MUTOH ValueJet VJ-1624 - Names of Parts and Functions

2 Product overview VJ-1624/1624W OPERATION MANUAL
2-2
2.1 Names of parts and functions
This section explains the names and functions of each part.
2.1.1 Front section
NOTE
The illustrations used in this section are those of VJ-1624.
No. Name Function
1 Media loading lever Used for fixing or releasing the media.
• Lower Lever to fix the media.
• Lower Lever further to fix the media firmly.
Used to improve the accuracy of media feeding.
• Raise Lever to release the media.
2 Operation panel Used to set the operation condition, printer display and various functions.
2.1.3 Operation panel
