APPENDIX A TECHNICAL
SPECIFICATIONS
MC40 Technical Specifications
The following table summarizes the MC40’s intended operating environment and technical hardware
specifications.
Table A-1
MC40 Technical Specifications
Item Description
Physical Characteristics
Dimensions Height: 143.9 mm (5.66 in.)
Width: 72.8 mm (2.87 in.)
Non-MSR: Depth: 20.1 mm (0.79 in.)
MSR: Depth: 31.8 mm (1.25 in.)
Weight Non-MSR: 257.7 g (9.09 oz.)
MSR: 266.1 g (9.38 oz.)
Display 4.3 in. capacitive; 480 x 800; 300 nit
Touch Panel Capacitive dual-touch
Backlight LED backlight
Battery Rechargeable Lithium Ion 3.7V, 2680 mAh Smart battery
Backup Battery NiMH battery (rechargeable) 15 mAh 3.6 V (not user accessible).
Connectivity One USB 2.0 OTG connector
Notification LED, audio and vibration.
Keypad Options On-screen keyboard
Audio Speakers, microphone and headset connector (mono, 2.5 mm jack with
microphone). Stereo audio through Bluetooth stereo headsets.
