8 Appendix VJ-1624/1624W OPERATION MANUAL
8-2
8.1 Product specifications
8.1.1 Printer specifications
Items Specification
Model name VJ-1624
VJ-1624W
Printing method On-demand piezo drive system
Drive system Firmware servo/DC motor drive
Media feed system Multipoint pressurizing grid roller system
Media fixing system Pressurization roller down system by manual lever
Media feed/ejection Rear feed/Front ejection
Roll media outer diameter 150mm or less
Roll media weight 30kg or less
Maximum media width 1,625mm
Minimum media width 900mm
Maximum media thickness VJ-1624: 0.3mm (when the head height is Low)/1.3mm (when the head height
is High)
VJ-1624W: 0.3 mm (when the head height is Low)/1.3 mm (when the head
height is Mid)/2.8 mm (when the head height is High)
Maximum printable media width 1,615mm
Print margin Top: 5 mm (15 mm after media initialization or after winding the media
manually, 40 mm when media initialization front edge detection is ON or after
cutting the media), Bottom: 5 mm (102 mm at the roll media end), Left: 5 mm
to 25 mm, Right: 5 mm to 25 mm.
Media cut system Horizontal automatic cut system/manual cut system
Head height adjustment VJ-1624: Two-level adjustment of Low and High
VJ-1624W: Three-level adjustment of Low, Mid, and High
CPU 64-bit RISC CPU
Memory 128MB
Command MH-RTL (RTL-PASS)
Interface Network interface (Ethernet IEEE 802.3)
Ink Supply system Supplied through tubes from independent color cartridges
Cartridges <VJ-1624>
Black, Cyan, Magenta, Yellow: 220ml ± 5ml each or 440ml ± 5ml (1000ml ±
5ml when the optional High-capacity ink pack adapter is used)
<VJ-1624W>
Black, Cyan, Magenta, Yellow: 220ml ± 5ml each
