Getting Started 1 - 13
Figure 1-10
Feed handstrap into Handstrap Slot
2. Slide pin into bottom of handstrap.
3. Center the pin in the handstrap loop.
4. Pull handstrap so that the pin and bottom of handstrap slide into position in the mounting area.
Figure 1-11
Pin and Handstrap in Mounting Area
Figure 1-12
Slide Handstrap and Tether Over Handstrap Mount
5. Slide tether loop over handstrap.
6. Insert the handstrap clip into the slot on the device. Ensure that it is securely in place.
NOTE Handstrap and pin should fit securely into the handstrap mounting area. When pulling on handstrap use
enough force to engage pin into place.
