VJ-1624/1624W OPERATION MANUAL 3 Before using
3-103
3.6.2.3 Custom micro adjustment pattern
Perform micro adjustment when the degree of misalignment is small.
This menu consists of the following menus.
3.6.2.3.1 Adj. PatternALL
Print micro adjustment pattern ALL and register the set values.
1. Display the Custom Adjust Print menu on Operation panel in the same way as Step 2 of "3.6.2.1
Custom confirmation pattern".
2. Press the [+] key or [-] key on Operation panel to select "Adj.3: Fine Pattern".
3. Press the [Enter] key on Operation panel.
• For VJ-1624, "Warming Up Skip ->E" is displayed on Operation panel.
(This is not displayed for VJ-1624W since it does not perform warming up.)
Menu name Description Reference
Custom micro
adjustment
pattern
Adj. PatternALL All confirmation patterns (A to F) will be
adjusted.
3.6.2.3.1 Adj. PatternALL
Individual Adj.
pattern
One of the confirmation patterns (A to F)
will be adjusted.
3.6.2.3.2 Individual Adj. pattern
To Next Page
