Accessories 10 - 9
VCD5000 Vehicle Cradle
This section describes how to use a VCD5000 vehicle cradle with the MC65. For cradle installation and
communication setup procedures refer to the MC65 Integrator Guide.
Once installed in a vehicle, the cradle:
•
holds the MC65 securely in place
•
provides power for operating the MC65
•
re-charges the battery in the MC65.
Charging the MC65 Battery
Insert the MC65 into the vehicle cradle to begin charging. A click indicates that the MC65 button release
locking mechanism is enabled and the MC65 is locked in place.
Figure 10-8
MC65 Battery Charging
Removing the MC65
To remove the MC65, hold back the release lever on the cradle and pull the MC65 up and out of the cradle.
CAUTION Ensure the MC65 is fully inserted in the cradle. Lack of proper insertion may result in property damage
or personal injury. Motorola is not responsible for any loss resulting from the use of the products while
driving.
