1 - 2 MC40 Integrator Guide
Installing the Battery
To install the battery:
1. Align the battery with the slots in the battery compartment.
2. Lower the battery and snaps into place.
3. Press down on the battery latch. If the battery is charged, the MC40 turns on automatically.
Figure 1-1
Inserting the Battery
Charging the Battery
Charging the Main Battery
Before using the MC40 for the first time, charge the main battery until the Right light emitting diode (LED) turns
solid green (see Table 1-1 on page 1-3 for charge status indications). To charge the MC40, use a cable or a
cradle with the appropriate power supply. For information about the accessories available for the MC40, see
Chapter 7, Accessories.
The MC40 is equipped with a memory backup battery that automatically charges from the fully-charged main
battery. When using the MC40 for the first time, the backup battery requires approximately 36 hours to fully
charge. This is also true any time the backup battery is discharged, which occurs when the main battery is
removed for several hours. The backup battery retains random access memory (RAM) data in memory for at
least 10 minutes (at room temperature) when the MC40’s main battery is removed, when Battery Swap feature
is used. When the MC40 reaches a very low battery state, the combination of main battery and backup battery
retains RAM data in memory for at least 48 hours.
For cable and cradle setup and charging procedures, see Chapter 2, Accessories.
•
Micro USB Cable
•
Single Slot Charging Cradle
•
Five Slot Universal Charge Only Cradle.
To charge the main battery:
CAUTION Ensure that you follow the guidelines for battery safety described in Battery Safety Guidelines on page
9-1.
