1 - 8 MC65 User Guide
Replacing the Battery
1. If the MC65 is in suspend mode, press the red Power button to wake the device.
2. Press and hold the red Power button for approximately 5 seconds.
3. Release the Power button. The Data Capture LED lights red.
4. When the LED turns off, remove the handstrap.
5. Slide the battery latch to the right. The battery ejects slightly.
Figure 1-6
Removing the Battery
6. Lift the battery from the MC65.
7. Insert the replacement battery, bottom first, into the battery compartment in the back of the MC65.
8. Press the battery down until the battery release latch snaps into place.
9. Replace the handstrap.
Replacing the microSD Card
To replace an microSD card:
1. If the MC65 is in suspend mode, press the red Power button to wake the device.
2. Press and hold the red Power button for approximately 5 seconds.
3. Release the Power button. The Data Capture LED lights red.
4. When the LED turns off, remove the handstrap.
5. Remove the battery.
CAUTION The MC65 backup battery retains data for up to 15 minutes. Replace the battery within 15 minutes to
ensure that application states are maintained and that data is not lost.
2
Battery Latch
CAUTION The MC65 backup battery retains data for up to 15 minutes. Replace the battery within 15 minutes to
ensure that application states are maintained and that data is not lost.
