VJ-1624/1624W OPERATION MANUAL 3 Before using
3-75
18. Firmly pinch the tabs on both sides of Connector cap with your fingers, and install it to the connector
of Print head.
19. Press the [Enter] key.
• "Wait for a while..." is displayed on Operation panel.
• "Remove white plate, then close left maintenance cover." is displayed on Operation panel.
No. Name
1 Connector cap
2Tabs
3 Print head section
4 Connector
1
2
2
4
1
3
To Next Page
