Scanning area
The scanned area is shown below.
Letter
Legal
Fax : 8.2 in. (208 mm)
Copy, Scan : 8.5 in. (216 mm)
Fax
: 0.08 in. (2.0 mm)
Copy, Scan : 0 in. (0 mm)
Fax
: 0.1 in. (2.5 mm)
Copy, Scan : 0 in. (0 mm)
Scanned area
Loading documents in the ADF
1
Insert the documents face-up, top edge first.
2
Adjust the document guides to the document
size.
Loading the document on the document glass
1
Make sure there is no documents in the ADF.
2
Lift the platen cover.
3
Face down the document and place it on the
document glass. The document should be
aligned to the upper left corner.
4
Gently close the platen cover.
IMPORTANT: When copying a bound document, such as a book, the copied image may contain
some black areas. To reduce this effect, hold down the document to prevent its
bound part from rising. However, do not press too strongly. This may break the
document glass and cause an injury.
