OnCell G3100 Series Introduction
OnCell
G3110/G3150
OnCell
G3110/G3150-HSPA
Tx Power 1 watt GSM1800/1900,
2 watt EGSM850/900
1 watt GSM1800,
2 watt GSM900,
0.25 watt UMTS/HSPA,
0.5 watt EDGE900,
0.4 watt EDGE1800
GPRS Multi-slot
class
12 12
GPRS Mobile
Station Class
Class B
EDGE Multi-slot
class
12 12
EDGE Mobile
Station Class
Class B
GPRS Coding
Schemes
CS1 to CS4
SIM Control 3V
Serial Interface
No. of Ports 1
ESD Protection 15 KV
Serial Standards G3110/G3110: RS-232 (DB9 male connector)
G3150/G3150: RS-232 (DB9 male connector), RS-422/485 (5-pin terminal block
connector)
Serial Communication Parameters
Parity None, Even, Odd, Space, Mark
Data Bits 5, 6, 7, 8
Stop Bit(s) 1, 1.5, 2 (when parity = None)
Flow Control RTS/CTS, XON/XOFF
Speed 50 bps to 921.6 Kbps
Serial Signals
RS-232 TxD, RxD, RTS, CTS, DTR, DSR, DCD, GND
RS-422 Tx+, Tx-, Rx+, Rx-, GND
RS-485-4w Tx+, Tx-, Rx+, Rx-, GND
RS-485-2w Data+, Data-, GND
I/O Interface
Alarm Contact 1 relay output with current carrying capacity of 1A@24 VDC
Digital Input 2 inputs electrically isolated from the electronics
+13 to +30 V for state “1” (On)
+3 to -30 V for state “0” (Off)
Software Features
Network Protocols ICMP, TCP/IP, UDP, DHCP, Telnet, DNS, SNMP, HTTP, SMTP, HTTPS, SNTP, ARP, SSL
Operation Modes Real COM, Reverse Real COM, TCP Server, TCP Client, UDP, RFC2217, Ethernet Modem,
SMS Tunnel
Secure Operation
Modes
Secure Real COM, Secure Reverse Real COM, Secure TCP Client, Secure TCP Server
Configuration and
Management
Options
SNMP MIB-II, SNMP Private MIB, SNMPv1/v2c/v3, DDNS, IP Report, Web/Telnet/Serial
Console/SSH
Authentication Local user-name and password
Security Accessible IP list
Utilities Provided for Windows 95/98/ME, Windows NT, Windows
2000/XP/2003/Vista/Server-2008, Windows XP/2003/Vista/ Server-2008 x64 Edition
