1.2Unpacking
Figure1-2BackView
18
19
20
21
22
23
24
25
Table1-2Features-BackView
NumberItemFunction
18
Battery
ProvidestheMC40withoperatingpower.
19
BatteryLatchSecuresthebatteryinposition.
20Camera
Takesphotos,videos,andcapturesbarcodedata.
21
Right
Scan/Action
Button
Initiatesscanningwhenascanapplicationisenabled(default).
ProgrammableusingButtonRemapProgram.SeeMC40Integrator
Guideformoreinformation.
22
V olumeControlIncreasesanddecreaseaudiovolume.ProgrammableusingButton
RemapProgram.See
MC40IntegratorGuideformoreinformation.
23
Imager
Capturesbarcodedata.
24
MSRSlot
(Optional)
Usetoswipemagneticstripecardsduringcreditordebittransactions.
25
FingerStrapPlugCoversmountingareaforoptionalFingerStrap.
1.2Unpacking
CarefullyremoveallprotectivematerialfromtheMC40andsavetheshippingcontainerforlaterstorageand
shipping.
Verifythefollowingitemsareinthebox:
•MC40
MN000111A01-August2013
1-3
