VJ-1624/1624W OPERATION MANUAL 3 Before using
3-53
e. Hold Damper drive switching plate and tighten the screws (2 pieces).
f. Make sure that Damper stopper does not rotate.
g. Change the locations of Damper drive switching plate of Media holder L in the same way, and
fix Damper stopper.
• The torque of Media holder is changed to 0.7kg.
3.4.5 Changing the torque of Roll media holder (for VJ-1624W)
This section describes the procedure to change the torque of Roll media holder.
The torque should be the same as at the factory shipment. However, if the media is wrinkled or it may
come in contact with Print head, follow the procedure below to fix Damper stopper and change the torque
to 1kg or 4kg.
No. Name
1 Damper drive switching plate
2Screw
No. Name
1 Roll media holder (Left)
2 Damper drive switching plate
3 Damper stopper
1
2
3
1
1
2
