VJ-1624/1624W OPERATION MANUAL 4 Handling the printer
4-33
4.5 Using Spectrophotometer (VJ-1624 only)
NOTE
• VJ-1624W cannot be equipped with Spectrophotometer (SPECTROVUE VM-10).
The optional spectrophotometer (SPECTROVUE VM-10) can be attached to print and measure the color
target. Performing color calibration or profiling of the printer by using RIP software compatible with
SPECTROVUE VM-10 enables printing with more accurate colors.
For Software server RIP (option), contact MUTOH local dealer.
Follow the procedure below.
CAUTION
When using Spectrophotometer (SPECTROVUE VM-10), make sure to use the media
whose thickness is less than 0.7mm. If you use the media thicker than 0.7mm,
Spectrophotometer may come into contact with media and damaged.
NOTE
• Do not install the printer in a place that is subject to strong light (sunlight, etc).
Getting strong light on the color measurement may affect the measurement accuracy.
• To use Spectrophotometer (SPECTROVUE VM-10), the printer setting must be as follows. Make
sure the setting before use.
• Media detection: Top&Width or Width
5.1.4 Media Initial menu
• Media ejection mode: Off or Auto Cut
5.1.6 Output Mode menu
• When the color target is printed on the translucent or colored media, or the media with patterned
indented surfaces, color measurement may not be accurate.
• Read the instruction manual of Spectrophotometer as well.
• When measuring colors, make sure that the color target is dry. If it is not dry enough, the ink may
adhere to the pressurizing rollers of the printer.
1. Connect the printer and computer.
3.7 Connecting the printer to PC
2. Turn the printer ON.
3. Set the media.
3.4 Loading media
