross-hairsintheaimingpattern.Theaimingdotisusedforincreasedvisibilityinbrightlightingconditions.
TheLeftandRightLEDslightredtoindicatethatscanningisinprocess,thenlightgreen,abeepsoundsandthe
MC40vibrates,bydefault,toindicatethebarcodewasdecodedsuccessfully.NotethatwhentheMC40isin
PickListMode,theMC40doesnotdecodethebarcodeuntilthecenterofthecrosshairtouchesthebarcode.
Figure3-2AimingPattern
Figure3-3PickListModewithMultipleBarCodesinAimingPattern
4Releasethescanbutton.
5Thecaptureddataappearsinthetexteld.
