4 - 6 MC65 User Guide
24. Tap Save.
Wireless Zero Config Setup
To setup WLAN using WZC:
1. Tap Status Bar > > Wireless Zero Config.
Figure 4-9
Wireless Zero Config Window
2. The MC65 searches for wireless networks in the area and displays them in the window.
3. Tap a network name.
Figure 4-10
Configure Wireless Network Window
4. In the Connects to drop-own list, select either The Internet or Work.
5. Check the This is a hidden network checkbox if the network is a hidden network.
6. Tap Next.
NOTE Obtain the proper WLAN configuration information from your system administrator prior to performing the
WZC setup procedures.
The following setup procedure example shows setup of a WLAN using WEP encryption.
